Oracle MICROS 110 Assembly page 4

Mount the Oracle MICROS Workstation 625/655 or the Oracle MICROS Express
Station 4 Series on the Kiosk
2. Unpack the Oracle MICROS Workstation 625/655 or Oracle MICROS Express Station 400.
3. Remove the I/O panel cover from the workstation or Express Station. If you cannot easily slide off the cover you may
need to remove the cover security screw.
Removing the I/O panel cover from the Oracle MICROS Workstation 625/655
4. Take the metal standoffs
and then partially install M4 screws from Box 1A / Bag L in the top two standoffs.
Oracle MICROS Express Station 4 Series Installation Note
To mount the Oracle MICROS Express Station 400 in portrait orientation, you must first install the optional
Portrait Mode Centering Plate for Express Station 4 Series. For more information, refer to the Portrait
Mode Centering Plate for Express Station 4 Series documentation on the final page of this document.
Verifone e355 Important Note
If your installation includes a Verifone e355 payment device, you must install the appropriate EMV payment
cradle on the kiosk display bracket before mounting the workstation on the kiosk. For detailed instructions
on installing the Verifone e355 EMV payment cradle, refer to Installing the Verifone e355 on page 13 of this
addendum.
from Box 2 and install them in the four VESA holes on the back of the workstation,
4
