Step 7
You will need
4 x Large Cam
Flat Head
Nuts (H2)
Screwdriver
Position side panels (P3, P4)
onto bottom panel (P2) as shown.
Insert 4 x large cam nuts (H2) into side panels (P3, P4). Rotate the cam nuts so the arrow
faces incoming cam bolts. Using a flat head screwdriver turn clockwise to lock.
Step 8
Slide back panel (P6) into
the grooves of the side panels (P3, P4) and bottom panel (P2).
fantasticfurniture.com.au
(P3)
H2
(P2)
(P6)
(P3)
(P4)
H2
H2
(P4)
(P2)
Page 9
