7. Parameters

7.1.

Standard parameters

Par. Description
P-01 Maximum speed
P-02 Minimum speed
Acceleration ramp
P-03
time
Deceleration ramp
P-04
time
P-05 Stop mode select
P-06 Reserved
P-07 Motor rated voltage
P-08 Motor rated current
Motor rated
P-09
frequency
P-10 Motor rated speed
P-11 Boost start voltage
Terminal / Keypad /
MODBUS / PI
P-12
Drive Control Mode
Selection
P-13 Trip log
Extended menu
P-14
access
NOTE Default parameter values for Horse Power rated drives are shown in brackets
Optidrive E2 Single Phase Output User Guide
Range
P-02 to 5*P-09 (max 120Hz)
5 to P-01 (max 120Hz)
0 to 600s
0 to 600s
0 : Ramp stop
(brown-out ride-through)
1 : Coast to stop
2 : Ramp to stop (fast stop)
Reserved
0, 20V to 150V
0, 20V to 250V
25% -100% of drive rated
current
25Hz to 120Hz
0 to 30 000 rpm
0.0 to 100% of max output
voltage.
0.Terminal control
1, 2 Keypad control – fwd only
3. MODBUS network control
with internal accel / decel
ramps
4. MODBUS network control
with accel / decel ramp
adjustment
5. User PI control
6. User PI control with analog
input 1 summation
Last four trips stored
Code 0 to 9 999
www.invertek.co.uk
Default Explanation
50Hz
Maximum speed limit – Hz or rpm. See P-10
(60Hz)
35Hz Minimum speed limit – Hz or rpm. See P-10
Acceleration ramp time from 0 to base speed
5s
(P-09) in seconds
Deceleration ramp time from base speed (P-09)
to standstill in seconds. When set to zero,
5s
fastest possible ramp time without trip is
activated
If the supply is lost and P-05=0 then the drive
will try to continue running by reducing the
speed of the load using the load as a generator.
1
If P-05 = 2, the drive will ramp to stop using the
P-24 decel ramp with dynamic brake control
when mains supply lost.
0 Reserved
115V Rated (nameplate) voltage of the motor (Volts).
230V Setting to zero disables voltage compensation
Drive
Rated (nameplate) current of the motor (Amps).
rating
50Hz
Rated (nameplate) frequency of the motor.
(60Hz)
When non-zero, all speed related parameters
0
are displayed in rpm
Percentage of rated motor voltage applied at
the start of the boost period (P-33). The
applied voltage increases from this level to
3%
rated voltage over the boost period. The
frequency during the applied boost period is
fixed at the motor rated frequency (P-09).
Primary Control Mode of the drive.
0. Terminal control
1,2 Uni-directional keypad control. Keypad
START button does not reverse direction.
3. Control via Modbus RTU (RS485) comms
interface using the internal accel / decel ramps
0
4. Control via Modbus RTU (RS485) comms
interface with accel / decel ramps updated via
Modbus
5. User PI control with external feedback signal
6. User PI control with external feedback signal
and summation with analog input 1
Previous 4 trips stored in order of occurrence,
with the most recent first.
Press UP or DOWN to step through all four.
Read only The most recent trip is always displayed first.
UV trip is only stored once.
Further fault event logging functions are
available through parameter group zero.
Set to "101" (default) for extended menu
access.
0
Change code in P-39 to prevent unauthorised
access to the Extended Parameter Set
11
