LeadingLEDApplications N Series User Manual N3/N4/N4W/N5 Slim & Front & Rear High Grayscale Intelligent Monitor Easy Maintenance Fast Installation Light Weight Servicing... -
Page 2: Table Of Contents
Leading Applications Table of Contents 02-03 Safety Information Product Introduction About N Series Product Dimensions Product Specifications Product Value Features Product Components Cabinet Introduction 08-10 Product Structure / Electronic Components Details Product Installation Front Installation / Rear Installation Floor Installation Use Sub-frame for Fast Installation Wall-mounting Solution 13-14... -
Page 3: Safety Information
Follow safety instructions in this manual and on the product. If you have any questions, please seek help from Absen. Beware of Electric Shock! • To prevent electric shock the device must be properly grounded during installation. Do not ignore using the grounding plug, or else there is a risk of electric shock. - Page 4 Leading Applications Beware of Fire! • Use a circuit breaker or fuse protection to avoid fire caused by power supply cables overloading. • To avoid fire caused by power supply cables overloading, do not connect to the same power supply point for more than 8 cabinets(N4W 6 cabinets) at a voltage of 100-120V, or 16 cabinets(N4W 12 cabinets) at a voltage of 200-240V.
-
Page 5: Product Introduction
Product Introduction About N Series N3/N4/N4W/N5 are indoor fixed mounted high-definition display with unique competitive advantages. Designed in a long rectangle shape with full aluminum structure, it looks like a tablet. Its cabinets are light and thin, only 8.8kg/cabinet(N4W 9.2kg), and only 54mm thickness. The thin cabinets are made of aluminum, use magnetic modules, support complete front and rear installation and complete front and rear maintenance, and don’t require a maintenance channel. -
Page 6: Product Dimensions
Leading Applications Product Dimensions 1152mm 54mm L E D Cabinet Dimension 288mm Module Dimension - 05 - N Series User Manual... -
Page 7: Product Specifications
Leading Applications Product Specifications Technical Specifications Pixel Configuration SMD 2121 SMD 2121 SMD 1921 SMD 2121 Pixel Pitch (mm) 5.14 Pixel Matrix per Cabinet 360×90 288×72 288×72 224×56 Module Size (L×W) / (mm) 288×288 288×288 288×288 288×288 Physical Parameters Cabinet Weight (kg) Cabinet Material Aluminum Cabinet Dimension (L×W×H) / (mm) -
Page 8: Product Value Features
• Super large viewing angle, high contrast ratio: 160/140 no dark spots phenomenon. Uses TOP type SMD LED, combined with light trap mask design, ensuring excellent optical effects. • Supports Absen’s 3 Generation Pixel-by-Pixel Correction (A3C) technology, ensuring even images. Different batches produced within one year can be mixed and used together. -
Page 9: Product Components
Leading Applications Product Components Cabinet Introduction Positioning Column Power output Mounting holes Test button Signal Input/Output Indicator Power input Product Structure / Electronic Components Details Product structure consists of two parts: Cabinet and module. Cabinet structure: Full aluminum cabinet is extremely thin and light. Cabinet can be installed either horizon- tally or vertically. - Page 10 Leading Applications Modular structure: Magnetic modules. Relative to the cabinet structure, modules can be rotated by 90 degrees for installation, so that the cabinet can be installed vertically or horizontally. When installed vertically, the module needs to be rotated by 90 degrees, so as not to affect left and right viewing angle. 30.6mm 287.7mm 16.1mm...
- Page 11 Leading Applications Packaging 1218.0mm 4-in-1 Carton Packing Wooden Case Packing Installation-use connecting plates and mounting bolts 100mm 74mm Connecting Plates M8x60 Bolts - 10 - N Series User Manual...
-
Page 12: Product Installation
Leading Applications Product Installation Various installation methods are available for this product: front installation, rear installation, floor installa- tion, using sub-frame for fast installation, as well as wall-mounted installation. Front Installation Remove modules M6X60 bolt fixed from both sides module Front Installation Hole on steel structure Module... -
Page 13: Floor Installation
Leading Applications Floor Installation A floor support stand is required for floor installation, so that cabinets can be mounted onto the support stand. Use Sub-frame for fast installation Front installation hole Rear installation hole Sub-frame When installing, first fix 4 (2 to 4) cabinets onto the sub-frame, and then mount the sub-frame onto the steel structure or wall, to achieve fast installation. -
Page 14: Wall-Mounting Solution
Leading Applications Wall-mounting Solution Wall Wall mounting device Install cabinets onto the sub-frame or fixed structure, and then directly mount the sub-frame onto the wall, to achieve wall-mounting installation. Front Installation Instructions (Wall-mounting) Step 1: Install cabinets onto the sub-frame and splice 2 to 4 cabinets. Number of cabinets is based on actual requirements at installation site. - Page 15 Leading Applications Step 2: Step 3: Take a properly spliced cabinet, remove modules According to the installation positions marked on from four corners, mark installation positions on the the wall, install M10 expansion screws. wall according to the mounting holes on the sub-frame.
-
Page 16: Product Wiring
Leading Applications Product Wiring Power Supply Wiring • Preparation before wiring Before connecting to power supply and switching on control signal to the entire screen, please carefully check the power supply and signal cable connections. Please carefully check the "L" line, "N" line and "PE" of each cabinet’s AC inlet, and ensure there is no short circuit between the three lines (Use multimeter to measure). -
Page 17: Power Cable Wiring
Leading Applications Power Cable Wiring Total power for 8 cabinets with size 1152x288mm each is: 8x1.152x0.288x450w=1.2kw, arranged in 2x4 with 2 cabinet columns, and 4 cabinets for each column connected to power supply in series. In this case use a 3X1.5m power cable to connect from the distribution box or socket to the bottom of the cabinet. -
Page 18: Maintenance
Leading Applications Maintenance Preparation Tools • Tools: front maintenance tools, multimeter, screwdriver etc. Front Maintenance Tools Multimeter Screwdriver - 17 - N Series User Manual... -
Page 19: Module Front & Rear Maintenance
Leading Applications Module Front & Rear Maintenance • Module Front Maintenance • Module Rear Maintenance Back cover screws Check for Power Supply Short Circuit After completing the cabinet wiring, please use a multimeter to check if there is any short circuit at the AC input power supply (L / N / PE) and DC output terminal (VCC / GND). - Page 20 V2.0 Nov. 2015 All rights reserved by Shenzhen Absen Optoelectronic Co., Ltd. Shenzhen Absen Optoelectronic Co., Ltd. reserves the rights to modify contents without any further notice. Shenzhen Absen Optoelectronic Co., Ltd. Absen American Inc. Absen GmbH Absen Building, Huawei Industrial Park, Bantian,...
