STWIN development kit - STEVAL-STWINWFV1
Wi-Fi expansion for the SensorTile Wireless Industrial Node (STWIN) kit
The STEVAL-STWINWFV1 expansion board adds 2.4 GHz Wi-Fi connectivity to the STEVAL-STWINKT1B.
Application examples that take advantage of this expansion board can be found also in STSW-STWINKT01 firmware
package as well as in the FP-IND-PREDMNT1 and FP-AI-PREDMNT2 Predictive Maintenance Function Pack.
Key Features
• Wi-Fi adapter for STEVAL-STWINKT1B
• Plugs into STWIN core system board through dedicated 12-pin connector
• Single 3.3 V power supply input
• ISM43362-M3G-L44-E Wi-Fi module:
• 802.11 b/g/n Compatible based on Broadcom MAC/Baseband/Radio device
• Fully contained TCP/IP stack
• Host interface: SPI up to 25 MHz
• Network features ICMP ( Ping), ARP, DHCP,TCP, UDP
• Low power operation (3.3 V supply) with built-in low power modes
• Secure Wi-Fi authentication WEP-128, WPA-PSK (TKIP), WPA2-PSK
• CE, FCC and IC certified
• RoHS and China RoHS compliant
• WEEE compliant
Hardware Overview
Latest info available at www.st.com
STEVAL-STWINWFV1
