- Page 1 LeadingLEDApplications CR Series UserManual TUV-CE CrystalView 16:9HD&4K Powerand SimpleRear technology pixel-to-pixel Receivingcard Maintenance resolution redundancy...
-
Page 2: Table Of Contents
Leading Applications Table of Contents 02-03 Safety Information 1、Product Introduction 1.1ProductMainFeatures 1.2ProductSpecifications 1.2.1ProductParameter 1.2.2CabinetDimensionDrawing 1.2.3ModuleDimensionDrawing 2、Product Components 2.1CabinetIntroduction 08-10 2.2ProductStructure/ElectronicComponentsDetails 3、Product Installation 11-12 4、Product Cabling 4.1PowerCabling 15-16 4.2DataCabling 5、Maintenance 5.1PreparationTools 5.2Maintenance 5.3TestforShortCircuit CR SeriesUserManual - 01 -... -
Page 3: Safety Information
Follow safety instructions in this manual and on the product. If you have any questions, please seek help from Absen. Beware of Electric Shock! • To prevent electric shock the device must be properly grounded during installation.Do not ignore using the grounding plug, or else there is a risk of electric shock. - Page 4 Leading Applications Beware of Fire! • Use a circuit breaker or fuse protection to avoid fire caused by power supply cables overloading. • Maintain good ventilation around the display screen, controller, power supply and other devices, and keep a minimum 0.1 meter gap with other objects. •...
-
Page 5: 1、Product Introduction
Applications 1. Product Introduction CR series products are indoor fixed and high-definition display line, specially designed for control rooms. The dimension of its cabinet is 610mm*343mm (precise cabinet dimension is 609.92mmx343.08mm). Each cabinet features a 27.5 inches diagonal with a 16:9 ratio, a 2*2 cabinet layout will make a perfect seamless 55 inch display, which can be used to replace a traditional LCD video wall with bezels. -
Page 6: ProductMainFeatures
Applications 1.1 Product Main Features • CR series products features integrated die-cast cabinets using aluminum alloy, actualizing precision with great screen surface flatness, enhanced heat dissipation and strengthened structural integrity. • With 16:9 27.5’’ diagonal cabinet design, any 16:9 FHD/4K pixel to pixel screen can be easily assembled. Achieving a FHD display is as simple as assembling a [4*4] CR1.2 (110’’... -
Page 7: ProductSpecifications
Leading Applications 1.2 Product Specifications 1.2.1 Product Parameter Parameters CR1.9 CR1.5 CR1.4 CR1.2 BLACK SMD1010 BLACK SMD1010 BLACK SMD1010 BLACK SMD1010 LED Type Pixel Pitch (mm) 1.906 1.58 1.46 1.27 Panel Dimensions 610×343×67 610×343×67 610×343×67 610×343×67 (WxHxD)/(mm) Physical 320×180 384×216 416×234 480×270 Pixel per Panel... -
Page 8: CabinetDimensionDrawing
Leading Applications 1.2.2 Cabinet Dimension Drawing 1.2.3 Module Dimension Drawing CR SeriesUserManual - 07 -... -
Page 9: 2、Product Components
Leading Applications 2. Product Components 2.1 Product Specifications Screw Handle DATA2 Poweroutput Dowelpin Righthandle Screwholes DATA1 Powerinput Lefthandle Testbuttonandindicatorlight 2.2 Product Elements 2.2.1Datacableforverticalconnectionsinbetweenthecabinets,0.5mlong. 2.2.2Datacableforhorizontalconnectionsinbetweenthecabinets,0.8mlong. CR SeriesUserManual - 08 -... - Page 10 Leading Applications 2.2.3Powercableforverticalconnection,lengthis0.25m: 2.2.4Powercableforhorizontalconnection,lengthis0.8m: 2.2.5Maindatacablefromscreentotheprocessor,lengthis30m; 2.2.6Mainpowercable,lengthis10m: Notes:MainPowercableissuitableforplugsorterminals. 2.2.7Standardpackage:cartonboxforeachcabinet,packagedsize:710x440x150mm(L*W*H), weight:about7kg CR SeriesUserManual - 09 -...
- Page 11 Leading Applications 2.2.8Connectorandboltforinstallation. Structureconnector M8x120full-lengththreadedbolt 105mm 16mm Threadedhole foradjustingZAxis Threadedhole forfixingcabinet Holeforfixing structureconnector Modulescrewhole Connectorbetweencabinets 49.5mm 105mm Verticalconnectorforthecabinets Horizontalconnectorforthecabinets CR SeriesUserManual - 10 -...
-
Page 12: 3、Product Installation
Applications 3. Product Installation This CR series products are suitable for fixed installation on steel frame, like the figure shows below. Suggested Installation Procedure: Installing the first two lines of cabinets at the bottom of the steel frame, then install cabinets layer by layer to top. - Page 13 Leading Applications SteelStructureConnector M8X120full-lengththreadedbolt Notes:Duringtheinstallation,theZ-Axisadjustmentboardisdesignedforadjustingthepositionofthe cabinets. CR SeriesUserManual - 12 -...
-
Page 14: 4、Product Cabling
Leading Applications 4. Product Cabling · Preparation before wiring Before supplying power and signal source to the screen, please check power and data cables connections carefully and make sure they are wired correctly. Use a multimeter to test the L, N and PE lines in AC power input port and make sure the tree lines are not short-circuited. -
Page 15: PowerCabling
Leading Applications Poweroutput Pilotlamp Testbutton Powerinput Using4x4CR1.5setupasanexample,seebelowfordataandpowercablingmethods. 4.1 Power Cabling 16 CR1.5 has a max power consumption of 16 x 0.61 x 0.343 x 520W=1.7kW. Connect the cabinets using the power jumpers, and use the main power cables to power each circuit. Note: a main power run will carry a maximum of 16 cabinets per 220V circuit, and 8 cabinets per 110V circuit. - Page 16 Leading Applications 4.2 Signal Cabling The product uses RJ45 CAT5 data interface with no designated input and output ports. The cabinets are cascaded in the form of “S” using data jumper cables. Calculate total pixel load based on the resolution of the screen, and cable the screen accordingly.
- Page 17 Leading Applications 4.2.2 Cabling for double-receiving-card version As for this version, route A is for DATA1, route B is for DATA2. DATA1 and DATA2 both have two identical RJ45 ports. Sengdingbox HDMI RJ45signalline Computer CR SeriesUserManual - 16 -...
-
Page 18: PreparationTools
Leading Applications Leading Applications 5. Maintenance 5.1 Preparation Tools Preparation tools: Multi-meter, Module front service tools, Screwdriver, etc. 5.2 Rear Maintenance Remove the back cover and HUB board from the back side of the cabinet to access the PCB board as the modules can be accessed from the front. - Page 19 V1.0 Aug. 2017 All rights reserved by Shenzhen Absen Optoelectronic Co., Ltd. Shenzhen Absen Optoelectronic Co., Ltd. reserves the rights to modify contents without any further notice.
