Leviton VerifEye 8000 Series Quick Start Manual
Hide thumbs
Also See for VerifEye 8000 Series:
- User manual (38 pages) ,
- Installation and user manual (35 pages) ,
- Installation manual (14 pages)
Related Manuals for Leviton VerifEye 8000 Series
Summary of Contents for Leviton VerifEye 8000 Series
- Page 1 VerifEye™ Series 8000 Meter Quick Start Guide PK-A3169-10-00-0A Series 8000 Quick Start Guide...
- Page 2 Full system overview The system diagram is intended to show the various electrical connections required for the Leviton Series 8000 multi-circuit meter. Indicated in the diagram are the names of the specific components of the meter which will be referred to later in this guide. Follow the installation steps below for the appropriate wiring information depending on the product model and panel service type.
- Page 3 Wiring Reference Voltage and Meter Power Utilize the correct column below for the type of service being monitored. Please note that 347/600V and 480V delta services require external PTs to step down the voltages before being wired to the meter. If none of the examples below match the form of service in the panel, please refer to the full manual for additional types.
- Page 4 1 Phase 120VAC (1P 2W) 1 Phase Wye 277VAC (1P 2W) Split Phase 120/240VAC (1P 3W) Not Applicable October, 2 NANA 3 Phase Wye 120/208VAC (3P 4W) 3 Phase Wye 277/480V (3P 4W) PK-A3169-10-00-0A Series 8000 Quick Start Guide...
- Page 5 Installing Current Transformers to Monitor the Loads Correct installation of CT orientation on conductor from panel to load. This is an example of a three-phase installation. Use the appropriate diagram below to identify the correct orientation of the CT to the conductor. The “source” refers to the side facing incoming power from the utility.
- Page 6 Once the tenant spreadsheet has been filled out and completed, the last steps are to configure the meter through software and verify the hardware installation is correct. The manual includes the necessary information to complete the commissioning of the Leviton Series 8000 multi-circuit meter. PK-A3169-10-00-0A...
- Page 7 PK-A3169-10-00-0A Series 8000 Quick Start Guide...
- Page 8 COMMENTS : The information in this document is the exclusive PROPRIETARY property of LEVITON MANUFACTURING COMPANY, INC. It is disclosed with the understanding that acceptance or review by the recipient constitutes an undertaking by the recipient. (1) to hold this information in strict confidence, and (2) not to disclose, duplicate, copy, modify or use the information for any purpose other than that for which disclosed.
