IO -AO 6X
I / O E x p a n s i o n M o d u l e
IO-AO6X Technical Specifications
Max. current consumption
Typical power consumption
Status indicator
(RUN)
Isolated power indicator
(ISO. PWR)
Isolation
Channel to bus
Channel to power supply
Channel to channel
Analog Outputs
Number of outputs
Output range
Resolution (except at 4-20mA)
Resolution at 4-20mA
Load impedance
Conversion time
Linearity error
Operational error limits
Analog Power Supply
Permissible range
Max. current consumption
Environmental
Operating temperature
Storage temperature
Relative Humidity (RH)
Dimensions (WxHxD)
Weight
Mounting
Notes:
1. Note that the range of each I/O is defined both by wiring and within the controller's software.
2. When an analog output is set to use current, the output must be connected before the
power is turned on.
6
32mA maximum from the adapter's 5VDC
29mA @ 5VDC
Green LED:
—Lit when a communication link is established between module and OPLC.
—Blinks when the communication link fails.
Green LED:
—Lit when the isolated power supply is on.
Yes
Yes
No
6 (single-ended)
0-10V, 0-20mA, 4-20mA. See Note 1.
12-bit (4096 units)
819 to 4095 (3277 units)
1kΩ minimum—voltage
500Ω maximum—current. See Note 2.
2 mSec, synchronized to expansion communication.
±0.1%
±0.2%
24VDC
20.4 to 28.8VDC
170mA@24VDC
IP20 / NEMA1
0° to 50°C (32 to 122° F)
-20° to 60°C (-4 to 140° F)
5% to 95% (non-condensing)
80mm x 93mm x 60mm (3.15 x 3.66 x 2.362")
159g (5.6oz.)
Either onto a 35mm DIN-rail or screw- mounted.
