Compliance West HT-3000P Instruction Manual

Dielectric withstand tester

Advertisement

Quick Links

HT-3000P
Dielectric Withstand Tester
0-2000 Volts AC Output
0-2800 Volts DC Output
Instruction Manual
COMPLIANCE WEST
USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-3000P and is the answer not in the manual?

Questions and answers

Summary of Contents for Compliance West HT-3000P

  • Page 1 HT-3000P Dielectric Withstand Tester 0-2000 Volts AC Output 0-2800 Volts DC Output Instruction Manual COMPLIANCE WEST...
  • Page 3 Dear Customer: Congratulations! Compliance West USA is proud to present you with your Dielectric Withstand Tester. Your instrument features a groundbreaking logic-controlled circuit design and ergonomic front panel, and represents the latest in high voltage production line testing. To fully appreciate all the features of your new meter, we suggest that you take a few moments to review this manual.
  • Page 5: Table Of Contents

    Table of Contents An Introduction to Dielectric Withstand Testing with the HT-3000P ............4 Safety Precautions ........................4 Test Personnel........................4 Testing Area........................4 Safety Techniques ......................5 Using the HT-3000P Dielectric Withstand Tester................5 Ground Check ........................5 Ground Check Failures ..................5 Defeating the Ground Check ................6 Leakage Test ........................6...
  • Page 6: An Introduction To Dielectric Withstand Testing With The Ht-3000P

    Because of sparking during a dielectric test failure, it is not safe to conduct dielectric withstand tests in combustible atmospheres. It is imperative that a good ground be provided to the HT-3000P. Before connecting the HT-3000P, ensure that a low-resistance ground is provided by the building wiring. If the HT- 3000P is used on a high-resistance grounding circuit, dangerous high voltages may be present to the operator.
  • Page 7: Safety Techniques

    Safety Techniques The high voltage circuit of the HT-3000P can be shut off at any time by pressing the RESET button. The HT-3000P has been provided with a Reset switch to provide an unarmed "Standby" setting when it is energized, but idle. When the red RESET button is lit the tester will not provide high voltage until the RESET button and the TEST button have been pressed in order.
  • Page 8: Defeating The Ground Check

    HT-3000P may show a "PASS". To allow the HT-3000P to test equipment using a two wire power supply cord, the Ground Check can be defeated by turning the rear panel Ground Check switch to the Off position.
  • Page 9: Sporadic Leakage Current Failures

    If the leakage current adjustment of the HT-3000P is set to 20 mA AC and almost all examples of the model being tested are still failing, the primary circuit capacitance of the equipment may be too high to allow the AC dielectric withstand test to be used.
  • Page 10: High Voltage Dielectric Withstand Test Failures

    Testing Equipment with non-Standard Plugs or Pigtail Operation The front panel of the HT-3000P is provided with a NEMA Type 5-15R receptacle, suitable for testing cord-equipped single-phase products designed for use on a 15 amp branch circuit in North America.
  • Page 11: Introduction And Specifications

    Operator instructions are printed on the rear panel for quick reference. The HT-3000P allows custom setups for voltage ramp, test time and leakage limit. The Ground check can be defeated by a switch on the rear panel for testing of products using a two wire power supply cord.
  • Page 12 Leakage Test Provided; 5 mA AC/5 mA DC factory set pass/fail point, user adjustable. Operation Instructions Provided on rear panel. Table 1. HT-3000P Specifications *Ground Continuity Pass/Fail Level can be adjusted from .5 to 5 ohms during the calibration procedure.
  • Page 13: Operation

    Before using your tester, take a few minutes to become familiar with the use of its controls, indicators, and connectors. The front panel features of the HT-3000P are shown in Figure 2 and described in Table 2. The rear panel features of the HT-3000P are shown in Figure 3 and described in Table 3.
  • Page 14 Figure 2. Controls, Indicators, Connectors - Model HT-3000P Front Panel...
  • Page 15 Red High Voltage jack. For connection of high voltage test lead for testing insulating materials, etc. AC/DC Switch Selects AC or DC output. Changing switch setting does not change output until the next time the Reset button is pushed. Table 2. Controls, Indicators, Connectors - Model HT-3000P Front Panel...
  • Page 16 Figure 3. Controls, Indicators, Connectors - Model HT-3000P Rear Panel...
  • Page 17 Use supplied cord set to connect tester to appropriate source of supply. Replace line fuse. Turn Tester Power Switch ON/OFF. Fuse replacement warning / Specifies replacement fuse and required supply voltage. Rating of supply Table 3. Controls, Indicators, Connectors - Model HT-3000P Rear Panel...
  • Page 19: Initial Checkout Procedure

    The following procedure will verify that the HT-3000P is working correctly. We recommend that this procedure be conducted periodically to ensure proper operation of the tester. (A Compliance West HTT-1 function tester may also be used to verify the HT-3000P is working correctly.) The following items are needed to conduct this procedure: - A three inch piece of 18 AWG insulated hookup wire with each end stripped back ½".
  • Page 20: Setting Up The Ht-3000P For Production Line Testing

    This section describes procedures for setting the Pass/Fail leakage current level, high voltage ramp time, high voltage level, and high voltage test time. The HT-3000P is calibrated as shown below at the factory to be usable without adjustment in the majority of applications. If the factory settings are acceptable, you may skip this section.
  • Page 21: Display Of Leakage Limit And Duration Settings

    Most safety agencies will allow a shorter test (usually 1 sec. vs. 1 min.) if the voltage is increased by 20%. The HT-3000P is factory set for 1200 volts AC, a voltage level used for the one second test for many types of equipment. Consult the safety agencies for the required voltage level for the type of equipment being tested.
  • Page 22: Setting The Ground Check Switch

    (usually 1 second vs. 1 minute) if the voltage is increased by 20%. The HT-3000P is factory set for 2 seconds. Consult the safety agencies for the test time for the type of equipment being tested. If a different test time is required, use this procedure to set it.
  • Page 23: Operating Techniques

    The operation of the HT-3000P should be audited daily by conducting the tests described in the Initial Checkout Procedure section of this Manual. Compliance West also offers the model HTT-1, which can be used to quickly verify the operation of your HT-3000P. Contact the factory for details.
  • Page 24: Test Results

    This will ensure that the test voltage has been bled off. The operator can now remove the equipment from the HT-3000P and connect another. The HT-3000P should then be armed by pressing the RESET button. When ready, the operator then presses the TEST button and the test procedure will be conducted again.
  • Page 25: Technical Assistance

    Technical Assistance For Technical Assistance Phone: (800) 748-6224 Technical Assistance is available from Compliance West USA between the hours of 8:30 AM and 4:30 PM Pacific Time. Compliance West USA 2120 Jimmy Durante Blvd., Suite 118 Del Mar, CA 92014...
  • Page 27: Maintenance And Calibration

    3-ohm 1/4 w 1% resistor. Service Information The HT-3000P is warranted to the original purchaser for a period of 1 year. This warranty does not cover problems due to misuse or neglect. Malfunctions which occur within the limits of the warranty will be corrected at no charge.
  • Page 28: Calibration Access

    Calibration Access Use the following procedures to gain access to the calibration adjustments of your instrument. 1. Set Line Power switch to OFF. 2. Disconnect the power cord from the rear of the instrument. 3. Remove the two upper screws on each side of the unit. 4.
  • Page 29: Voltage Calibration Adjustment

    LED has been attained. Voltage Calibration Adjustment Use the following procedure to calibrate the output voltage. Ensure that all test leads are removed from the HT-3000P. Turn OFF the HT-3000P tester. To enter the Calibration Mode you MUST follow the following sequence: - Hold in both the Test and Reset buttons.
  • Page 30 "V2" again. The voltage is now be calibrated. 14. Turn Off the HT-3000P tester. 15. The voltage can be verified by turning on the HT-3000P, running a test, and using the 1000:1 voltage probe to check the meter at different voltages. If the voltages are not within +/- 2% at each voltage, the voltage calibration must be performed again starting at step 1 above.
