- Page 1 MSP 316H 1x2 HDMI Distributor USER MANUAL Article No: RGB-RD-UM-MSP316H E001 Revision No: V1.0...
-
Page 2: Table Of Contents
Chapter 3 Order Codes......................... 11 4.1 Product..........................11 4.2 Other........................... 11 Chapter 4 Support ........................12 4.1 Contact Us.........................12 Chapter 5 Appendix........................13 5.1 Specification........................13 5.2 MSP Garage Installation......................15 5.3 Terms & Definitions......................16 5.4 Revision History........................21 MSP 316H User Manual... -
Page 3: Declarations
30 days after the transfer of risks. In the event of justified notice of compliant, RGBlink can repair the fault or provide a replacement at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the purchase price or cancellation of the contract. -
Page 4: Operators Safety Summary
Normal wear as well as normal maintenance are not subject to the guarantee provided by RGBlink either. The environmental conditions as well as the servicing and maintenance regulations specified in this manual must be complied with by the customer. -
Page 5: Installation Safety Summary
The AC Socket-outlet should be installed near the equipment and be easily accessible. Unpacking and Inspection Before opening MSP 316H processor shipping box, inspect it for damage. If you find any damage, notify the shipping carrier immediately for all claims adjustments. As you open the box, compare its contents against the packing slip. -
Page 6: Chapter 1 Your Product
Chapter 1 Your Product 1.1 In the Box Power Cord 1×Power Adapter (USB-DC) Note: Power Adapter supplied as standard according to destination market. MSP 316H User Manual... -
Page 7: Product Overview
● Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio ● Built-in equalizer, retiming and driver ● Smart EDID, STD(1080p) mode and TV(copy OUT1) mode ● Compact design for an easy and flexible installation MSP 316H System Connection Diagram MSP 316H User Manual... -
Page 8: Front Panel
TV/display/monitor. 1080p@60Hz and the audio output at LPCM 2CH Stereo. When in 'TV' mode, the unit will read the EDID settings of the display device connected to HDMI OUT 1. MSP 316H User Manual... -
Page 9: Back Panel
DVD player or set-top box with an HDMI cable. DC 5V, Plug the 5V DC power supply into the unit and connected the adapter to an AC outlet. MSP 316H User Manual... -
Page 10: Dimension
1.2.3 Dimension Following is the dimension of MSP 316H for your reference: MSP 316H User Manual... -
Page 11: Chapter 2 Use Your Product
2.1 Operation Steps 1. Connect HDMI port of bluray player or PC to “HDMI IN” on MSP 316H and connect “HDMI Out1” and “HDMI OUT 2” on MSP 316H to HDMI port on HD Display or projector by premium HDMI cable. -
Page 12: Chapter 3 Order Codes
Chapter 3 Order Codes 4.1 Product 621-0316-01-1 MSP 316H 4.2 Other 920-0005-01-0 MSP Garage with PSU MSP 316H User Manual... -
Page 13: Chapter 4 Support
Chapter 4 Support 4.1 Contact Us MSP 316H User Manual... -
Page 14: Chapter 5 Appendix
LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio Audio Format General Input Voltage DC 5V Working 0°C ~ 40°C / 32°F ~ 104°F Temperature Storage -20°C ~ 60°C / -4°F ~ 140°F Temperature Humidity 20 - 95% MSP 316H User Manual... - Page 15 Weight Nett 0.17kg Packaged 0.47kg Dimensions Nett 102mm×58mm×23mm Packaged 160mm×120mm×80mm MSP 316H User Manual...
-
Page 16: Msp Garage Installation
5. Connect the small converters to the devices with the specific cables. 6. Plug in the power cord (AC 85~264V IEC-3 port), and push the power switch to the ON position, the device will enter normal working. MSP 316H User Manual... -
Page 17: Terms & Definitions
This serves as a color synchronizing signal to establish a frequency and phase reference for the chroma signal. Color burst is 3.58 MHz for NTSC and 4.43 MHz for PAL. MSP 316H User Manual... - Page 18 10 bit depth and 4:2:2 color quantization over a single coaxial cable with a data rate of 1.485 Gbit/second. Multiple video resolutions exists including progressive 1280x720 and interlaced 1920x1080 resolution. Up to 32 audio signals are carried in the ancillary data. MSP 316H User Manual...
- Page 19 RS-232 is a serial control standard with a set number of conductors, data rate, word length, and type of connector to be used. The standard specifies component connection standards with MSP 316H User Manual...
- Page 20 Up to 127 external computer devices may be added through a USB hub, which may be conveniently located in a keyboard or monitor. USB devices can MSP 316H User Manual...
- Page 21 4. It has a pixel by line resolution of 640×480 with a color palette of 16 bits and 256,000 colors. “YCrCb”: Used to describe the color space for interlaced component video. “YPbPr”: Used to describe the color space for progressive-scan (non-interlaced) component video. MSP 316H User Manual...
-
Page 22: Revision History
Release Fanny All information herein is Xiamen RGBlink Science & Technology Co Ltd. excepting noted. RGBlink is a registered trademark of Xiamen RGBlink Science & Technology Co Ltd. While all efforts are made for accuracy at time of printing, we reserve the right to alter otherwise make change without notice.
