e. Box 3, Step 7: Does not apply to this assembly scenario and can be ignored.
Installing the Verifone e355
10. Open Box 4 and follow the assembly instructions ("INSTALLATION INSTRUCTIONS: E200465 KIT-EMV-INGENICO
ICMP CRADLE-I/M, E201088 KIT-EMV-VERIFONE E355 CRADLE-I/M") and include the changes described below:
a. Box 4, Step 1: Follow as directed.
b. Box 4, Step 2: Route cable as shown in Verifone e355 illustration. Connect the e355 to the USB hub.
c. Box 4, Steps 3-4: Follow as directed.
d. There is no Step 5.
e. Box 4, Steps 6-8b: Does not apply to this assembly scenario and can be ignored.
f. Box 4, Step 9: Install 4x M4 flat head screws from Box 4 / Bag E in the large VESA holes to secure
the EMV cradle assembly to the workstation VESA mount. In the ELO instructions these holes are
marked with the short red arrows.
− Ignore the following instruction: Attach bracket (3) assy. to bracket (4) or (5) using
screw(s) from bag A (red circles). One screw in mid. hole for ESY15/22i.
g. Partially install M4 screws in the two threaded mounting holes above the top two VESA holes. In the
ELO instructions these two holes are marked with short green arrows.
h. Mount the full workstation/EMV cradle assembly on the kiosk by inserting the two partially installed
M4 screws into the top display bracket holes. Slide the unit down into the smaller grooves, and then
tighten the M4 screws. Install M4 screws in the two holes in the lower area of the display bracket.
For reference, the following image shows the Verifone e355 and the Oracle MICROS Workstation
625/655 mounted on the kiosk.
