Page 1
Midea Ceramic Hob Instruction MODEL : MC-HV868 SAVE THESE INSTRUCTIONS CAREFULLY Read these instructions carefully before using your hob,and keep it carefully. If you follow the instructions, your hob will provide you with many years of good service.
1. Foreword 1.1 Safety Warnings Your safety is important to us. Please read this information before using your cooktop. 1.2 Installation 1.2.1 Electrical Shock Hazard Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. ...
Page 5
This appliance should be connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply. Failure to install the appliance correctly could invalidate any warranty or liability claims. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning...
1.3 Operation and maintenance 1.3.1 Electrical Shock Hazard Do not cook on a broken or cracked cooktop. If the cooktop surface should break or crack, switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician. ...
1.3.5 Important safety instructions Never leave the appliance unattended when in use. Boilover causes smoking and greasy spillovers that may ignite. Never use your appliance as a work or storage surface. Never leave any objects or utensils on the appliance. ...
-staff kitchen areas in shops, offices and other working environments; -farm houses; -by clients in hotels, motels and other residential type environments; -bed and breakfast type environments. WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. ...
Read this guide, taking special note of the „Safety Warnings‟ section. Remove any protective film that may still be on your ceramic hob. 2.6 Technical Specification Cooking Hob MC-HV868 Cooking Zones 5 Zones Supply Voltage 220-240V~ 50Hz or 60Hz...
3.2 Choosing the right Cookware Do not use cookware with jagged edges or a curved base. Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone. Always lift pans off the ceramic hob –...
Place a suitable pan on the cooking zone that you wish to use. • Make sure the bottom of the pan and the surface of the cooking zone are clean and dry. Touching the heating zone selection control, and a indicator next to the key will flash Adjust heat setting by touching the slider control.
3.3.3 Locking the Controls You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). When the controls are locked, all the controls except the ON/OFF control are disabled. To lock the controls The timer indicator will show “Lo”...
Press “◎”, the double loop function will be cancelled, and power level returns to “6”. Note: The double loop is available only in 3# and 4# cooking zones You can select the function from level 1 to level 9. You can active the Dual zone only when the 3# or 4# cooking zone is selected. 3.3.5 Timer control You can use the timer in two different ways: You can use it as a minute minder.
Page 14
b) Setting the timer to turn one cooking zone off Set one zone Touching the heating zone selection control that you want to set the timer for. Touch timer control, the “10” will show in the timer display, and the “0” flashes. Set the time by touching the slider control.
c). When cooking timer expires, the corresponding cooking zone will be switch off automatically. Note: a) The red dot next to power level indicator will illuminate indicating that zone is selected. b) you want to change the time after the timer is set, you have to start from step 1. 3.3.6 Over-Temperature Protection A temperature sensor equipped can monitor the temperature inside the ceramic hob.
4.1.2 Searing steak To cook juicy flavorsome steaks: Stand the meat at room temperature for about 20 minutes before cooking. Heat up a heavy-based frying pan. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and then lower the meat onto the hot pan.
6. Care and Cleaning What? How? Important! Everyday soiling on 1. Switch the power to the • When the power to the cooktop is glass (fingerprints, cooktop off. switched off, there will be no „hot marks, stains left by 2. Apply a cooktop cleaner while surface‟...
7. Hints and Tips Problem Possible causes What to do The cooktop cannot Be No power. Make sure the ceramic hob is connected turned on. to the power supply and that it is switched on. Check whether there is a power outage in your home or area.
Page 19
SEAL L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm) F(mm) 875+4 495+4 50 mini 3 mini Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As shown below Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm.
There are ventilation holes around outside of the hob. YOU MUST ensure these holes are not blocked by the worktop when you put the hob into position. Be aware that the glue that join the plastic or wooden material to the furniture, has ...
Adjust the bracket position to suit for different work surface‟s thickness. TABLE TABLE BRACKET BRACKET Under any circumstances, the brackets cannot touch with the inner surfaces of the worktop after installation (see picture). 8.3 Cautions The ceramic cooker hob must be installed by qualified personnel or technicians. We have professionals at your service.
Page 22
Yellow/Green Black Brown Blue 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. 2. If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts.
