- Page 1 HTT-1 Function Tester Instruction Manual COMPLIANCE WEST...
- Page 3 Dear Customer: Congratulations! Compliance West USA is proud to present you with your HTT-1. The operating instructions are included in the Manual, so please retain this information for future use. Thank you for your trust and confidence. Rev. 2.0, February 2009...
-
Page 5: Table Of Contents
Operating Instructions ..........................1 Theory of Operation ........................1 Introduction and Specifications ........................2 Introduction ..........................2 Specifications ..........................2 Operation ..............................3 Setting up the HTT-1........................3 Front Panel Features........................3 Setup Procedure: Hipot Tester ....................3 Setup Procedure: Ground Continuity Tester ................4 Unanticipated Results........................4 Troubleshooting the HTT-1........................7... -
Page 6: Operating Instructions
While all three switches can be simultaneously set for failing modes, we recommend that the HTT-1 be set with one failure at a time to ensure that your testers are functioning correctly. -
Page 7: Introduction And Specifications
Unless optionally equipped as shown in the Specification Section of this manual, the HTT-1 is not intended as a calibration verification tool. The HTT-1 is warranted for a period of one year upon shipment to the original purchaser. Specifications Specifications for the HTT-1 are listed in Table 1 below. -
Page 8: Operation
Remove the HTT-1 from the container and place it on a non-conductive test bench. Plug the cord of the HTT-1 into the receptacle on the Hipot tester and connect the return the front of the Compliance West hipot or continuity tester. To begin testing, follow the directions in Section 1 above. -
Page 9: Setup Procedure: Ground Continuity Tester
On your ground continuity tester, plug the HTT-1 into the high current receptacle. 2) Conduct a simulated PASSING test by setting all three switches of the HTT-1 to the PASS (green) setting and initiating a ground continuity test by starting your ground continuity tester. - Page 10 Figure 1: HTT-1 Front Panel Features...
- Page 11 When set to FAIL, an open ground is simulated and the tester should Ground Test stop testing and indicate a failure. When set to PASS, a normal passing Switch result is simulated. Table 2: HTT-1 front panel Controls, Indicators, and Connectors...
-
Page 12: Troubleshooting The Htt-1
Section 4 Troubleshooting the HTT-1 The HTT-1 does not require calibration. If the HTT-1 does not operate as described in the Theory of Operation section, and the equipment connected to the HTT-1 has been verified to be in good working condition, then the HTT-1 should be returned to Compliance West USA for inspection and/or repair. -
Page 13: Technical Assistance
Section 5 Technical Assistance For Technical Assistance Phone: (800) 748-6224 Technical Assistance is available from Compliance West USA between the hours of 8:30 AM and 4:30 PM Pacific Time Monday through Friday. Compliance West USA 2120 Jimmy Durante Blvd., Suite 124...
