FP-AI-PREDMNT2 is not the default firmware on the STEVAL-

STWINKT1B, so it needs to be downloaded on the board by the user.

The easiest way is to use the pre-compiled binary provided in the

package in the folder Projects\STM32L4R9ZI-

STWIN\Applications\PREDMNT2\Binary.

To update the firmware:

• Connect the STWIN core system board to the STLINK-V3MINI

programmer.

• Connect both the boards to a PC using micro USB cables.

• Open

STM32CubeProgrammer, select the proper binary file and

download the firmware.

For further details, see UM2937

Setup & Demo Examples

Firmware update

STLink-V3MINI
