Point Mobile PM40 User Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Model :

PM40

The Point Mobile name and logo are trademarks of Point Mobile Co., Ltd. in Korea and many other countries.

belonging to Point Mobile and/or its affiliates. You are hereby notified that any disclosure, copying, distribution

or the taking of any action based on the contents of this information is strictly prohibited.

Originator :

Version :

Jinny Cho

1.0

PM40

User Manual

POINT MOBILE CO., LTD.

B-9F, Kabul Great Valley,

9F, Kabul Great Valley, 32, Digital-Ro 9Gil

Geumcheon-gu, Seoul, Korea 153

gu, Seoul, Korea 153-709

www.pointmobile.co.kr

Dept.

PC/PE/ID/PM/QA

Date :

July. 17

, 2013

Table of Contents

Need help?

Do you have a question about the PM40 and is the answer not in the manual?

Questions and answers

Summary of Contents for Point Mobile PM40

Page 1 User Manual The Point Mobile name and logo are trademarks of Point Mobile Co., Ltd. in Korea and many other countries. The Point Mobile name and logo are trademarks of Point Mobile Co., Ltd. in Korea and many other countries.
Page 2: Table Of Contents
CONTENTS [REFERENCE : The Bookmark is not clearly defined yet] 1. INTRODUCTION ·················································································· 5 Trademarks ································································································ 5 About the PM40 Handy Terminal ································································· 5 Accessories ································································································· 5 2. SAFETY REGULATIONS HW ··································································· 6 2.1. General Safety Rules ········································································· 7 2.2.
Page 3 Suspend Mode ················································································· 30 4.22. Memory Allocation ············································································ 31 4.23. Care and Cleaning of the Products······················································· 31 4.24. PM40 Technical Specifications ···························································· 31 5. USING THE KEYPAD ··········································································· 32 5.1. Numeric Keypad Layout ····································································· 33 5.2. Navigation Keys ··············································································· 33 5.3.
Page 4 9.3. Memory ·························································································· 43 9.4. Device name ··················································································· 43 9.5. Copyrights······················································································· 43 9.6. Power properties ·············································································· 43 9.7. Battery tab ······················································································ 43 9.8. Power off tab ··················································································· 44 9.9. CPU Power Setting Tab ····································································· 45 9.10. Alerts Tab ······················································································· 45 9.11.
Page 6: Introduction
This manual generally provides you with the safety information and basic features and operations of the PM40 device. Please read all safety precautions and this manual carefully before using your handy terminals and peripherals to ensure safe and proper use.
Page 7: Safety Regulations Hw
☞ NOTE: PM40 handy terminals meet or exceed the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to read this manual carefully before performing any type of connection to the handy terminal and operate them according to the agency...
Page 8: General Safety Rules
· be repaired by the user. Any tampering will invalidate the warranty. When replacing the battery pack or at the end of the operative life of the PM40 handy terminal, · disposal must be performed in compliance with the laws in force in your country.
Page 9 PM40 handy terminal. Laser Safety Statement This product has been tested in accordance with and complies with C has been tested in accordance with and complies with CDRH 21 CFR 1040 DRH 21 CFR 1040.10 and...
Page 10: Led Safety
Pursuant to part 15 of the FCC Rules, you are cautioned that changes or modifications not expressly approved by Pointmobile could void your authority to operate the PM40 handy terminal. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 11: Weee Compliance
PM40 RF terminals are in conformity with all essential requirements of the R&TTE Directive RF terminals are in conformity with all essential requirements of the R&TTE Directive RF terminals are in conformity with all essential requirements of the R&TTE Directive (1999/5/EC).
Page 12: Getting Started
3. Getting Started Install the Battery 3.1. The HANDY TERMINAL is shipped with the battery packaged separate from the unit. Follow the steps below to install the battery. 1. Remove the battery compartment door by moving the door’s locks right and lifting up the bottom of door.
Page 13: Charge The Batteries
☞ NOTE: Two points of Battery guide stopper must be pertinently inserted to rear cover battery guide stopper hole ☞ NOTE: The battery door must be installed prior to booting the unit. WARNING: Use only Pointmobile-approved Li-Ion battery packs. Unauthorized battery may result in damage not covered by the warranty.
Page 14: Guidelines For Battery Pack Use And Disposal
Alternatively, it is also possible to recharge the battery pack by using the single slot cradle, the single Ethernet cradle or the 4-slot battery charger. During the charging process the LED positioned at the left upper side of the display is red constant. Once the charging process has been completed this LED is green constant.
Page 15: Turn Your Device On
WARNING Do not short-circuit the battery pack contacts connecting the positive terminal and negative terminal. This might happen, for example, when you carry a spare battery pack in your pocket or purse; accidental short–circuiting can occur when a metallic object such as a coin, clip, or pen causes direct connection of the contacts of the battery pack (these look like metal strips on the battery pack).
Page 16: Indicator Icons
Indicator Icons 3.7. The command bar, located at the Upper of application screens, provides access to many system functions and programs. Left and right arrows are used to scroll through additional icons Icons Meaning open the start menu Access the Wireless Manager Open the Scanner option menu Indicates the Keypad value Shows phone signal mode...
Page 17: Using The Stylus
Access the Bluetooth radio Icon Meaning Indicates AC connection mode Indicates WAN (Phone) connection mode Indicates Sound connection mode Indicates LAN / Bluetooth mode Indicates Keypad mode Using the Stylus 3.8. The terminal comes with a stylus included in a loop on the Lanyard. Use this stylus (or your finger) to select or enter information on the touch screen.
Page 18: Get To Know Your Device
4. Get to Know Your Device Feature of Your Device 4.1. The following list outlines a few of the feature included in your device. PM40 Handy Terminal 4.2. Ø Operating Systems: Microsoft Windows Embedded Handheld 6.5 Pro Ø Micro Processor: Cortex-A8 1GHz Ø...
Page 19 Receiver Touch screen display Scan key Keyboard (29-key numeric) LED Indicator Shows the information needed to operate your device as follows: Note: The LED is user-programmable. LED Color Meaning Lights when main battery is charging. Green Lights when scanned bar code is successfully decoded. Lights when main battery charging has completed.
Page 20: Display Backlight
Display Backlight 4.4. The intensity of the backlight of the touch screen display may be changed, and the backlight may be programmed to turn off after the terminal has been idle for a specified period of time. To adjust the intensity of the backlight while on battery power, tap Start -> Settings -> System - >...
Page 21: Using Screen Protectors
Using Screen Protectors Using Screen Protectors 4.6. Pointmobile defines proper use of the terminal touch panel display as using a screen protector and defines proper use of the terminal touch panel display as using a screen protector and defines proper use of the terminal touch panel display as using a screen protector and proper stylus.
Page 22 6. Press gently but firmly. Use the card a necessary to smooth out any air pockets or bumps after allocation Press the Power key to weak the terminal and check the touch panel with the stylus. Verify that the screen accepts input from the stylus as usual. If not, re-apply the screen protector.
Page 23: Back Panel Layout
13. For maximum performance, recalibrate the screen Tap Start > Settings > System > Screen Tap Recalibrate the follow the instructions on the screen. Back Panel Layout 4.8. Lanyard mount hole...
Page 24 LED window Wire spring Camera mount hole window Speaker Battery cover < Wire spring > < Lanyard > Lanyard The HANDY TERMINAL comes with Lanyard and wire spring. You can attach it to the device. Finger Saddle This is a slightly depressed and angled area of the back housing that is designed to cradle or “saddle”...
Page 25: Left Side Panel Layout
etc.). The speaker can also be used for playing sounds (e.g., WAV or MP3 files). The speaker meets the following SPL levels at 10cm: • 500Hz–80dB • 1kHz–90dB • 4kHz–90dB Stylus HANDY TERMINAL is shipped with a stylus inserted in a loop on the Lanyard. Store the stylus in the Lanyard when you’re not using it;...
Page 26: Installing Memory Cards
Installing Memory Cards 4.10. The HANDY TERMINAL supports Micro Secure Digital (SD) memory cards up to 32GB. Sandisk, Kingstone and ATP micro SD recommended To access the Micro SD card slot and insert the card, proceed as follows: 1. Press the Power key to put the terminal in Suspend Mode; see Suspend Mode on paragraph 4.23.
Page 27: Right Side Panel Layout
Side Button You can use the Programs Buttons option in the Control Panel to change the functionality of the side buttons. Scan function is assigned by default. EarJack 3.5pi 4pole Jack. This connector supports Ear-Mic headset USB Port This connector supports High speed USB 2.0 communication (up to 480 Mbps) Also external power from the MicroUSB Adaptor that is included with the terminal.
Page 28: Bottom Panel Layout
Image engine window (with engine) Image Engine Window The angled image engine reads and decodes most popular bar code symbolizes. For more information, see Using the Image Engine on paragraph 6. Bottom Panel Layout 4.13. I/O connector HandyLink Connector The HandyLink mechanical connector is designed to work exclusively with HANDY TERMINAL peripherals and cables.
Page 29: Peripherals And Accessories
Pin Description Direction DC IN +5V DC IN +5V RS-232 Transmitted Data RS-232 Request To Send USB Host +5V USB Host D+ IN/OUT USB Host D- IN/OUT USB Host Detect RS-232 Clear To Send RS-232 Received Data RS-232 ShutDown USB Clinet D+ IN/OUT USB Client D- IN/OUT...
Page 30: Battery Power
Battery Power 4.17. The intelligent battery technology inside the terminal features of battery power: The intelligent battery technology inside the terminal features of battery power: The intelligent battery technology inside the terminal features of battery power: • The battery pack The battery works to prevent data loss when the terminal is used over long periods of time.
Page 31: Resetting The Terminal
Charging Time The standard capacity 1800mAh Li-ion battery pack requires five hours to charge to full capacity, while the high capacity 3600mAh pack requires eight hours. Managing Main Battery Power 4.19. Data and files saved on the Handy Terminal may be stored in RAM memory; therefore, maintain a continuous power supply to the terminal to help prevent data loss.
Page 32: Suspend Mode
Care and Cleaning of the Products 4.23. When needed, clean the image engine window and the LCD display with a clean, non-abrasive, lint-free cloth. The terminal can be cleaned with a damp cloth. PM40 Technical Specifications 4.24. Model PM40 Operating System Microsoft Windows Embedded Handheld 6.5 Pro...
Page 33: Using The Keypad
Memory 512MB RAM X 512MB Flash Storage Expansion User accessible Micro SD memory card slot. Display 2.83 in. transmissive active matrix 65K color LCD with backlight, QVGA (240 x 320) 1D engine: N4313 Scan Engine 2D engine : N560x Keypad 29-key shifted alpha numeric Audio Built-in microphone and speaker...
Page 34: Numeric Keypad Layout
Environmental Independently certified to meet IP65 standards for moisture and particle resistance H; 182mm x W; 66.5mm x D; 30.5mm(grip), 39mm(top) Dimensions 1) 1D ; 293g (318g with High capacity battery) Weight 2) 2D ; 288g (313g with High capacity battery) 2D enginemodel: N560X 2D Imager.
Page 35: Alpha/Numeric Modes
Escape Cancels an action. Enter Performs the same function as the Enter key on a workstation. Power Suspends and resumes the terminal. Scan Activates the image engine to scan a bar code or take an image. Moves the cursor one space forward. Space If you are typing text, it moves the text one space forward as well.
Page 36: Blue Key Combinations
BLUE Key Combinations 5.6. BLUE key modifies the next key pressed to perform specific functions. Key Combination Function BLUE + 1 BLUE + 2 BLUE + 3 BLUE + 4 BLUE + 5 BLUE + 6 BLUE + 7 BLUE + 8 BLUE + 9 BLUE + 0 BLUE + SP...
Page 37: Available Image Engines
☞ NOTE: It may not read the barcode the barcode due to specular reflection if scanning from directly above. due to specular reflection if scanning from directly above. Try again after changing angle. ☞ NOTE: It may not read the barcode the barcode, if this handy terminal is too close to or too far from the barcode even if the , if this handy terminal is too close to or too far from the barcode even if the barcode is within the aiming range.
Page 38: Depth Of Field
Depth of Field 6.3. Depth of Field for N560X ☞ NOTE: Test Condition: Room Temperature (Approx. 23°C), 0 Lux. New picture : N5600-IM Rev E.pdf base. Supported Bar Code Symbologies 6.4. Symbology Type Symbology Name...
Page 39: Activating The Engine
Codabar 1D Symbologies Code 11 Code 128 Trioptic Code Code 39 Code 32 Pharmaceutical (PARAF) Code 93 / 93i Matrix 2 of 5 EAN-8 Telepen EAN-13 GS1-128 Interleaved 2 of 5 ISBT 128 Reduced Space Symbology Straight 2 of 5 (Industrial) UPC-A UPC-A (Coupon Code) UPC-E...
Page 40: Decoding
Decoding 6.7. The Handy Terminal supports Full Full-area Imaging decode mode. Full-area Imaging With full-area imaging the Handy Terminal supports omni area imaging the Handy Terminal supports omni-directional aiming meaning that a directional aiming meaning that a positive read can be obtained from many positions. For details, see Omni positive read can be obtained from many positions.
Page 41: Using The Laser Engine
quickly learn to adapt to different application environments. Image Preview When the imaging process is initiated, the touch screen displays a preview of the object. This is a live video image of what the imager is currently viewing and has a slightly degraded appearance compared to the captured image.
Page 42: Activating The Engine
Code 39 40 mil 26.7in / 67.5cm Code 39 55 mil 31.8in / 80.8cm ☞ NOTE: Test Condition: Room Temperature(Approx. 20°C), 450 ~ 500 Lux. ☞ NOTE: * = dependent on width of bar code. Supported Bar Code Symbologies 7.4. Symbology Type Symbology Name Codabar...
Page 43: Scanning Positions
Scanning Positions 7.9. The aiming beam must be aimed across the entire bar code to provide you with the best scanning performance. The aiming pattern is smaller when the terminal is held closer to the code and larger when the terminal is held farther from the code. Symbologies with smaller bars or elements (mil size) should be read closer to the unit whereas larger bars or elements (mil size) should be read farther from the unit.
Page 44: Using Control Panel
reception. There is one sound for success and another sound for an error. Enables and disables LED notification for decode/data reception. Enables disables Vibrator notification decode/data Vibrator reception. Specifies the method to use when sending the decoded message to the foreground application Keyboard Send decoded bar code data as Keyboard event(stroke) Event...
Page 45: Copyrights
other computers. Terminal Serial Number will be in Device Name section by default. You can modify it Copyrights 9.4. Portions of this software are based on NCSA Mosaic. Power properties 9.5. Battery tab 9.6. To see main battery level indicators open Start >...
Page 46: Cpu Power Setting Tab
☞ To save battery life it is recommended to set idle time as short as possible. NOTE: Alerts Tab 9.8. Adjust the level of main battery for Low battery message and Critical battery message. By default, 20% is set for Low battery message and 10% is set for Critical battery message Wakeup Source Tab 9.9.
Page 47: Key Define Tab
• Delay before first repeat (Short/Long) Delay before first repeat (Short/Long) • Repeat rate (Slow/Fast) ☞ It is useful for a customer to want to remap keyboard. It is useful for a customer to want to remap keyboard. NOTE: Backlight Properties Backlight Properties 9.13.
Page 48: Battery Power Tab
External power Tab 9.15. Modify display backlight settings when device runs on external power. · Set display brightness level · Set backlight timeout time. Available options: (By default) Unchecked 1 min 2 min 5 min 10 min 15 min 30 min ·...
Page 49 Section Option Description Specifies the trigger time out in seconds. If a barcode is not Trigger timeout (sec) decoded within the specified timeout, the default Notifier indicates that decoding is failed Enable Auto Scan with specified Enable Auto Scan interval. Auto Scan interval (sec) Set Auto Scan interval time.
Page 50: 10. Communication
Enter Prefix to be sent prior to Prefix the decoded/received data. Label Enter Suffix to be sent after the Suffix decoded/received data Select barcode types you want to read Symbologies There is “Enable All” and “Disable All” to enable/disable all symbologies Section Option Description...
Page 51: Installing Additional Software
The mechanical connector on the bottom panel connects the terminal to various Handy Terminal communication peripherals that connect to a host workstation via USB (1.1 or higher), thus enabling ActiveSync communication. For more information, see ActiveSync Communication on paragraph 10.4. Wireless Radios (Wireless Communication) HANDY TERMINALs can be equipped with an 802.11a/b/g/n Bluetooth radio and WWAN.
Page 52: Activesync Communication
ActiveSync Communication 10.4. To synchronize, ActiveSync 4.1 or higher must be installed and configured for the appropriate communication type on the host workstation and the Handy Terminal. Handy Terminals ship with ActiveSync already installed. Therefore, if ActiveSync is already installed on the host workstation, you just need to connect the Handy Terminal to the host workstation (via Handy Terminal peripheral) to initiate communication.
Page 53: Communicating With The Handy Terminal
Communicating with the Handy Terminal 10.9. After setting up both the workstation and the terminal, ActiveSync connection should be automatic. 1. Connect the Handy Terminal to a communication peripheral, such as the Handy Terminal Docking cradle. 2. The Handy Terminal automatically opens ActiveSync or Windows Mobile Device Center to establish a connection.
Page 54: Exploring The Terminal From The Workstation
The Handy Terminal is now treated as a mass storage device, and transferring files is as simple as dragging and dropping or copying and pasting as you would for moving files between folders on your hard drive. Adding Programs via ActiveSync 10.12.
Page 55: Adding Programs Via Activesync
3. Phone (WWAN configuration): 3.9G WWAN HSPA Module 4. GPS: Module inherent to HSPA Module ☞ NOTE: PM40 does not provide all Bluetooth profiles. Connecting the Terminal to a Wireless Network 10.14. You connect the terminal to a wireless network through the on-board radio (802.11a/b/g/n Bluetooth and/or Phone).
Page 56: Wlan (802.11B/G/N Radio)
LAN On. The enable/disable state of the radio will survive subsequent soft and hard resets. The next step is to configure the connection parameters of the radio to connect to a wireless network. Configuring the WLAN Radio The WLAN radio is configured in the Pointmobile WLAN Client, which you access by the program icon in the command bar.
Page 57: Connecting To Other Devices
caused by other devices (microwave ovens, radio transmitters, etc.). Connecting to Other Devices 11.2. Before connecting to another device, make sure that the Bluetooth connection on the other device is enabled. 1. Tap on the Bluetooth icon in the task bar. The Bluetooth Handler appears on the screen.
Page 58: Battery Charging
cradle supports full-speed USB 2.0 and RS-232 communication with a workstation. The Single Ethernet cradle is identical to the Single Slot cradle except it supports Ethernet communication as well as full-speed USB 2.0 and RS-232. Battery Charging 12.2. The base completes a full charge of the battery pack in 5hours for the standard capacity 1800mAh pack and 8hours for the extended capacity 3600mAh pack on the handy terminal.
Page 59: Back Panel
the terminal, and charge the terminal’s battery. Make sure that the device is securely seated. Rubber Feet The bottom panel has four rubber feet to stabilize the unit on a flat surface. You can set the base on a dry, stable surface, such as a desktop or workbench near an electrical outlet. Charging LED If the LED is red, the unit is charging;...
Page 60: Powering The Single Slot Docking Cradle Or Single Slot Ethernet Cradle Device
• Transmitted Data • Received Data • Request to Send • Clear to Send ☞ NOTE: ActiveSync is not supported ActiveSync is not supported over the serial port. Ethernet Port (Single Ethernet cradle only) Ethernet cradle only) Using an Ethernet cable, you can connect the Using an Ethernet cable, you can connect the Single Ethernet cradle to an Ethernet Ethernet cradle to an Ethernet-compliant device to facilitate Ethernet communication to and from the terminal.
Page 61: Technical Specifications
As battery packs charge, the charging circuitry follows the two As battery packs charge, the charging circuitry follows the two-step charging process (CC step charging process (CC-CV) that is recommended for Li-Ion batteries. Ion batteries. The process monitors changes in temperature, current, and voltage. The process monitors changes in temperature, current, and voltage.
Page 62 Red: charging Communication MicroUSB connector supports data transmission of up to 480Mbps Interface Standard DB9 serial connector supports data transmission up to 115 Kbps Ethernet 10/100BASE-T(support only PM40-SE) Agency Approvals UL listed Power Supply TUV licensed Power Supply compliant to FCC part 15, Class B...
