  • Page 1 MaxiRecorder MaxiTPMS ® MaxiCheck are trademarks of Autel Intelligent Technology Corp., Ltd., registered in China, the United States and other countries. All other marks are trademarks or registered trademarks of their respective holders. Copyright Information No part of this manual may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Auteltech.

  • Page 2: Table Of Contents

    Contents 1 SAFETY PRECAUTIONS ..............1 2 INTRODUCTION ................2 ................2 PECIFICATIONS ..............3 CCESSORIES NCLUDED ..............4 OMPONENTS AND ORTS 3 PRODUCT TROUBLESHOOTING ..........13 4 UPDATE ..................14 ................14 OFTWARE PDATE 5 COMPLIANCE INFORMATION ............16 6 WARRANTY AND SERVICE ............18 ............18 IMITED ARRANTY...

  • Page 3: Safety Precautions

    Safety Precautions The AUTELTECH MaxiProgrammer 201 (XP201 for short) has been carefully designed to help automotive technicians maintaining and servicing modern vehicles. To avoid personal injury or damage to vehicles, please read this manual first and observe the following safety precautions whenever working on a vehicle.

  • Page 4: Introduction

    Introduction The MaxiProgrammer 201 is specially designed to read Volkswagen vehicle key chip data, clone and generate exclusive keys, read/write on-board EEPROM data, and read/write Freescale 9S12 MCUs. By working with diagnostic tool and PC that are both loaded with programmer software, the MaxiProgrammer 201 can read/write key chip data quickly and accurately.

  • Page 5: Accessories Included

    Accessories Included APB001 – EEPROM Adaptor APA002 – EEPROM Socket APA001 – EEPROM Clamp Integrated MC9S12 Cable User’s Manual APC001 – USB Cable (Standard USB – Mini USB) APC002 – USB Cable (Mini USB – Mini USB) (Optional) The two types of USB cables work with different products, please choose the corresponding USB cable for the product you use.

  • Page 6: Components And Ports

    Components and Ports Figure 2-1 MaxiProgrammer 201 Views Vehicle Key Chip Slot – holds the vehicle key chip. Vehicle Key Slot – holds the vehicle key. Status LED Light – indicates the current operating status. Connection Port – connects EEPROM Adaptor and EEPROM Clamp Integrated MC9S12 Cable.
  • Page 7 device. See Table 2-2 for detailed description. Table 2-2 Status LED Light on the Front Panel LED Light Color/Status Description Solid Green Powered on and Default Status Power Flashing Green Communication Status Solid Red Error Status Connection Port There are two accessories that can be paired with the connection port: EEPROM Clamp Integrated MC9S12 Cable and EEPROM Adaptor.
  • Page 8 EEPROM Clamp Integrated MC9S12 Cable Figure 2-2 EEPROM Clamp Integrated MC9S12 Cable MC9S12 Cable...
  • Page 9 Table 2-3 Definitions of MC9S12 Cable correspond Color Definition Note to DB15 Green TXCLKS Black Shielded line White TOSC Shielded line Blue Brown Yellow TRESET EEPROM Clamp Cable Table 2-4 Definitions of EEPROM Clamp Cable Pin correspond Color Definition Note to DB15 White and Pin 1 is red...
  • Page 10 White and Orange White and Black black Here are the possible causes for EEPROM read/write failure and data error when connecting the clamp to the test board for EEPROM read/write: A. EEPROM read/write operations are affected by the circuit of the connected test board;...
  • Page 11 and the diagnostic device or the PC, and it is also the port for power supply charge. EEPROM Read/Write Supported Types Chip Type Name Chip Type Name ATMEL AT24C01 M24C04 ATMEL AT24C02 M24C08 ATMEL AT24C04 M24C16 ATMEL AT24C08 M24C32 ATMEL AT24C16 M24C64 ATMEL...
  • Page 12 Chip Type Name Chip Type Name M24C01 ATMEL AT25320 M24C02 ATMEL AT25640 ATMEL AT25128 MICROCHIP 25xx080 ATMEL AT25256 MICROCHIP 25xx160 ATMEL AT25512 MICROCHIP 25xx320 ATMEL AT25010_1.8 MICROCHIP 25xx640 ATMEL AT25020_1.8 MICROCHIP 25xx040_TSSOP ATMEL AT25040_1.8 MICROCHIP 25xx320_TSSOP ATMEL AT25080_1.8 MICROCHIP 25xx640_TSSOP ATMEL AT25160_1.8 CATALYST...
  • Page 13 Chip Type Name Chip Type Name M95512 MICROCHIP 93C06 MICROCHIP 25xx040 NATIONAL NM93C13 NATIONAL NM93C14 NATIONAL NM93CS06 NATIONAL NM93C14TM8 NATIONAL NM93CS46 MICROCHIP 93C46X NATIONAL NM93CS56 MICROCHIP 93C46A NATIONAL NM93CS66 MICROCHIP 93C46 FAIRCHILD FM93CS46T MICROCHIP 93C46AX M93C46 MICROCHIP 93C46BX_93C46CX M93C56 MICROCHIP 93C56A M93C66 MICROCHIP...
  • Page 14 Chip Type Name Chip Type Name ATMEL AT93C76 TMC93LC86 ATMEL AT93C86 SONY CXK1011 SONY CXK1012 Seiko S_24S45 SONY CXK1013 TOSHIBA TC89101 Seiko S_24H30 TOSHIBA TC89102 Seiko S_24H30_SOP8 TOSHIBA TC89121 Seiko S_24H45 TOSHIBA TC89122 Seiko S_24H45_SOP8 Xicor X24C44 Seiko S_24S30 9S12 Read/Write Supported Types Chip Type Name FREESCALE...

  • Page 15: Product Troubleshooting

    Product Troubleshooting This part describes problems that you may encounter while using the XP201. Vehicle Linking Error A communication error occurs if the XP201 fails to communicate with the diagnostic tools. Please do the following check-ups:  Verify that the diagnostic tool authorization is approved. ...

  • Page 16: Update

    Update Software Update This part describes two ways to update the driver and the software of the XP201. Update via MaxiSys Display Tablet This function allows you to update the XP201 software via MaxiSys Display Tablet. Connect the XP201 to MaxiSys Display Tablet via USB cable. Verify the power LED light on the front panel illuminates solid green.
  • Page 17 Figure 4-1 Sample Firmware Update Screen The update agent will automatically check for available update online. Press Next to install the newest firmware. Press Cancel to exit.

  • Page 18: Compliance Information

    Compliance Information FCC COMPLIANCE FCC ID: WQ8MXPRGXP201 This device complies with Part 15 of the FCC rules Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 19 used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna.

  • Page 20: Warranty And Service

    Limited One Year Warranty Autel Intelligent Technology Corp., Ltd. (the Company) warrants the original retail purchaser of this MaxiProgrammer 201 that should this product or any part thereof during normal usage and under normal conditions be proven defective in material or workmanship and results...

  • Page 21: Service Information

    Service Information If you have any questions, please contact your local distributor or visit our website at www.auteltech.com. If it becomes necessary to return the tool for repair, please download and fill the Technical Support Form from www.auteltech.com, or contact your local distributor for more information. Other Services Accessories can be purchased from Auteltech authorized suppliers and your local distributors.
