- Page 1 JP Series User Manual STEP Simple Operation Panel Weight Cooling System Fast Assembly High Brightness Front Servicing High Refresh...
-
Page 2: Table Of Contents
Catalogue Safety Information Product Introduction About JP Series Product Specifications Basic Wiring Overview for Hanging Installation Locking System Product Assembly Hanging bar Service and Maintenance Accessories Flight Cases... -
Page 3: Safety Information
This product may result in serious injury or death due to fire hazard, electric shock or on dropping. Please read this manual carefully before installing, powering up, operating and maintenance of this product. Follow safety instructions in this manual and on the product. If you have any questions, please seek help from Absen. - Page 4 Beware of Electric Shock! ⚫ To prevent electric shock the device must be properly grounded during installation. Do not ignore using the grounding plug, or else there is a risk of electric shock. ⚫ During a lightning storm, please disconnect the device’s power supply, or provide other suitable lightning protection.
- Page 5 Beware of Injury! ⚫ Warning: Wear a helmet to avoid injury. ⚫ Ensure any structures used to support, fix and connect the equipment, can withstand at least 10 times the weight of all the equipment. ⚫ When stacking products, please hold products firmly to prevent tipping or falling.
-
Page 6: Product Introduction
Product Introduction About JP Series JP series products are designed for stage display. It is mainly used in rental applications for festival and vocal concert, as a medium for video broadcast, result of exhibition and so on. JP series includes JP6.25, JP8.33 and JP9.3. The JP series uses aluminum profile + die-casting aluminum structure and the LED curtain with more than 35% transparency, greatly reducing wind resistance and better cooling effect. - Page 7 JP6.25 Locating pin Up-down lock Left-right lock Power box JP8.33 Arc lock Up-down lock Power in Date in Power box Left-right lock Date out Power out...
-
Page 8: Product Specifications
Product Specifications Parameters JP6.25 JP8.33 JP9.37 Pixels SMD1515 SMD1921 SMD1515 Pixel Pitch (mm) 6.25 8.33 9.37 Cabinet Pixels 96×96 60×60 64×128 Pixel Density (Pixels / m 25600 7200 11377 Physical Module size (L × W)/(mm) 600×200 500×125 600×150 Parameters 600×600×100 Panel size (L ×... -
Page 9: Basic Wiring Overview For Hanging Installation
1、Hanging bars can load a max height of 16 panels. 2、At an input voltage of 220V, one power cable can load 16 panels of JP series ; at an input voltage of 110V, one power cable can load 8 panels of JP series. -
Page 10: Locking System
Locking System Horizontal Locking Procedures... - Page 11 Vertical Locking Procedures...
-
Page 12: Product Assembly
Product Assembly Procedure Hanging Hanging Installation Fix the Hanging Bar on the Truss Turn the adjustment screw to make the clamps close. The hanging bar should be directly affixed to the truss. -
Page 13: Hanging Bar
Connect and assemble tiles. Hanging bar 0.5m hanging bar... - Page 14 1m hanging bar...
-
Page 15: Service And Maintenance
Service and Maintenance Module Front Maintenance Step1: Loosen the screws used for fixing module with a cross screwdriver Step2: Replace a good module Easy Maintenance for Power Box Step1: Loosen the fixed bolts from the power Step2: Remove the power box and maintain it... -
Page 16: Accessories
Accessories Name:Power Cable Name:long Power Cable Name:Display DATA cable Name:Panle DATA cabel Dimension: 1m Dimension: 10m Dimension: 20m Dimension: 1m Max Current :16A Max Current :16A Name: Sending card Box Name:Flight case Name:Front Maintenance Name:base stand Dimension: Max Capacity :12 in 1 tool Dimension: 0.5M,1M W480×H45×D240mm... -
Page 17: Flight Cases
Flight case LED panels stored horizontally to prevent SMD damage. Flight cases are optimised to fit in vehicles for low cost transport. Fully stackable to save space. 12 in 1 design. - Page 18 All rights reserved by Shenzhen Absen Optoelectronic Co., Ltd. Shenzhen Absen Optoelectronic Co., Ltd. reserves the rights to modify contents without any further notice. Shenzhen Absen Optoelectronic Co., Ltd. 18-20F Building 3A, Cloud Park, Bantian, Longgang District, Shenzhen 518129, P.R.China T: +86-755-89747399 absen@absen.com...
