- Page 1 ALLOTMENT Digging Planter Assembly Instructions REF: CP068/DPA - ALLOTMENT DIGGING PLANTER pg 1 of 12...
-
Page 2: Parts Required
(angle cleats/brackets) QTY 4 (47mm x 47mm) QTY 2 (47mm x 47mm) (40mm brass screws) QTY 4 (90mm x 90mm) (80mm brass screws) (120mm brass screws) QTY 2 (Hex board base) pg 2 of 12 REF: CP068/DPA - ALLOTMENT DIGGING PLANTER... -
Page 3: Tools Required
PARTS required QTY 2 DIVIDER ASSEMBLIES (consists of T5 / T6 timbers and 4 angle cleats) TOOLS required pg 3 of 12 REF: CP068/DPA - ALLOTMENT DIGGING PLANTER... -
Page 4: Foundation Details
Foundation Details SOIL TIMBER SUPPORT POST CONCRETE pg 4 of 12 REF: CP068/DPA - ALLOTMENT DIGGING PLANTER... - Page 5 Assembly Instructions Digging Planter to be pre-assembled UP TO STEP Installation on site jump to this step Dividers shown in BLACK above Assembly the first RING Using 4 x T1 timbers pg 5 of 12 REF: CP068/DPA - ALLOTMENT DIGGING PLANTER...
- Page 6 Assembly Instructions Assemble the second ring Using the remaining T1 timbers & T1A timbers The 2 ring are to be positioned as shown below pg 6 of 12 REF: CP068/DPA - ALLOTMENT DIGGING PLANTER...
- Page 7 Screw T2 timbers (floor support) to the lower T1 ring Using 80mm brass screws (5 per T2 timber) One side will be butted up against the adjacent T1 timber Attach the remaining T2 timbers Using 80mm brass screws pg 7 of 12 REF: CP068/DPA - ALLOTMENT DIGGING PLANTER...
- Page 8 Screw T3 timbers to the T2 timbers & T1 lower ring Using 40mm / 120mm brass screws & angle cleats (use 40mm brass screws to attach angle cleats to T3 timbers pg 8 of 12 REF: CP068/DPA - ALLOTMENT DIGGING PLANTER...
- Page 9 Be careful that screws do not ‘cross’ screws used for the T2 support timbers Attach the Assembly with floor & upper ring to the T4 timbers Using 120mm brass screws pg 9 of 12 REF: CP068/DPA - ALLOTMENT DIGGING PLANTER...
- Page 10 - use 4 x 120mm brass screws - Offset screws as shown dashed line shows screws going into the flat side (screws into grooved side sit ‘inside) pg 10 of 12 REF: CP064/BSP - BASIC SANDPIT REF: CP068/DPA - ALLOTMENT DIGGING PLANTER...
- Page 11 Assembly Instructions Main assembly complete Attach the divider Using 40mm brass screws for angle cleats & 120mm brass screws for T5 to T1A timber pg 11 of 12 REF: CP068/DPA - ALLOTMENT DIGGING PLANTER...
- Page 12 Assembly Instructions Repeat for the second divider pg 12 of 12 REF: CP068/DPA - ALLOTMENT DIGGING PLANTER...
