Denham Bedside Table
Assembly Instructions
Thank you for your purchase. Please follow the instructions for correct assembly.
While we took great effort to ensure these assembly instructions were correct at
the time of printing, sometimes updates are required post production. For the
most up to date versions please refer to the product page on our website.
mocka.com.au/mocka.co.nz
A
B
C
dowel
screw
bolt
locking
x8
x4
x12
nut x12
J
K
L
bracket
plastic
bolt
wedge
x4
glide
x16
x4
WARNING:
Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
E
D
F
G
screw
Allen
handle
Key x1
x24
x2
M
N
O
P
screw
slide
slide
x4
x4
rail x2
rail x2
Hardware Supplied
Phillips & Flathead screwdrivers
and hammer required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
H
I
safety
strap x1
screw
bolt
x8
x8
Q
R
slide
slide
rail x2
rail x2
V
W
X
Y
screw
wall
wall
x1
anchor
screw
x1
x1
Wall Strap
Z
washer
x2
1
Advertisement
Related Manuals for Mocka Denham Bedside Table
Summary of Contents for Mocka Denham Bedside Table
- Page 1 Phillips & Flathead screwdrivers and hammer required For quicker assembly, we recommend the use of a power drill on a low-speed setting. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
-
Page 2: Panel Layout
Denham Bedside Table Assembly Instructions Panel layout Insert 4x bolts (C) into panel [1] and tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558... - Page 3 Attach panels [3] and [4] to panel [1] with 4x dowels (A) and secure with 4x [4] as shown, and secure with 12x small screws (E). Tighten with locking nuts (D). Tighten with a screwdriver. a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 4 Attach panel [2] to panels [3] and [4] with 4x dowels (A) and secure with to form the back of the unit as shown. 4x screws (B). Tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 5 Attach legs [40] to panel [2] using 16x bolt (L) as shown. Tighten with an Allen key (F). Attach 4x plastic glide (K) to the ends of the legs. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 6 Attach panels [30] and [31] to panel [32] as shown using 4x screws (H). Slide panel [33] down along the grooves between the panels [30] Tighten with a screwdriver. and [31] to form the back of the unit as shown. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 7 Attach slide rail (Q) and slide rail (R) to the underside of the side Tighten with a screwdriver. panels as shown. Secure with 4x screws (E) and tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 8 Attach 1x handle (G) to panel [34] secure with 2x screws (E).Tighten with Insert the assembled drawers into the corresponding compartments a screwdriver. as shown. Ensure the drawers slide easily along the rails. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 9 Fasten to the wall using 1x washer (Z), 1x wall anchor (X) and using 1x washer (Z) and 1x screw (W). Tighten with a screwdriver. 1x wall screw (Y). Ensure unit is balanced and steady before use. You’re done, enjoy! mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
