8 OPERATE
Parameters

Standard Parameters

Par. Description
P-01 Maximum Frequency/Speed Limit
P-02 Minimum Frequency/Speed Limit
P-03 Acceleration Ramp Time
P-04 Deceleration Ramp Time
P-05 Stopping Mode/Mains Loss Response
Setting On Disable
0 Ramp to Stop (P-04)
1 Coast
2 Ramp to Stop (P-04)
3 Ramp to Stop (P-04) with AC Flux Braking
4 Ramp to Stop (P-04)
P-06 Energy Optimiser
Setting Motor Energy Optimisation
0 Disabled
1 Enabled
2 Disabled
3 Enabled
P-07 Motor Rated Voltage/Back EMF at rated speed (PM/BLDC)
P-08 Motor Rated Current
P-09 Motor Rated Frequency
P-10 Motor Rated Speed
P-11 Low Frequency Torque Boost
P-12 Primary Command Source
0: Terminal Control
1: Uni-directional Keypad Control
2: Bi-directional Keypad Control
3: Modbus Network Control
4: Modbus Network Control
NOTE When P-12 = 1, 2, 3, 4, 7, 8 or 9, an enable signal must still be provided at the control terminals, digital input 1.
P-13 Operating Mode Select
0: Industrial Mode
Setting Appli-
cation
0 General
1 Pump
2
P-14 Extended Menu Access code
1: Pump Mode 2: Fan Mode
Current Limit
(P-54)
150%
1 10%
Fan 1 10%
On Mains Loss
Ride Through (Recover energy from load to maintain operation)
Coast
Fast Ramp to Stop (P-24), Coast if P-24 = 0
Fast Ramp to Stop (P-24), Coast if P-24 = 0
No action
Optidrive Energy Optimisation
Disabled
Disabled
Enabled
Enabled
Torque Spin Start
Characteristic (P-33)
Constant 0: Off
Variable 0: Off
Variable 2: On
Min Max
P-02 500.0 50.0 (60.0) Hz/RPM
0.0 P-01
0.00 600.0
0.00 600.0
0 4
0 3
0 250/ 500 230/400
Drive Rating Dependent
10 500
0 30000
0.0 Drive Dependent
0 9
5: PI Control
6: PI Analog Summation Control
7: CAN Control
8: CAN Control
9: Slave Mode
0 2
Thermal Overload Limit
Reaction (P-60 Index 2)
0: Trip
1: Current Limit Reduction
1: Current Limit Reduction
0 65535
Default Units
0.0 Hz/RPM
5.0 s
5.0 s
0 -
0 -
V
A
50 (60) Hz
0 RPM
%
0 -
0 -
0 -
