Single DP-1

Menu Overview

Main Menu Options

1. DMX Addressing

01) Press the MENU button until the display shows
02) Press the UP/DOWN buttons to choose the desired DMX address.
03) The adjustment range is between
04) Press and hold down the UP/DOWN buttons for fast DMX address selection.
05) The currently selected DMX address will be automatically saved.

2. Dimmer/Switch

01) Press the MENU button until the display shows
02) Press the UP/DOWN buttons to choose between
03) If set to , then the device is a dimmer.
04) If set to , then the device is a switch.
05) In the switch mode
06) If set to , you can switch on the connected light fixture.
07) If set to , you can switch off the connected light fixture.

3. Dimmer Limit

01) Press the MENU button until the display shows
02) Press the UP/DOWN buttons to set the desired maximum dimming limit value. The adjustment range is
between

4. Dimmer Preset

01) Press the MENU button until the display shows
02) Press the UP/DOWN buttons to set the desired dimmer value. The adjustment range is between

5. Power not Stable (AC-0)

01) If the power frequency is not stable, the display will show
device to a stable power source or wait until the power becomes stable at the currently used outlet.
Ordercode: 50396
1. DMX Addressing
2. Dimmer/Switch
3. Dimmer Limit
4. Dimmer Preset
you can choose between
.
, from dark to brightest.
.
.
.
and .
and
.
.
. You will have to connect the
8
.
