Autel MaxiProgrammer 201 Manual page 9

No. Color
3 Green
4 Black
5 White
6 Blue
7 Brown
8 Yellow
9 Red
2. EEPROM Clamp Cable
Table 2-4 Definitions of EEPROM Clamp Cable
No. Color
White and
10
Red
White and
11
Purple
White and
12
Blue
13 Grey
White and
14
Brown
White and
15
Green
Table 2-3 Definitions of MC9S12 Cable
Definition
TXCLKS
GND
TOSC
TSW
GND
TRESET
VDD
Definition
P1
P2
P3
P4
P5
P6
Pin correspond
to DB15
1
2
6
7
8
11
12
Pin correspond
to DB15
5
15
10
4
14
9
7
Note
Shielded line
Shielded line
Note
Pin 1 is red
