Model :
XM5
The Point Mobile name and logo are trademarks of Point Mobile Co., Ltd. in Korea and many other countries.
All rights reserved. This document and any enclosed documents contain confidential or privileged information
belonging to Point Mobile and/or its affiliates. You are hereby notified that any disclosure, copying, distribution
or the taking of any action based on the contents of this information is strictly prohibited.
Originator :
Version :
Jinny Cho
1.0
XM5
User Manual
POINT MOBILE CO., LTD.
B-9F, Kabul Great Valley, 32, Digital-Ro 9Gil
Geumcheon-gu, Seoul, Korea 153-709
www.pointmobile.co.kr
Dept.
PC/PE/ID/PM/QA
Date :
Dec 1
st
, 2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Point Mobile XM5
Summary of Contents for Point Mobile XM5
- Page 1 , 2014 User Manual The Point Mobile name and logo are trademarks of Point Mobile Co., Ltd. in Korea and many other countries. All rights reserved. This document and any enclosed documents contain confidential or privileged information belonging to Point Mobile and/or its affiliates. You are hereby notified that any disclosure, copying, distribution...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ················································································· 4 Trademarks ······························································································· 4 About the XM5 Handy Terminal ·································································· 4 Accessories ······························································································· 4 SAFETY REGULATIONS HW ·································································· 5 2.1. General Safety Rules ········································································ 6 2.2. Power Supply ·················································································· 6 2.3. Laser Safety ···················································································· 6 2.4. LED Safety ····················································································· 8 2.5. - Page 3 Suspend Mode ··············································································· 31 4.22. Memory Allocation ··········································································· 32 4.23. Care and Cleaning of the Products ······················································ 32 4.24. XM5 Technical Specifications ···························································· 32 USING THE KEYPAD ·········································································· 33 5.1. Numeric Keypad Layout ···································································· 34 5.2. Navigation Keys ·············································································· 34 5.3.
- Page 4 USING CONTROL PANEL ···································································· 46 9.1. System Properties ··········································································· 45 9.2. Power properties ············································································· 46 9.3. Program Button properties ································································ 47 9.4. Backlight Properties ········································································· 49 9.5. Scanner Settings ············································································· 49 10. COMMUNICATION ············································································ 52 10.1. Communication Options ···································································· 52 10.2.
-
Page 5: Introduction
This manual generally provides you with the safety information and basic features and operations of the XM5 device. Please read all safety precautions and this manual carefully before using your handy terminals and peripherals to ensure safe and proper use. -
Page 6: Safety Regulations Hw
☞ NOTE: XM5 handy terminals meet or exceed the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to read this manual carefully before performing any type of connection to the handy terminal and operate them according to the agency... -
Page 7: General Safety Rules
Ne tentez pas de démonter le XM5. Ce produit ne contient aucune pièce ne pouvant être réparée par l'utilisateur. Toute manipulation fera perdre la garantie au produit. Lors du remplacement de la batterie ou en fin de vie du terminal portatif XM5, l'élimination et le recyclage doit être effectuée en conformité avec les lois en vigueur dans votre pays. - Page 8 A Class 2 laser is safe because the blink reflex limit the exposure to no more than 0.25 seconds. It only applies to visible-light lasers (400–700 nm). Class-2 lasers are limited to 1mW continuous wave, or more if the emission time is less than 0.25 seconds or if the light is not spatially coherent. Although staring directly at the laser beam momentarily causes no known biological damage, avoid staring at the beam as one would with any very strong light source, such as the sun.
-
Page 9: Led Safety
The following information is provided to comply with the rules imposed by international authorities and refers to the correct use of XM5 handy terminal. Laser Safety Statement This product has been tested in accordance with and complies with CDRH 21 CFR 1040.10 and 1040.11 and IEC 60825-1 Ed 2 (2007) except for deviations pursuant to Laser Notice No 50, dated... -
Page 10: Cb Scheme
. Radio Compliance 2.8. XM5 RF terminals are in conformity with all essential requirements of the R&TTE Directive (1999/5/EC). This device is marked with in accordance with the Class II product requirements specified in the R&TTE Directive, 1999/5/EC. -
Page 11: Weee Compliance
For more detailed information about disposal, reuse, and recycle system, contact your local or regional waste administration. HAZARODUS Locations (USA&Canada) 2.11. XM5 terminals are in conformity with all essential requirements of the HAZARODUS Locations. Canadian Electrical Code U.S. National Electrical Code According to definitions in the... -
Page 12: Atex Directive (Europe)
The following information applies when operating this equipment in hazardous locations: XM5 marked “Class I, Division 2, Groups A, B, C and D” are suitable for use in Class I Division 2 Groups A, B, C, D, Hazardous Locations and nonhazardous locations only. XM5 is supplied with markings on the rating nameplate indicating the hazardous location temperature code. -
Page 13: Getting Started
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les typesd'antenne énumérés ci- dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. -
Page 14: Charge The Batteries
3. Replace the battery door to start from bottom to top door’s lock downwards. ☞ NOTE: Two points of Battery guide stopper must be pertinently inserted to rear cover battery guide stopper hole ☞ NOTE: The battery door must be installed prior to booting the unit. WARNING: Use only Janam-approved Li-Ion battery packs. -
Page 15: Led Indicators
WARNING: Use only Janam-approved peripherals, power cables, and power adapters. Unauthorized peripherals, cables, or power adapters may cause batteries to explode or damage your device. DO NOT attempt to charge damp/wet handy terminals or batteries. All components must be dry before connecting to an external power source. -
Page 16: Guidelines For Battery Pack Use And Disposal
Alternatively, it is also possible to recharge the battery pack by using the single slot cradle, the single Ethernet cradle or the 4-slot battery charger. During the charging process the LED positioned at the upper side of the display is red constant. Once the charging process has been completed this LED is green constant. - Page 17 Do not place the battery pack in or near a fire or heat; do not place the battery pack in direct sunlight, or use or store the battery pack inside unventilated areas in hot weather; do not place the battery pack in microwave ovens, dryer, high pressure containers, on induction cookware or similar device.
-
Page 18: Turn Your Device On
Ne pas percer la batterie avec des objets pointus, la soumettre à l’écrasement ou à des chocs violents. Ne pas démonter ou modifier la batterie (en la pliant, l’écrasant ou la déformant). Celle-ci contient des dispositifs de sécurité et de protection, qui, s'ils sont endommagés, peuvent entraîner un échauffement excessif allant jusqu’à provoquer, son explosion ou son enflammement. -
Page 19: Indicator Icons
Indicator Icons 3.7. The command bar, located at the upper of application screens, provides access to many system functions and programs. Icons Meaning Open the start menu Access the Wireless Manager Open the Scanner option menu Indicates the Keypad value Shows phone signal mode Shows the volume Indicates the Battery Control Panel (CPL) -
Page 20: Selecting Program
4. Get to Know Your Device Feature of Your Device 4.1. The following list outlines a few of the feature included in your device. XM5 Handy Terminal 4.2. Operating Systems: Microsoft Windows Embedded Handheld 6.5 Pro Micro Processor: Cortex-A8 1GHz ... -
Page 21: Front Panel Layout
3.5” VGA Display: 480x640 Transmissive TFT Industrial Grade Touch Screen Keyboards: Numeric, Qwerty Micro SDHC Expansion Memory Card Interface: Support up to 32 GB Power Supply : MicroUSB power adaptor Interfaces : Micro-USB connector : USB 2.0 High Speed ... -
Page 22: Display Backlight
LED Indicator Shows the information needed to operate your device as follows: Note: The LED is user-programmable. LED Color Meaning Lights when main battery is charging. Blinks, when the battery is very low (<10%), Lights when the battery is low (<20%), Blinks as Red/ Green by turns when it is no battery or not recognized Green Lights, when the PDA resets... -
Page 23: Keypad Backlight
To adjust the intensity of the backlight while on battery power, tap Start -> Settings -> System - > Backlight. Screen Backlight - Battery/External Power Move the slider to adjust the screen backlight while on battery power. You may turn the screen backlight off if the device is not used for a designated period of time by checking the option and designating the desired time period. -
Page 24: Installing Your Screen Protector
Janam also mandates use of the proper stylus, which is one that has a stylus tip radius of no less than 0.8mm. Use of the stylus included with the terminal is recommended at all times. Installing Your Screen Protector 4.7. When installing a screen protector, use a flat plastic card (e.g., credit card) to apply the screen protector smoothly and remove any air bubbles. - Page 25 6. Press gently but firmly. Use the card a necessary to smooth out any air pockets or bumps after alloation Press the Power key to weak the terminal and check the touch panel with the stylus. Verify that the screen accepts input from the stylus as usual. If not, re-apply the screen protector.
-
Page 26: Back Panel Layout
12. For maximum performance, recalibrate the screen Tap Start > Settings > System > Screen 13. Tap Recalibrate the follow the instructions on the screen. Back Panel Layout 4.8. Tether hole Handstrip Wire spring mount hole Speaker LED window Camera window Battery cover Wrist Lanyard... -
Page 27: Left Side Panel Layout
Hand strap The HANDY TERMINAL comes with Hand strap. You can attach it to the device. Finger Saddle This is a slightly depressed and angled area of the back housing that is designed to cradle or “saddle” your finger while holding the terminal. This unique ergonomic design makes the terminal comfortable to hold and helps prevent you from accidentally dropping the terminal. -
Page 28: Installing Memory Cards
Installing Memory Cards 4.11. The HANDY TERMINAL supports Micro Secure Digital (SD) memory cards up to 32GB. Sandisk, Kingstone and ATP micro SD recommended To access the Micro SD card slot and insert the card, proceed as follows: 1. Press the Power key to put the terminal in Suspend Mode; see Suspend Mode on paragraph 4.23. -
Page 29: Top Panel Layout
the side buttons. Scan function is assigned by default (Scan button). EarJack 3.5pi 4pole Jack. This connector supports Ear-Mic headset Top Panel Layout 4.13. Image engine window (with engine) Image Engine Window The angled image engine reads and decodes most popular bar code symbolizes. For more information, see Using the Image Engine on paragraph 6. -
Page 30: Peripherals And Accessories
TERMINAL peripherals and cables. This connector powers the terminal, charges the main battery, and facilitates communication. This connector supports High speed USB 2.0 communication (up to 480 Mbps) Through this connector, you can communicate with a host workstation via Microsoft ActiveSync;... -
Page 31: Usb Activesync Cable
For more information, see Single Slot cradle/Single Ethernet cradle Device on paragraph 12. USB ActiveSync Cable 4.16. The MicroUSB ActiveSync Cable is used when communicating between the terminal and a host computer to transfer data via the USB interface. Li-ion Battery Packs 4.17. -
Page 32: Managing Main Battery Power
Main battery pack Charging Options When the battery is installed in the terminal, you can use any of the peripherals listed below to charge the battery. • AC Power Supply to USB Port direct. • Single slot docking cradle/Single slot Ethernet cradle •... -
Page 33: Resetting The Terminal
☞ Start -> Settings -> System -> Power NOTE: You can also check battery power by tapping Resetting the Terminal 4.21. There are three types of system resets: a Soft Reset, a Hard Reset, or a Factory Reset. The soft and hard resets preserve all data stored in the file system. -
Page 34: Suspend Mode
2. When the reset is complete, the Desktop appears. To perform a Hard Reset if the terminal has stopped responding, press and hold the Power button for 8 seconds until the terminal starts to re-boot. Factory Reset NOTE: To prevent data loss, back up all user data to an SD card or external memory device before performing an upgrade or factory reset. -
Page 35: Xm5 Technical Specifications
XM5 Technical Specifications 4.25. Model Operating System Microsoft Windows Embedded Handheld 6.5 Pro Application Software Tools and Demos Processor Cortex-A8 1GHz Memory 512MB RAM X 1GB Flash Storage Expansion User accessible Micro SD memory card slot. Display 3.5 in. transmissive active matrix 65K color LCD with backlight, VGA (480 x 640) -
Page 36: Using The Keypad
Operating -20° to 55°C Temperature Charging Temperature 0~45℃ (±3℃)) Storage Temperature -25ºC to 70ºC Humidity 95% humidity, non-condensing High impact resistant PC/ABS housings Construction Magnesium alloy internal chassis with component shock mounts Drop 1.22m multiple drops to concrete, MIL-STD-810G, Method 516.6, 1.5m Procedure Tumble 3.3 ft (1.0m) tumbles (500 drops) Air:... -
Page 37: Basic Keys
Basic Keys 5.3. Name Function BLUE Modifies the next key pressed to type specific functions. Toggles the keypad between alpha and numeric modes. Indicator changes Yellow accordingly on the command bar. Send Begin dialing. Start an action. Hang up. Cancels an action. returns to closing stage of program and stage before Moves to next control (Indent function to Text editor) Backspace moves the cursor back one space. -
Page 38: Blue Key Combinations
White Indicators on the Numeric Keys 5.5. (Please refer to Keyboard Specification v1.5 document) The mode is changed as Numeric / Alpha when you press the white key, you can type each number/ letter in the sequence Each number key display the characters typed when you press that key in alpha mode. Note that when typing in alpha mode, you must use the same multi-press method you would use when typing letters on a phone keypad. -
Page 39: Using The Image Engine
FSCAN Do Scan LSCAN Do Scan RSCAN Do Scan VOL+ Volume up VOL- Volume down Esc Key Tab Key BACK SPACE Bksp Key ENTER Return Key Del Key TARGET BACKLIGHT No Action No Action No Action No Action No Action No Action No Action No Action... -
Page 40: Available Image Engines
☞ NOTE: It may not read the barcode if the barcode surface is curved. Scan the barcode at the center of the aiming range. ☞ NOTE: It may not read the barcode if the barcode surface is dirty. Try again after cleaning the barcode. ☞... -
Page 41: Supported Bar Code Symbologies
☞ NOTE: Test Condition: Room Temperature (Approx. 23°C), 0 Lux. New picture : N5600-IM Rev E.pdf base. Supported Bar Code Symbologies 6.4. Symbology Type Symbology Name Codabar 1D Symbologies Code 11 Trioptic Code Code 128 Code 32 Pharmaceutical (PARAF) Code 39 Matrix 2 of 5 Code 93 / 93i Telepen... -
Page 42: Activating The Engine
Aztec Code 2D Symbologies Data Matrix MaxiCode MicroPDF417 PDF417 QR Code and Micro QR Code Han Xin EAN.UCC Composite Composite Codes Codablock F TCIF Linked Code 39 (TLC39) Postal Codes Postnet British Post(BPO) Canadian Post Australian Post Japanese Post Planet Code KIX (Netherlands) Post China Post Korea Post... -
Page 43: Sample Bar Codes
1. Tap Start -> Demos -> Scan Demo. 2. Position the Handy Terminal over one of the Sample Bar Codes on paragraph 6.9. A range of 4–10 inches (10–25 cm) from the bar code is recommended. 3. Project the aiming brackets by pressing and holding the Scan key. The Scan LED lights red 4. -
Page 44: Using The Laser Engine
This is a live video image of what the imager is currently viewing and has a slightly degraded appearance compared to the captured image. This is normal; the captured image has a higher resolution. File Formats The Handy Terminal supports BMP file format only. 7. -
Page 45: Supported Bar Code Symbologies
☞ NOTE: * = dependent on width of bar code. Supported Bar Code Symbologies 7.4. Symbology Type Symbology Name UPC A Codabar 1D Symbologies UPC E Code 39 EAN 13 Interleaved 2of 5 EAN 8 Nec 2of5 Code 93 Straight 2of5 Industrial Plessey Straight 2 of 5 IATA GS1 Databar Omnidirectional... -
Page 46: Scanning Positions
Scanning Positions 7.9. The aiming beam must be aimed across the entire bar code to provide you with the best scanning performance. The aiming pattern is smaller when the terminal is held closer to the code and larger when the terminal is held farther from the code. Symbologies with smaller bars or elements (mil size) should be read closer to the unit whereas larger bars or elements (mil size) should be read farther from the unit. -
Page 47: Using Control Panel
Menu Item Sub Item This item … Enables and disables the audio notification for decode/data Beep reception. There is one sound for success and another sound for an error. Notification Enables and disables LED notification for decode/data reception. Vibrator Enables and disables Vibrator notification for decode/data reception. Specifies the method to use when sending the decoded message to the foreground application Keyboard... -
Page 48: Power Properties
Device ID 9.1.2. Your device uses this information to identify itself to other computers. Terminal Serial Number will be in Device Name section by default. You can modify it Copyrights 9.1.3. Portions of this software are based on NCSA Mosaic. Power properties 9.2. - Page 49 Battery tab 9.2.1. To see main battery level indicators open Start > Settings > System > Power icon . Set up the USB charging and On / Off Advanced tab 9.2.2. To adjust power management settings, 1. Set idle time when on battery power before device suspends. 2.
-
Page 50: Program Button Properties
Program Button properties 9.3. Program Buttons Tab 9.3.1. Select Start > Settings > Control Panel > Program buttons Chose its type: Default – button will be assigned default function. No function – button does not have any functions. ... - Page 51 Battery power Tab 9.4.1. Modify display backlight settings when device runs on batteries. Set display brightness level Set backlight timeout time. Available options: 10 sec (by default) 30 sec 1 min 2 min 3 min 4 min 5 min ...
-
Page 52: Scanner Settings
Enable to turn on backlight when a button is pressed or the screen is tapped Keyboard backlight Tab 9.4.3. Enable Keyboard backlight when button is pressed By default this is turned off. Scanner Settings 9.5. To change the Scanner configuration parameter as follows: Tap the Scanwedge icon in the System Tray to open the menu shown in image on the right and select Settings to open the Scanner Settings applet or Start >... - Page 53 Scanner Settings Applet 9.5.1. Section Option Description Specifies the trigger time out in seconds. If a barcode is not Trigger timeout (sec) decoded within the specified timeout, the default Notifier indicates that decoding is failed Enable Auto Scan with specified Enable Auto Scan interval.
-
Page 54: 10. Communication
Enable to transmit predefined Barcode ID Transmit Barcode ID barcode ID in Detail tab Enter Prefix to be sent prior to Wedge Prefix the decoded/received data. Label Enter Suffix to be sent after the Suffix decoded/received data Select barcode types you want to read Symbologies There is “Enable All”... -
Page 55: Installing Additional Software
HandyLink Connector (Wired Communication) The mechanical connector on the bottom panel connects the terminal to various Handy Terminal communication peripherals that connect to a host workstation via USB (1.1 or higher), thus enabling ActiveSync communication. For more information, see ActiveSync Communication on paragraph 10.4. Wireless Radios (Wireless Communication) HANDY TERMINALs can be equipped with an 802.11b/g/n Bluetooth radio and WWAN. -
Page 56: Activesync Communication
ActiveSync Communication 10.4. To synchronize, ActiveSync 4.1 or higher must be installed and configured for the appropriate communication type on the host workstation and the Handy Terminal. Handy Terminals ship with ActiveSync already installed. Therefore, if ActiveSync is already installed on the host workstation, you just need to connect the Handy Terminal to the host workstation (via Handy Terminal peripheral) to initiate communication. -
Page 57: Software Requirements For Communication
• ActiveSync v4.1 or higher (for Windows XP), Windows Mobile Device Center (for Vista and Windows 7) installed on the host workstation • Windows XP, Windows Vista, Windows 7 computer. Software Requirements for Communication 10.7. To sync successfully, ActiveSync must be configured for the same communication type on both the host workstation and the Handy Terminal. -
Page 58: Adding Programs Via Activesync
The Mobile Device folder opens in Windows Explorer. The Handy Terminal is now treated as a mass storage device, and transferring files is as simple as dragging and dropping or copying and pasting as you would for moving files between folders on your hard drive. -
Page 59: Wireless Radios
5. NFC : 13.56MHz HF, ISO14443A, ISO14443B & ISO15693 are supportive ☞ NOTE: XM5 does not provide all Bluetooth profiles. Connecting the Terminal to a Wireless Network 10.14. You connect the terminal to a wireless network through the on-board radio (802.11b/g/n Bluetooth and/or Phone). -
Page 60: Wlan (802.11B/G/N Radio)
will need specific information from your network administrator. ☞ NOTE: 802.11 b/g/n radio module is off by default, in order to avoid wasting energy, you can switch it off using the Wireless Communications applet ☞ NOTE: Suspending the terminal powers off the 802.11 b/g/n radio and drops the radio connection. When the terminal resumes, depending on the radio power mode and security protocol selected, it may take up to 30 seconds for the 802.11 b/g/n radio drivers to re-associate the radio to the network. -
Page 61: 11. Bluetooth Handler
required by the program. 5. On the terminal, the installer file; e.g., the *.exe file. 6. The installation wizard for the program begins. 7. Follow the directions on the screen to complete installation. 11. Bluetooth Handler Bluetooth wireless technology is a short-range communications technology to connect portable and/or fixed devices while maintaining high levels of security. -
Page 62: Setting Up A Bluetooth Printer
5. After pairing, tap on the selected device / profile and select Active. Setting Up a Bluetooth Printer 11.4. 1. Make sure that the Bluetooth printer is on and activated. 2. If not done so already, turn Bluetooth On (by selecting the vertical arrow on the Command Bar). 3. -
Page 63: Front Panel
WARNING: DO NOT attempt to charge damp/wet handy terminals or batteries. All components must be dry before connecting to an external power source. : Nous recommandons l'utilisation des périphériques, câbles d'alimentation et les adaptateurs AVERTISSEMENT électriques fournis par Janam. L'utilisation de tout autre périphérique, peut causer des dommages non couverts par la garantie. -
Page 64: Charging Thebattery
The USB port is full-speed (v2.0). Using the USB cable, you can connect the base to a USB- compliant device to facilitate USB communication to and from the terminal. USB communication occurs through Microsoft ActiveSync (v.4.1 or higher). For more information about ActiveSync setup, see ActiveSync Communication on paragraph 10.4. -
Page 65: Technical Specifications
: Provoquer un court-circuit entre les contacts de la station d’accueil, pourrait provoquer un incendie. AVERTISSEMENT Technical Specifications for Cradle 12.8. CRD-P1-005U (XM5-Single Slot Cradle) Model CRD -P1-005E (XM5-Single Ethernet Cradle) Structural Dimensions 135.5mm(L) x 116mm(W) x 81mm(H) Single Slot cradle - 320g... -
Page 66: Overview
AC 100–240 Vac. Input (Universal) 50/60Hz 0.9A (from the power source) Included with Cradle Output (to the cradle) DC 5V , 4A Charging Standard Charge Main battery: Standard Capacity:4000mAh (60-BTSC) – Approx. 5hours Green: charged Status LED Red: charging Communication MicroUSB connector supports data transmission of up to 480Mbps OR Interface Ethernet 10/100BASE-T(support only CRD -P1-005E) -
Page 67: Front Panel
WARNING: DO NOT attempt to charge damp/wet handy terminals or batteries. All components must be dry before connecting to an external power source. : NE PAS tenter de recharger des terminaux ou des batteries encore humides ou mouillés. AVERTISSEMENT Tous les pièces et parties doivent être sèches avant la connexion à une source d'alimentation externe Front Panel 13.3. -
Page 68: Charging Thebattery
DC Power Jack Connect the power cable to this power jack; see powering the Single Slot Cradle Device on paragraph 12.6. Charging the Battery 13.5. The base powers the terminal and fully charges the battery pack in 5 hours depending on the battery. -
Page 69: Technical Specifications
Technical Specifications for 4slot battery charger 13.6. Model BC-P4-005 (XM5-4Slot Battery Charger) Structural Dimensions 256mm(L) x 105mm(W) x 37mm(H) Weight 4- Slot Battery Charger - 434g Material Polycarbonate Color Black Environmental Operating Temperature -20° to 55°C Storage Temperature -25° to +70°C 0~45℃...
