Bill of Materials, PCB Layout, and Schematics

7 Bill of Materials, PCB Layout, and Schematics
This section lists the bill of materials of the ADS7041EVM, shows the printed circuit board (PCB) layout for
the ADS7041EVM. The schematics for the ADS7041EVM are appended to the end of this user's guide.
7.1

Bill of Materials

NOTE: All components should be compliant with the European Union Restriction on Use of
Hazardous Substances (RoHS) Directive. Some part numbers may be either leaded or
RoHS. Verify that purchased components are RoHS-compliant.
Reference
Qty
Designators
6 C1 ,C22, C23, C40,
C41, C46
1 C2
6 C3, C38, C39, C54,
C55, C58
1 C4
5 C5, C7, C9, C11, C52
2 C17, C27
2 C33, C34
2 C36, C37
3 C56, C57, C59
1 J1
1 J2
1 J3
1 L1
2 P2, P4
1 P3
9 R1, R2, R3, R4, R5,
R6, R7, R83, R85
6 R12, R22, R62, R79,
R80, R81
2 R13, R14
3 R20, R21, R25
5 R36, R38, R43, R64,
R65
1 R41
3 R44, R45, R71
1 R46
3 R47, R75, R76
1 R48
5 R50, R54, R55, R78,
R82
1 R66
1 R74
1 R77
1 R84
5 TP1, TP2, TP3, TP4,
TP5
1 U1
1 U2
2 U4, U5
1 U8
18
ADS7041EVM-PDK
Table 6. ADS7041EVM Bill of Materials
Description
Capacitor, 0402, Ceramic, 0.1µF, 10V, 10%, X5R
Capacitor, 0402, Ceramic, 2.2µF, 4V, 20%, X5R
Capacitor, 0402, Ceramic, 1µF,10V,10%,X7S
Capacitor, 0402, Ceramic, 0.22µF,16V,10%
Capacitor, 0603, Ceramic, 10µF,6.3V,20%,X5R
Capacitor, 0402, Ceramic, 1500pF,50V,5%,C0G/NP0
Capacitor, 0402, Ceramic, 15pF,50V,1%,C0G/NP0
Capacitor, 0402, Ceramic, 10000pF,50V,10%,X7R
Capacitor, 0805, Ceramic, 47µF,6.3V,20%,X5R
Connector, Female, 50P, .8mmLS
Connector, Micro SD Card,SMD,8P
SMA Jack, Edge Mount, Gold, Straight, 50Ω
Inductor, 2P, Power Choke 1uH, 30%
Uninstalled
Header W/Shunt,2P,100LS TL=.125
Resistor, 0402,10.0K,1%,1/16W
Resistor, 0402,0Ω,1/16W, Zero Jumper
Resistor, 0402, Thick Film,5%,1/16W,1.5K
Resistor, 0402,25.5Ω,1%,1/16W
Resistor, 0402,49.9Ω,1/16W, 1%, 100ppm
Resistor, 0402, Thick Film,5%,1/16W,1.0M
Resistor, 0402, Thick Film,30.1KΩ,1%,1/10W
Resistor, 0402,51.1K,1%,1/16W
Resistor, 0402,10Ω,1/16W,1%,100ppm
Resistor, 0402, 88.7KΩ, 1/16W, 1%
Uninstalled
Resistor, 0402, Thick Film,5%,1/16W,5.6K
Resistor, 0402,16.2KΩ,1/16W,1%
Resistor, 0402,3.3K,1/16W,1%,100ppm
Uninstalled
Testpoint, Thru-hole, Miniature, 0.1LS,120TL, Black
IC, I2C Compatible, Serial EEPROM, TSSOP-8
IC,60mA, 5.0V, Buck/Boost Charge Pump, TSOT23-6
1.2~5.5V,Ultralow Noise High PSRR Fast RF 100mA LDO
Linear Regulator
IC, Low-power SAR ADC, RUG-8, 1.5x1.5x0.4mm
Copyright © 2014, Texas Instruments Incorporated
Vendor Part Number
Murata GRM155R61A104KA01
Murata GRM155R60G225ME15D
TDK C1005X7S1A105K050BC
Murata GRM155R71C224KA12
Murata GRM188R60J106ME47D
Kemet C0402C152J5GACTU
Murata GRM1555C1H150FZ01D
Murata GRM155R71H103KA88D
Murata GRM21BR60J476ME15L
SAMTEC ERF8-025-01-L-D-RA-L-TR
TYCO Electronic 5025700893
SAMTEC SMA-J-P-X-ST-EM1
Wurth 744029001
Uninstalled Header,MalE,2Pin,0.100CC
TYCO Electronics 103321-2
Panasonic ERJ-2RKF1002X
Venkel CR0402-16W-000T
Panasonic ERJ-2GEJ152
Panasonic ERJ-2RKF25R5X
VISHAY CRCW040249R9F100
Panasonic ERJ-2GEJ105
Panasonic ERJ-2RKF3012X
Panasonic ERJ-2RKF5112X
VISHAY CRCW040210R0F100
VISHAY CRCW040288K7FKED
Uninstalled CRCW04020000Z0ED
Panasonic ERJ-2GEJ562
VISHAY CRCW040216K2FKED
VISHAY CRCW04023301F100
Uninstalled CRCW04021002F100
Keystone Electronics 5001
ATMEL AT24C02C-XHM
Texas Instruments REG71055DDC
Texas Instruments TPS79101DBVREP
Texas Instruments ADS7041IRUG
