Summary of Contents for SHOWTEC DB-1-4/RDM
- Page 1 MANUAL ENGLISH DB-1-4/RDM Ordercode: 50785 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
DB-1-4/RDM Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Connection with the mains............................4 Return Procedure ................................5 Claims ....................................5 Description of the device ..............................6 Frontside..................................6 Backside ..................................6 Installation ................................... 6 Set Up and Operation ............................... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec DB-1-4/RDM ● IEC power cable (1,5 m) ●... - Page 4 If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service. For adult use only. The device must be installed out of the reach of children. Never leave the unit running unattended.
-
Page 5: Operating Determinations
DB-1-4/RDM Operating Determinations ● This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light output and the illuminated surface must be bigger than 0.5 meter. -
Page 6: Return Procedure
DB-1-4/RDM Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 7: Description Of The Device
08) IEC connecter + fuse F0,5A/250V 09) M10 clamp thread Installation Remove all packing materials from the DB-1-4/RDM. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. -
Page 8: Set Up And Operation
DB-1-4/RDM Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. -
Page 9: Fixture Linking
DB-1-4/RDM Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support. -
Page 10: Maintenance
04) If all of the above appears to be O.K., plug the unit in again. 05) If you are unable to determine the cause of the problem, do not open the DB-1-4/RDM, as this may damage the unit and the warranty will become void. - Page 11 DB-1-4/RDM Problem Probable cause(s) Solution No power to the fixture • Check if power is switched on and One or more cables are plugged in fixtures do not function at all Primary fuse blown • Replace fuse Fixtures reset The controller is not connected.
-
Page 12: Product Specifications
DB-1-4/RDM Product Specifications Model: Showtec DB-1-4/RDM Input voltage: 100-240V AC, 50/60Hz Power consumption: Fuse: F0,5A/250V Output: 4 DMX channels Control protocols: DMX-512 Connections: IEC-connecter, 3-pin/5-pin DMX IN, 3-pin/5-pin DMX THROUGH, 4 x 3-pin DMX OUT, 4 x 5-pin DMX OUT Housing: Metal &... -
Page 13: Notes
DB-1-4/RDM Notes Ordercode: 50785... - Page 14 DB-1-4/RDM Ordercode: 50785...
- Page 15 DB-1-4/RDM Ordercode: 50785...
- Page 16 ©2017 Showtec...
