e.
Connect the scanner cable to the USB hub, and then use the cable tie mounts and cable ties to route the cable
as shown below.
The dashed line shows the proper scanner cable routing path.
NOTE:
Route the cable from the outside through the lower rectangular opening. If you route the
cable directly into the scanner bracket, the cable will be severed when you close the display
bracket.
9
