7.2.

Extended parameters

Par. Description
Digital input
P-15
function select
P-16 Analog input format
Effective switching
P-17
frequency
User relay output
P-18
select
User relay output
P-19
limit
P-20 Preset speed 1
P-21 Preset speed 2
P-22 Preset speed 3
P-23 Preset speed 4
2nd decel ramp
P-24 time
(Fast Stop)
Analog output
P-25
function select
Skip frequency
P-26
hysteresis band
P-27 Skip frequency
V/F characteristic
P-28
adjustment voltage
V/F characteristic
P-29
frequency adjust
Terminal mode
P-30
restart function
12
Range
0 to 12
0..10V, b 0..10V, 0..20mA,
t 4..20mA, r 4..20mA,
t 20..4mA r 20..4mA
4 .. 32kHz
0 : Drive enabled
1 : Drive healthy
2 : Motor at target speed
3 : Drive tripped
4 : Motor speed >= limit
5 : Motor current >= limit
6 : Motor speed < limit
7 : Motor current < limit
0.0 to 100% for speed
0.0 to 200% for current
0 to P-01
0 to P-01
0 to P-01
0 to P-01
0...25.0s
Digital output mode
0 : Drive enabled
1 : Drive healthy
2 : Motor at target speed
3 : Drive tripped
4 : Motor speed >= limit
5 : Motor current >= limit
6 : Motor speed < limit
7 : Motor current < limit
Analog output mode
8 : Motor speed
9 : Motor current
0 to P-01
P-02 to P-01
0 ... P-07
0 ... P-09
EdgE-r, Auto-0 .. Auto-5
www.invertek.co.uk
Default Explanation
Defines the function of the digital inputs
depending on the control mode setting in P-12.
0
See section 8 Analog and Digital Input
Configurations for more information.
Configures the voltage or current format of the
analog input signal.
"t" indicates the drive will trip if signal removed
0..10V
when drive is enabled.
"r" indicates the drive will ramp to Preset Speed
1 if signal is removed when drive is enabled
Sets maximum effective switching frequency of
the drive. If "rEd" is displayed, the switching
8 / 16kHz
frequency has been reduced to the level in P00-
14 due to excessive drive heatsink temperature.
Defines the function of the user relay, when the
operating conditions are met.
Disabled : Contacts open
Enabled : Contacts closed
1
Options 4 to 7: the Relay output is enabled
using the level set in P-19
100% Sets the limit for P-18 & P-25
0 Hz Sets jog / preset speed 1
0 Hz Sets jog / preset speed 2
0 Hz Sets jog / preset speed 3
0 Hz Sets jog / preset speed 4
2nd Deceleration ramp time from base speed
(P-09) to standstill in seconds.
0 Selected using fast stop function via digital
input setting or on mains loss as set by P-05
If set to zero drive will coast to STOP.
Digital Output Mode
Options 0 to 7 select a digital voltage output
signal
Disabled : 0V
Enabled : +24V, (20mA limit)
Options 4 to 7 : the Digital output is enabled
8
using the level set in P-19
Analog Output Mode
Option 8 : Motor Speed signal range
0..10V = 0..100% of P-01
Option 9 : Motor Current signal range
0..10V = 0..200% of P-08
Set P-09 before adjusting.
Speed reference held at upper or lower skip
frequency limit until input signal reaches the
0 Hz
opposite skip frequency limit. Speed ramps
through the skip frequency band at a rate set
by P-03 and P-04.
Set P-09 before adjusting.
0 Hz
Skip frequency centre point
Adjusts the applied motor voltage to this value
0
at the frequency set in P-29
Sets the frequency at which the adjustment
0.0Hz
voltage set in P-28 is applied
Edge-r : if drive is powered up with Digital Input
1 closed (enabled), drive will not run. The
switch must be opened & closed after power up
or after clearing a trip for the drive to run.
Auto-0 : drive will run whenever digital input 1
is closed (if not tripped).
Auto-0
Auto-1..5 : drive will make 1..5 attempts to
automatically restart after a trip (25s between
attempts). If fault has cleared drive will restart.
To reset the counter the Drive must be
powered down, reset on the keypad or by re-
enabling the drive.
