- Page 1 AX series User Manual High refresh 4 in 1 16:9 Pixel to pixel 4K High contrast ratio...
- Page 2 4 Service and Maintenance ....................- 14 - Module Front Maintenance ..................... - 14 - Easy Maintenance for Power Box ................. - 14 - 5 Accessories ..........................- 15 - 6Flight Case ..........................- 16 - - 2 - AX series User Manual...
- Page 3 Please read this manual carefully before installing, powering up, operating and maintenance of this product. Follow safety instructions in this manual and on the product. If you have any questions, please seek help from Absen. Beware of Electric Shock! • To prevent electric shock the device must be properly grounded during installation. Do ignore using the grounding plug, or else there is a risk of electric shock.
- Page 4 • Any component that has a recycling bin label can be recycled. • For more information on collecting, reusing and recycling, please contact the local or regional waste management unit. • Please contact us directly for detailed environmental performance information. - 4 - AX series User Manual...
- Page 5 1 Product Introduction Product Info AX series display is a product specially designed for stage rental use. It is mainly used in rental applications for auto show, TV studio, large concerts, business activities, etc., as a medium for video broadcast, information release, and so on.
- Page 6 IP40/IP21 IP40/IP21 IP40/IP21 Product Life (hrs) 100000 100000 100000 Leasing Panel Installation Method Hanging/Stacking Hanging/Stacking Hanging/Stacking Product Maximum number of Installation hoisted cabinets Remark: Power consumption tolerance: ±15%, according to the actual situation. - 6 - AX series User Manual...
- Page 7 Basic Wiring Overview for Hanging Installation and Stacking Installation Built in Power Supply Input VoltageAC 220V P-3x2.5mm² Built in Power Supply Input Voltage AC 220V - 7 - AX series User Manual...
- Page 8 Auto-Ejection Side Lock System Enables Super Fast, East and Convenient Disconnection of Panels. Take out the panel from the flight case Pressing the four corners “push” of the box Auto Retracing corner protector - 8 - AX series User Manual...
- Page 9 Innovative integrated repositionable curve connection block system maintains the highest level of alignment accuracy in both flat of curve configuration. Curve connection blocks are available to support any increment of curve +2.5 degree concave giving users unlimited design flexibility and control. - 9 - AX series User Manual...
- Page 10 3 Product Assemble Procedure Stacking - 10 - AX series User Manual...
- Page 11 Hanging Hanging installation Fix the Hanging Bar on the Truss Turn the adjust screw to make the clamps close. The hanging bar should be directly affixed to the truss. - 11 - AX series User Manual...
- Page 12 Connect and assemble tiles. Stacking system - 12 - AX series User Manual...
- Page 13 Hanging bar 0.61m hanging bar 1.2mm hanging bar - 13 - AX series User Manual...
- Page 14 Easy Maintenance for Power Box Step1: Push the switch upwards and turn on the power box. Step2: After removing 2pcs screws, remove the received card. Step3: After removing 4pcs screws, remove the power supply. - 14 - AX series User Manual...
- Page 15 Box Dimension: Dimension: 1036x664x576mm Maintenance tool W480×H45×D240mm 0.68m,1.22m Max Capacity :8 in 1 Name: Adjustable Beam Name:ladder Name: Outrigger Name: Clamp between Connector-Different Dimension: Dimension: 0.8m the tile and the ladder Dimension: 0.9~1.3M 0.686m,0.43m - 15 - AX series User Manual...
- Page 16 Flight cases are optimized to fit in vehicles for low cost transport. Fully stackable to save space. 8 in 1 design. All right reserved by Shenzhen Absen Optoelectronic Co., Ltd. Shenzhen Absen Optoelectronic Co., Ltd. Reserves the lights to modify contents without any further notice. - 16 - AX series...
