Key Features - Quectel LTE Standard Module Series Hardware Design

GSM
GNSS (Optional)
Digital Audio (PCM)

2.3. Key Features

The following table describes the detailed features of EG21-G Mini PCIe module.
Table 2: Key Features of EG21-G Mini PCIe
Features
Function Interface
Power Supply
Transmitting Power
LTE Features
UMTS Features
GSM Features
EG21-G_Mini_PCIe_Hardware_Design
850/900/1800/1900MHz
GPS, GLONASS, BeiDou (Compass), Galileo, QZSS
Supported
Description
PCI Express Mini Card 1.2 Standard Interface
Supply voltage: 3.0V~3.6V
Typical supply voltage: 3.3V
Class 4 (33dBm± 2dB) for GSM850
Class 4 (33dBm± 2dB) for EGSM900
Class 1 (30dBm± 2dB) for DCS1800
Class 1 (30dBm± 2dB) for PCS1900
Class E2 (27dBm± 3dB) for GSM850 8-PSK
Class E2 (27dBm± 3dB) for EGSM900 8-PSK
Class E2 (26dBm± 3dB) for DCS1800 8-PSK
Class E2 (26dBm± 3dB) for PCS1900 8-PSK
Class 3 (24dBm+1/-3dB) for WCDMA bands
Class 3 (23dBm± 2dB) for LTE-FDD bands
Class 3 (23dBm± 2dB) for LTE-TDD bands
Support up to non-CA Cat 1 FDD and TDD
Support 1.4/3/5/10/15/20MHz RF bandwidth
Support MIMO in DL direction
LTE-FDD: Max 10Mbps (DL), Max 5Mbps (UL)
LTE-TDD: Max 8.96Mbps (DL), Max 3.1Mbps (UL)
Support 3GPP R8 DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA
Support QPSK,16-QAM and 64-QAM modulation
DC-HSDPA: Max 42Mbps (DL)
HSUPA: Max 5.76Mbps (UL)
WCDMA: Max 384Kbps (DL), Max 384Kbps (UL)
GPRS:
Support GPRS multi-slot class 33 (33 by default)
Coding scheme: CS-1, CS-2, CS-3 and CS-4
LTE Standard Module Series
EG21-G Mini PCIe Hardware Design
10 / 54
