Introduction

The MaxiProgrammer 201 is specially designed to read Volkswagen
vehicle key chip data, clone and generate exclusive keys, read/write
on-board EEPROM data, and read/write Freescale 9S12 MCUs. By
working with diagnostic tool and PC that are both loaded with
programmer software, the MaxiProgrammer 201 can read/write key
chip data quickly and accurately.

Specifications

Item
Operating Temperature
Storage Temperature
Port
Input Voltage
Operating Current
Maximum Consumption
Device Dimensions (L*W*H)
Package Dimensions (L*W*H)
Net Weight
Gross Weight
Table 2-1 Specifications
Description
-10℃ ~ 85℃ (14℉ ~ 185℉)
-20℃ ~ 85℃ (-4℉ ~ 185℉)
Mini USB, VGA_DB15
5 VDC
< 250 mA
1 W
130 mm * 68 mm * 28 mm
201 mm * 167 mm * 75 mm
466 g
11 kg (20 pcs)
