INSTALLATION
Rear bus
splices
Figure 6. Cutaway view between sections showing rear bus splices (left) and close-up of splice hardware (right). In some
cases, multiple washers may be required to maintain a minimum ³⁄₄-inch air gap between hardware and adjacent buses or
structure; see the drawings furnished.
Figure 7. Ground bus splice cutaway view. In some cases, the lower tray(s) must be temporarily removed to access the ground
bus splice and anchor brackets.
656-500
Ground bus splice
12
