- Page 1 AX series User Manual STEP Simple Operation Panel Weight Cooling System Fast Assembly High Brightness Front Servicing High Refre...
-
Page 2: Table Of Contents
Table of content Safety Information Product Introduction About AX series Product Specifications Basic Wiring Overview for Hanging Installation and Stacking Installation Locking System Product Assembly Hanging Bar/Rigging Bar Service and Maintenance Accessories Flight Cases... -
Page 3: Safety Information
Please read this manual carefully before installing, powering up, operating and maintenance of this product. Follow safety instructions in this manual and on the product. If you have any questions, please seek help from Absen. - Page 4 Beware of Electric Shock! To prevent electric shock the device must be properly grounded during installation. Do not ignore using the grounding plug, or else there is a risk of electric shock. During a lightning storm, please disconnect the device’s power supply, or provide other suitable lightning protection.
- Page 5 Beware of Injury! ⚫ Warning: Wear a helmet to avoid injury. ⚫ Ensure any structures used to support, fix and connect the equipment, can withstand at least 10 times the weight of all the equipment. ⚫ When stacking products, please hold products firmly to prevent tipping or falling.
-
Page 6: Product Introduction
The product has a 1.58mm and 1.27mm pixel pitch, and is high-definition display for indoor rental use. The AX series uses die-cast aluminum structure, and the cabinet design is modern, slim and light. The display has excellent flatness, high quality cabinet and module finish, and high structural strength. - Page 7 Magnetic Locking system Locking system Locking system Power box Protection corner...
-
Page 8: Product Specifications
AX1.5 Product Specifications Parameters Specifications Pixels IMD 4 in 1 1.58 Pixel Pitch (mm) 1.58 Cabinet Pixels 384×216 Pixel Density (Pixels / m 396424 Physical Parameters Module size (L × W × H)/(mm) 152.5×343 Module size (L × W × H)/(mm) 610×343×80 Cabinet Material Die-cast Aluminum... - Page 9 Leasing Cabinet Installation Method hanging, stacking Product Maximum number of hoisted cabinets Installation AX1.2 Product Specifications Parameters Specifications Pixels IMD 4 in 1 1.27 Pixel Pitch (mm) 1.27 Cabinet Pixels 480×270 Pixel Density (Pixels / m 619414 Physical Parameters Module size (L × W × H)/(mm) 152.5×343 Module size (L ×...
-
Page 10: Basic Wiring Overview For Hanging Installation And Stacking Installation
Product Life (hrs) 100000 Leasing Cabinet Installation Method hanging, stacking Product Maximum number of hoisted cabinets Installation 2. Basic Wiring Overview for Hanging Installation and Stacking Installation 12 panels high 6 panels high Notes:... -
Page 11: Locking System
1、Hanging bars can load a max height of 25panels, and the stacking system can load a max of 15panels. 2、At an input voltage of 220V, one power cable can load 12 panels of AX1.5(AX1.2); at an input voltage of 110V, one power cable can load 6 panels of AX1.5(AX1.2). - Page 12 ⚫ Hold the bottom of the Panels upward ⚫ Pull the knob of top lock system to lock the Panels 2.1 Horizontal Locking Procedures Inner and outer curve lock systems Innovative integrated repositionable curve connection block system maintains the highest level of alignment accuracy in both flat of curve configuration. Curve connection blocks are available to support any increment of curve +2.5 degree concave giving users unlimited design flexibility and control.
-
Page 13: Product Assembly
03 Product Assembly 3.1 Procedure Stacking... - Page 14 Hanging Hanging Installation Fix the Hanging Bar on the Truss Turn the adjustment screw to make the clamps close. The hanging bar should be directly affixed to the truss.
- Page 15 Connect and assemble tiles. 3.2 Stacking system...
-
Page 16: Hanging Bar/Rigging Bar
3.2 hanging bar 0.61m hanging bar 1.22m hanging bar... -
Page 17: Service And Maintenance
04 Service and Maintenance Module Front Maintenance 1．Take off the failure module... - Page 18 Step1：Attach the vacuum maintenance tool to the module and press the maintenance tool switch before vacuum for 5 seconds. Pull it vertically and pull the module off the panel. Step 2：Unload the module safety rope and remove the failure module Easy Maintenance for Power Box...
-
Page 19: Accessories
Step1： Push the switch upwards and turn on the power box. Step2： After removing 2 pcs screws,remove the recevied card; Step3: After removing 4 pcs screws,remove the power supply. 05 Accessories... -
Page 20: Flight Cases
Name:Power Cable Name:long Power Cable Name:Display DATA cable Name:Panle DATA cabel Dimension: 1m Dimension: 10m Dimension: 20m Dimension: 1m Max Current :16A Max Current :16A Name: Sending card Box Name:Flight case Name:Front Maintenance Name:base stand Dimension: Dimension: tool Dimension: 0.68m,1.22m W480×H45×D240mm 1036x664x576mm Max Capacity :8 in 1... - Page 21 Flight cases are optimised to fit in vehicles for low cost transport. Fully stackable to save space. 8 in 1 design. All rights reserved by Shenzhen Absen Optoelectronic Co., Ltd. Shenzhen Absen Optoelectronic Co., Ltd. reserves the rights to modify contents without any further notice.
