Quick Start Guide
PM452
v1.0, July 2024
Copyright © 2024 Point Mobile Co., Ltd. All rights reserved.
Point Mobile Co., Ltd. is the designer and manufacturer of mobile handheld devices.
The Point Mobile logo is a registered trademark and symbol of Point Mobile Co., Ltd.
Features and specifications are subject to change without prior notice.
Advertisement
Related Manuals for Point Mobile PM452
Summary of Contents for Point Mobile PM452
- Page 1 Copyright © 2024 Point Mobile Co., Ltd. All rights reserved. Point Mobile Co., Ltd. is the designer and manufacturer of mobile handheld devices. The Point Mobile logo is a registered trademark and symbol of Point Mobile Co., Ltd. Features and specifications are subject to change without prior notice.
-
Page 2: Device Parts
Device Parts LED indicator (Front) Touch screen Keypad Microphone I/O connector for cradle Battery release button (Left) Scan button (Left) USB connector with cap LED indicator (Center-Left) - Page 3 Device Parts Scanner & Top camera Power button LED indicator (Center-Right) Scan button (Right) Battery release button (Right) Speaker Hand strap hole (Top) Gun handle connect part Battery Hand strap hole (Bottom)
-
Page 4: Battery Replacement
Product Standard Accessories Battery Replacement Install Battery 1. Insert the battery from the top side (opposite side of the gold contacts). 2. Push the battery down firmly Battery pack Charger Check if the battery release buttons are completely outward. Remove Battery While pressing the battery release button in, pull the battery’s bottom side up. -
Page 5: Turning On/Off
Installing SIM, SD card Turning on / off PM452 supports • 1 micro SD card slot • 1 micro SIM card slot - WWAN (LTE) SKU only 1. Remove the battery and open the card slot cover. 2. Insert a SD or SIM card with the contacts facing down. -
Page 6: Charging The Device
4. Provide power by plugging the power adapter to the wall socket. Solid red Charging the device / Battery is low Power PM452 can also be charged with a charging cradle. The cradles are Charging temperature is out of Blinking red sold separately and can be used in common with PM451. - Page 7 Using Keyboard Backlight Using Keypad Functions Turn on the keyboard backlight when the keypad is not visible in a Control volume, display brightness, keyboard backlight brightness dark place. using key(s) on the keypad. Some function is available using a key combination with Function 1.
-
Page 8: Scan A Barcode
Scan a Barcode Certification • Model: PM452 Scanner is enabled by default. If the scanner is not enabled, turn on • Trade name of certified: Point Mobile Co., Ltd. the scanner from ScanSettings first. • Manufacturer : Point Mobile Co., Ltd.
