Dimensions and Packaging

7.1. General Description

This chapter mainly describes mechanical dimensions as well as packaging specification of EG21-G Mini
PCIe module. All dimensions are measured in millimeter (mm), and the dimensional tolerances are
± 0.05mm unless otherwise specified.

7.2. Mechanical Dimensions of EG21-G Mini PCIe

30.00±0.20
8.34 6.39
2.90
0.50
0.80
2.35
2.15 8.25
11.15
EG21-G_Mini_PCIe_Hardware_Design
6.39
24.20
29.00
1.65
0.60
15.95
1.50
Top
Figure 19: Mechanical Dimensions of EG21-G Mini PCIe
EG21-G Mini PCIe Hardware Design
1.00±0.10
2.45±0.20
0.58
1.45
Side
LTE Standard Module Series
28.80
2.05 1.95
0.60
0.80
Bottom
