Oracle® MICROS Kiosk 110 Assembly Addendum
Introduction
This addendum provides important assembly information for the Oracle MICROS Kiosk 110.
IMPORTANT:
•
Some steps/parts described in the original ELO assembly instructions do not apply and can
be ignored.
•
This addendum contains important information not included in the original assembly instructions.
•
Use this addendum as the primary overview for assembling the kiosk.
Installation Notes
•
Assemble the kiosk in a dry, well-lit area with a level surface.
•
To assist with assembly, use a magnetic tip screwdriver.
•
The kiosk must be securely bolted to the floor to ensure safety.
•
References to Ingenico, i-Series devices, Star printers, and ELO workstations do not apply to this installation
scenario and can be ignored.
•
This release of the kiosk supports the Oracle MICROS Workstation 625/655 in landscape orientation and the Oracle
MICROS Express Station 400 in portrait orientation.
Oracle MICROS Kiosk 110 Boxes
To simplify the instructions in this addendum, Kiosk 110 shipping boxes have been assigned
"virtual" box numbers. Refer to the table below for more information about box contents,
part numbers, etc.
ACTUAL SHIPPING BOXES ARE NOT MARKED AS BOX 1, BOX 1A, BOX 2, BOX 3,
ETC.
Note that your installation may not include some optional components.
Core Components
Box Number
Oracle Part Number
Varies
***
Varies
***
1*
7602031
2
7601142
Model / Description
Oracle MICROS Workstation 625/655
Oracle MICROS Express Station 4 Series
Oracle MICROS Kiosk 110
* Includes two interior boxes:
•
Box 1A: stand top (
ELO-STAND-SELF-SERVICE-15-22-FLOOR-TOP
•
Box 1B: stand base (
ELO-STAND-SELF-SERVICE-15-22-FLOOR-BASE
Electronic versions of ELO stand documentation can be downloaded from
the ELO website at
https://www.elotouch.com/accessories-wallaby-self-
service-stands.html
External power supply for Oracle MICROS Workstation 6 Series
1
)
)
Advertisement
Summary of Contents for Oracle MICROS 110
- Page 1 References to Ingenico, i-Series devices, Star printers, and ELO workstations do not apply to this installation scenario and can be ignored. • This release of the kiosk supports the Oracle MICROS Workstation 625/655 in landscape orientation and the Oracle MICROS Express Station 400 in portrait orientation. Oracle MICROS Kiosk 110 Boxes To simplify the instructions in this addendum, Kiosk 110 shipping boxes have been assigned “virtual”...
- Page 2 Optional Components Box Number Part Number Model / Description 7602033 Payment cradle for Verifone MX915 7602034 Payment cradle for Verifone e355 7602032 Scanner, scanner cable, L-bracket, and screws *Includes one interior box: • Box 5A: Zebra scanner Varies Printer (Epson TM-T88 or Bixolon SRP-350) Assemble the Kiosk Open Box 1 and the two interior boxes (Box 1A and Box 1B).
- Page 3 Box 1A, Step 7: This install supports the Windows Display Bracket only. Box 1A, Step 8: Use position A for the Oracle MICROS Workstation 625/655 in landscape orientation. Use position C for the Oracle MICROS Express Station 400 in portrait orientation.
- Page 4 Oracle MICROS Express Station 4 Series Installation Note To mount the Oracle MICROS Express Station 400 in portrait orientation, you must first install the optional Portrait Mode Centering Plate for Express Station 4 Series. For more information, refer to the Portrait Mode Centering Plate for Express Station 4 Series documentation on the final page of this document.
- Page 5 Mount the workstation or Express Station on the kiosk by inserting the two standoffs with the M4 screws into the top display bracket holes. Slide the unit down into the smaller grooves, and then tighten the M4 screws. Follow the Box 2 assembly instructions, and include the changes described below: Box 2, Step 1: Does not apply to this assembly scenario and can be ignored.
- Page 6 Plug the Micro USB cable into the scanner, and then replace the cable clip. Scanner with Micro USB cable and cable clip. When using the scanner with the Workstation 625/655 in landscape orientation: Install the scanner on the right corner of the L-bracket by placing the scanner logo-side down and positioning the L-bracket over the mounting holes on the scanner.
- Page 7 Example of the scanner/L-bracket assembly. Insert the scanner/L-bracket assembly between the floor head assembly and the display bracket, and then align the top L-bracket mounting holes with the lower mounting holes on the display bracket. Secure the scanner/L- bracket assembly with two M4 screws.
- Page 8 Attaching the scanner/L-bracket assembly to the floor head assembly. Image shows optional EMV cradle.
- Page 9 Connect the scanner cable to the USB hub, and then use the cable tie mounts and cable ties to route the cable as shown below. The dashed line shows the proper scanner cable routing path. NOTE: Route the cable from the outside through the lower rectangular opening. If you route the cable directly into the scanner bracket, the cable will be severed when you close the display bracket.
- Page 10 When using the scanner with the Express Station 4 Series in portrait orientation: Install the scanner on the short extension of the L-bracket by placing the scanner logo-side down and positioning the L-bracket over the mounting holes on the scanner. Secure the scanner with two M3 screws from Box 5.
- Page 11 Attaching the scanner/L-bracket assembly to the floor head assembly (Express Station 4 Series portrait configuration) Connect the scanner cable to the USB hub by routing the cable through the opening in the floor head assembly, and then through the opening in the display bracket. The dashed line shows the proper scanner cable routing path (Express Station 4 Series portrait configuration)
- Page 12 MX915-ING-ISC250”) and include the changes described below: Box 3, Steps 1-2: Follow as directed. Box 3, Step 3: Use position 3 for the Oracle MICROS Workstation 625/655 in landscape orientation. Box 3, Steps 4-5: Follow as directed. Box 3 Step 6: Route EMV terminal cable through the display bracket, and then connect power and...
- Page 13 M4 screws into the top display bracket holes. Slide the unit down into the smaller grooves, and then tighten the M4 screws. Install M4 screws in the two holes in the lower area of the display bracket. For reference, the following image shows the Verifone e355 and the Oracle MICROS Workstation 625/655 mounted on the kiosk.
- Page 14 Oracle MICROS Kiosk 110 with Verifone e355 and Oracle MICROS Workstation 625/655...
- Page 15 Secure the Kiosk to the Floor To prevent tipping and to ensure stability, the Oracle MICROS Kiosk 110 must be firmly secured to the floor. To facilitate this, there are two holes in the floor mounting plate. The holes can accommodate bolts up to 9/16 or ~.56 inch in diameter with countersunk heads up to 1 inch in diameter.
- Page 16 Optional: Apply MICROS Oracle stickers to each the side of the kiosk in the location shown in the following image: Optional: Apply the Please Scan Here sticker to the scanner face, as shown in the following image:...
-
Page 17: Fcc Statement
Optional: If using an Epson printer, apply the narrow MICROS Oracle sticker over the existing logo on the printer face, as shown in the following image: FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 18 This software or hardware and documentation may provide access to or information about content, products, and services from third parties. Oracle Corporation and its affiliates are not responsible for and expressly disclaim all warranties of any kind with respect to third-party content, products, and services unless otherwise set forth in an applicable agreement between you and Oracle.
- Page 19 Portrait Mode Centering Plate for Express Station 4 Series Return to page 4 of Kiosk Assembly...
