7

Bill of Materials, PCB Layout, and Schematics

This section contains the ADS8900BEVM
7.1

Bill of Materials

Table 6 lists the ADS8900BEVM BOM.
Manufacturer Part
Number Qty Reference Designators
PA006 1 !PCB
PHI-EVM-CONTROLLER
1 !PCB2
(Edge# 6591636 rev. B)
C3216X5R1E476M160AC 2 C1, C3
C2, C5, C6, C8, C32, C36,
GRM188R71E105KA12D 9
C38, C40, C43
C4, C21, C23, C26, C41,
GRM21BR71A106KE51L 7
C44, C48
C0603C104J3RACTU 1 C7
ZRB18AD71A106KE01L 5 C13, C39, C45, C50, C51
GRM1885C1H102FA01J 3 C16, C31, C42
C2012X7S1A226M125AC 1 C20
C0805C103F1GACTU 3 C34, C35, C37
GRM155R71C104KA88D 2 C47, C49
APT2012LZGCK 1 D1
CUS05S40,H3F 1 D2
PMSSS 440 0025 PH 4 H1, H2, H3, H4
1891 4 H5, H6, H7, H8
9774050360R 2 H9, H10
RM3X4MM 2701 2 H14, H15
87898-0204 2 J1, J2
142-0701-801 2 J3, J7
TSM-103-01-L-SV 3 J4, J6, J8
QTH-030-01-L-D-A 1 J5
THT-14-423-10 1 LBL1
RG2012P-2803-B-T5 1 R1
ERJ-3RSFR10V 1 R2
SBAU269 – October 2016
Submit Documentation Feedback
bill of materials, PCB layout, and the
Table 6. ADS8900BEVM Bill of Materials
Manufacturer Description
Any Printed Circuit Board for Evaluation of ADS8900B
Texas Instruments USB Controller Board for ADC EVMs (Kit Item)
TDK CAP, CERM, 47 µF, 25 V, +/- 20%, X5R, 1206
Murata CAP, CERM, 1 µF, 25 V, +/- 10%, X7R, 0603
Murata CAP, CERM, 10 µF, 10 V, +/- 10%, X7R, 0805
Kemet CAP, CERM, 0.1 µF, 25 V, +/- 5%, X7R, 0603
Murata CAP, CERM, 10 µF, 10 V, +/- 10%, X7T, 0603
Murata CAP, CERM, 1000 pF, 50 V, +/- 1%, C0G/NP0, 0603
TDK CAP, CERM, 22 µF, 10 V, +/- 20%, X7S, 0805
Kemet CAP, CERM, 0.01 µF, 100 V, +/- 1%, C0G/NP0, 0805
Murata CAP, CERM, 0.1 µF, 16 V, +/- 10%, X7R, 0402
Kingbright LED, Green, SMD
Toshiba Diode, Schottky, 40 V, 0.5 A, SOD-323
B&F Fastener Supply MACHINE SCREW PAN PHILLIPS 4-40
Keystone 3/16 Hex Female Standoff
Wurth Elektronik ROUND STANDOFF M3 STEEL 5MM
APM HEXSEAL Machine Screw Pan PHILLIPS M3
Molex Header, 2.54 mm, 2x1, Gold, R/A, SMT
Johnson Connector, End launch SMA, 50 ohm, SMT
Samtec Header, 100mil, 3x1, Gold, SMT
Samtec Header(Shrouded), 19.7mil, 30x2, Gold, SMT
Brady Thermal Transfer Printable Labels, 0.650" W x 0.200" H - 10,000 per roll
Susumu Co Ltd RES, 280 k, 0.1%, 0.125 W, 0805
Panasonic RES, 0.1, 1%, 0.1 W, 0603
Copyright © 2016, Texas Instruments Incorporated
Bill of Materials, PCB Layout, and Schematics
EVM schematics.
