NOTE:
Route the scanner cable through the opening in the floor head assembly and display
bracket. If you route the cable directly to the scanner bracket, the cable will be severed
when you close the display bracket.
Optional: Install a Printer (Epson TM-T88 or Bixolon SRP-350)
7. Return to Box 1A, Step 20. Follow the instructions and include the changes described below:
a. Box 1A, Step 20: Follow as directed.
b. Box 1, Step 21-23: Star printers not supported. Skip to Step 24 and continue with Epson TM-T88 printer
installation. Note: The Epson printer installation steps also apply to the Bixolon SRP-350 printer.
c. Box 1, Steps 24-26: Follow as directed.
d. Install the printer power supply.
e. Box 1, Step 27: Follow as directed.
f. Box 1, Step 28: Bolt the kiosk to the floor only after assembling all components for your installation.
Refer to the Securing the Kiosk to the Floor section of this addendum for more information.
g. Box 1A, Step 29: Does not apply to this assembly scenario and can be ignored.
Optional: Mount a Payment Device/EMV Card Reader
This release of the kiosk supports the following payment devices:
•
Verifone MX915
•
Verifone e355
•
Contact your Oracle MICROS representative for information about support for other payment devices.
Mounting instructions for devices other than the Verifone MX915 and Verifone e355 do not apply to this assembly scenario
and can be ignored.
Install the Verifone MX915
8. Open Box 3.
The following items in Box 3 do not apply to this assembly scenario and can be ignored:
•
EMV Edge Bracket, 22 Android (bag label "22 A")
•
EMV Edge Bracket, 22 Windows (bag label "22 W")
•
EMV Edge Bracket, 15 Windows (bag label "15 W")
•
EMV Edge Bracket, 15 Android (bag label "15A")
9. Follow the Box 3 assembly instructions ("ASSEMBLY INSTRUCTIONS E798125 EMV-SELF-SERV-15-22-VF-
MX915-ING-ISC250") and include the changes described below:
a. Box 3, Steps 1-2: Follow as directed.
b. Box 3, Step 3: Use position 3 for the Oracle MICROS Workstation 625/655 in landscape orientation.
c. Box 3, Steps 4-5: Follow as directed.
d. Box 3 Step 6: Route EMV terminal cable through the display bracket, and then connect power and
Ethernet cables to the Verifone MX915.
