Basta Boatlifts Over-Center 12k64 Manual

Hydraulic steel lift 12,000 lbs capacity

Advertisement

Quick Links

12k
64
tm
Over-Center
Hydraulic Steel Lift
12,000 lbs Capacity
Model # 12k
64
ASSEMBLY
READ complete manual CAREFULLY
INSTALLATION
BEFORE attempting assembly or operation
REPLACEMENT PARTS
866-GO-BASTA
www.gobasta.com
08/21
©
Copyright 2018 Basta Marine
L392-0099C

Advertisement

loading
Need help?

Need help?

Do you have a question about the Over-Center 12k64 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Basta Boatlifts Over-Center 12k64

  • Page 1 Over-Center Hydraulic Steel Lift 12,000 lbs Capacity Model # 12k ASSEMBLY READ complete manual CAREFULLY INSTALLATION BEFORE attempting assembly or operation REPLACEMENT PARTS 866-GO-BASTA www.gobasta.com 08/21 © Copyright 2018 Basta Marine L392-0099C...
  • Page 2 INDEX Warning ..…………………….................Pages 2 - 3 Parts List and Diagrams ..............Pages 4, 10, 11 Assembly Instructions .................Pages 5 - 13 First Use / Adjustments ..……………............Page 14 Troubleshooting / FAQ .…................Page 15 Warranty ......…................Page 16 WARNING NOTE: Your boat lift is a very heavy piece of equipment. Improper use could result in serious injury or death.
  • Page 3 INSPECT the lift monthly Before Using: for frayed hoses, loose Read this manual fasteners and corrosion completely! lift unattended OIL INJECTED INTO THE SKIN FROM HIGH PRESSURE LEAKS IN HYDRAULIC SYSTEMS CAN CAUSE SEVERE INJURY. MOST DAMAGE OCCURS DURING THE FIRST FEW HOURS.
  • Page 4 Assembly Item List Note: Items A-K referred to as sets (i.e., C = bolt, washer, nut) PART # ITEM # DESCRIPTION PART # ITEM # DESCRIPTION S362-0014 Nylon Insert Lock Nut 1 SS W110-0021 Aft Crossmember S313-0015 Washer Flat 1 SS W110-0020 Forward Crossmember Hex Cap Screw 3/4 x 5 SS...
  • Page 5 ASSEMBLY INSTRUCTIONS NOTE: alternate between set screws A & B while tightening to push leg securely into corner of leg socket Foot and Leg Sockets QTY 12: 5/8 x 1 1/2 hex head set screws...
  • Page 6 A3 A1 NOTE: do not tighten bolts completely until the H-frames and bunks have been installed and squared up A3 A2 Aft Crossmember QTY 8: 1/2 x 1 1/2 bolts QTY 16: 1/2 flat washers QTY 8: 1/2 lock nuts A3 A1 A3 A2 NOTE:...
  • Page 7 ASSEMBLY INSTRUCTIONS NOTE: remove ties C2 C3 Forward H-Frame QTY 2: 1” x 9 bolts QTY 2: 1” flat washers QTY 2: 1” lock nuts...
  • Page 8 NOTE: remove ties C2 C3 Aft H-Frame QTY 2: 1” x 9 bolts QTY 2: 1” flat washers QTY 2: 1” lock nuts Install cylinder with lift in 'down' position G1 G2 G1 G2 Cylinder QTY 4: 3/4 x 3 1/2 clevis pins QTY 4: ring type cotter pins NOTE: install cylinders with hydraulic fittings toward center of lift...
  • Page 9 ASSEMBLY INSTRUCTIONS NOTE: after bunks are installed, adjust the base frame to be square and level, then tighten bolts left loose in steps 2 & 3 D2 D3 NOTE: remove ties Bunk Rails QTY 4: 3/4 x 5 bolts QTY 4: 3/4 flat washers QTY 4: 3/4 lock nuts...
  • Page 10 CONNECT POWER UNIT FEMALE QUICK COUPLER DO NOT SUBMERSE H700-0025 COMPLETE POWER PACKAGE Keep inside dry H653-0012 Prevent unauthorized use - KEEP BOX LOCKED up/down switch power NOTE: NOTE: switch REMOVE SHIPPING PLUG IN REMOVE SHIPPING PLUG IN solar RESERVOIR AND REPLACE RESERVOIR AND REPLACE controller WITH BREATHER PLUG...
  • Page 11 POWER SYSTEM COMPONENTS SOLAR PANEL ASSEMBLY R281-0004 NOTE: pump appearance may vary Padlock not included ENCLOSURE C243-0003 NOTE: NOTE: REMOVE SHIPPING PLUG IN REMOVE SHIPPING PLUG IN RESERVOIR AND REPLACE RESERVOIR AND REPLACE WITH BREATHER PLUG WITH BREATHER PLUG BEFORE START-UP BEFORE START-UP CONTROL PANEL ASSEMBLY...
  • Page 12 J1 J3 J2 J3 Bunk Chevrons [3 places] QTY 12: 3/8 x 3-1/2 bolts QTY 24: 3/8 flat washers QTY 12: 3/8 lock nuts NOTE: LEAVE LOOSE UNTIL BUNKS ARE INSTALLED IN STEP 10 A1 A2 A3 FORWARD A2 A3 A1 A2 E1 E2 A1 A2...
  • Page 13 F2 F3 Keel Block [3 places] QTY 12: 5/16 lock washers QTY 12: 5/16 flat washers QTY 12: 5/16 hex nuts Adjust the base frame to be square and level. Confirm that all bolts are properly tightened and the lift has been properly assembled. Lower the lift completely, then raise it slightly.
  • Page 14 FIRST USE AND ADJUSTMENTS First test lift on dry ground for oil leaks, remote control function and correct operation. IMPORTANT: After installation, the legs MUST be adjusted so that the lift frame is level. Lift must move into Over-Center position when fully raised. 178"...
  • Page 15 We use a special low-toxicity hydraulic fluid that is safe Always leave the boat in the fully raised, Over-Center™ for the environment. This fluid is different than food-grade oil. Only use Basta Boatlifts approved fluid in your position with the power off. hydraulic system.
  • Page 16 Dealer within 50 miles of the location of the Product. Labor will not be provided for on the water. Welcome to the Basta Boatlifts family and Boat Happy! direct purchases from Company or when an active Authorized Dealer is not located within 50 miles of the location of the Product.
