AFL2-12A-HM65 Series Panel PC

MODEL:

AFL2-12A-HM65 Series

Flat Bezel Panel PC with Intel® Sandy Bridge Mobile CPU,

TFT LCD, Wi-Fi, Touchscreen, RFID Reader, GbE LAN,

Rev. 1.12 - 8 April, 2014

RS-232/422/485, Camera, RoHS

User Manual

Page I

Table of Contents

Summary of Contents for IEI Technology AFL2-12A-HM65/PC-EM-R11

Page 1 AFL2-12A-HM65 Series Panel PC MODEL: AFL2-12A-HM65 Series Flat Bezel Panel PC with Intel® Sandy Bridge Mobile CPU, TFT LCD, Wi-Fi, Touchscreen, RFID Reader, GbE LAN, RS-232/422/485, Camera, RoHS User Manual User Manual Page I Rev. 1.12 - 8 April, 2014...
Page 2 AFL2-12A-HM65 Series Panel PC Revision Date Version Changes Modified viewing angle information. 8 April, 2014 1.12 Added information of the CPU temperature alert LED in Section 1.2.1.1. 8 August, 2013 1.11 Updated for R11 (remove second LAN function) 10 July, 2012 1.10 Initial release 8 December, 2011...
Page 3 AFL2-12A-HM65 Series Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
Page 4 AFL2-12A-HM65 Series Panel PC WARNING: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 5: Table Of Contents
AFL2-12A-HM65 Series Panel PC Table of Contents 1 INTRODUCTION......................1 1.1 AFL2-12A-HM65 F PC O ..........2 EZEL ANEL VERVIEW 1.1.1 Model Variations ....................3 1.1.2 Features ......................3 1.1.3 Applications ....................... 3 1.2 E ....................4 XTERNAL VERVIEW 1.2.1 Front Panel ......................4 1.2.1.1 LED Indicators....................
Page 6 AFL2-12A-HM65 Series Panel PC 2.7.1.1 ATX Power Mode (Default)..............18 2.7.1.2 AT Power Mode ..................18 2.7.2 Power Adapter ....................18 3 UNPACKING ....................... 19 3.1 U ......................20 NPACKING 3.1.1 Packing List ..................... 20 4 INSTALLATION ......................24 4.1 A ..................
Page 7 AFL2-12A-HM65 Series Panel PC 5.3 T ....................52 URN OFF THE OWER 5.4 O ....................52 PENING THE YSTEM 5.4.1 Removing the Back Cover................52 5.4.2 Removing the Internal Aluminum Cover............53 5.5 R ..................54 EPLACING OMPONENTS 5.5.1 Memory Module Replacement ................. 54 5.5.2 WLAN Card Replacement ................
Page 8 AFL2-12A-HM65 Series Panel PC 6.8 S & E ......................92 7 SOFTWARE DRIVERS ....................94 7.1 A ................95 VAILABLE OFTWARE RIVERS 7.2 S ................95 TARTING THE RIVER ROGRAM 7.3 C ................95 HIPSET RIVER NSTALLATION 7.4 G ................99 RAPHICS RIVER NSTALLATION...
Page 9 AFL2-12A-HM65 Series Panel PC D.2.3 Install Operating System, Drivers and Applications........140 D.2.4 Building the Recovery Partition..............141 D.2.5 Create Factory Default Image ..............143 D.3 A ..............148 ECOVERY ETUP ROCEDURE D.4 S ................153 ETUP ROCEDURE FOR INUX D.5 R ................
Page 10 AFL2-12A-HM65 Series Panel PC List of Figures Figure 1-1: AFL2-12A-HM65 Flat Bezel Panel PC ................2 Figure 1-2: AFL2-12A-HM65 Front View ..................4 Figure 1-3: LED Indicators......................5 Figure 1-4: Function Keys ......................7 Figure 1-5: AFL2-12A-HM65 Rear View ..................8 Figure 1-6: AFL2-12A-HM65 I/O Interface Panel ................9 Figure 2-1: AFL2-12A-HM65 Dimensions (mm) .................13 Figure 2-2: COM Ports........................15 Figure 2-3: RJ-45 Ethernet Connectors..................15...
Page 11 AFL2-12A-HM65 Series Panel PC Figure 4-20: D-sub 9 Serial Port Connector................44 Figure 4-21: Ethernet Connector....................45 Figure 4-22: RJ-45 Serial Port Connector ..................45 Figure 4-23: RS-422/485 Serial Port ....................46 Figure 4-24: RS-422/485 Cable ....................47 Figure 4-25: D-sub 9 Connector ....................47 Figure 4-26: USB Device Connection ..................48 Figure 4-27: HDMI Connection ....................49 Figure 5-1: Back Cover Retention Screws .................53 Figure 5-2: Internal Cover Retention Screws................54...
Page 12 AFL2-12A-HM65 Series Panel PC Figure 7-21: Touchscreen Driver Update Complete............... 108 Figure 7-22: PenMount Monitor Icon ..................109 Figure 7-23: PenMount Monitor Popup Menu................. 109 Figure 7-24: Configuration Screen................... 110 Figure 7-25: Calibration Initiation Screen ................110 Figure 7-26: Calibration Screen ....................111 Figure 7-27: AMCap Driver Welcome Screen .................
Page 13 AFL2-12A-HM65 Series Panel PC Figure D-23: Disable Automatically Restart................149 Figure D-24: Launching the Recovery Tool ................150 Figure D-25: Auto Recovery Environment for Windows ............150 Figure D-26: Building the Auto Recovery Partition..............151 Figure D-27: Factory Default Image Confirmation ..............151 Figure D-28: Creating Image.....................
Page 14 AFL2-12A-HM65 Series Panel PC List of Tables Table 1-1: AFL2-12A-HM65 Model Variations ................3 Table 1-2: LED Indicators ......................6 Table 1-3: Function Key Descriptions ..................7 Table 1-4: System Specifications....................11 Table 4-1: Ethernet Connector Pinouts ..................45 Table 4-2: RS-422/485 Serial Port Pinouts .................46 Table 4-3: D-sub 9 Connector Pinouts ..................47 Table 6-1: BIOS Navigation Keys ....................61 Page XIV...
Page 15: Introduction
AFL2-12A-HM65 Series Panel PC Chapter Introduction Page 1...
Page 16: Afl2-12A-Hm65 Flat Bezel Panel Pc Overview
AFL2-12A-HM65 Series Panel PC 1.1 AFL2-12A-HM65 Flat Bezel Panel PC Overview Figure 1-1: AFL2-12A-HM65 Flat Bezel Panel PC The AFL2-12A-HM65 is a 2 generation Intel® Core™ i7/i5/i3 or Celeron® processor powered flat bezel panel PC with a rich variety of functions and peripherals. The AFL2-12A-HM65 is designed for easy and simplified integration into kiosk and point-of-sales (POS) applications.
Page 17: Model Variations
AFL2-12A-HM65 Series Panel PC 1.1.1 Model Variations The model variations of the AFL2-12A-HM65 Series are listed below. Model No. Touchscreen Type Optional Features AFL2-12A-HM65/PC-EM-R11 Projective capacitive EM card reader AFL2-12A-HM65/PC-MF-R11 Projective capacitive MIFARE card reader Projective capacitive AFL2-12A-HM65/PC-R11 5-Wire Resistive...
Page 18: External Overview
AFL2-12A-HM65 Series Panel PC 1.2 External Overview 1.2.1 Front Panel The front side of the AFL2-12A-HM65 is a flat bezel panel TFT LCD screen surrounded by an ABS/PC plastic frame. Figure 1-2: AFL2-12A-HM65 Front View Page 4...
Page 19: Led Indicators
AFL2-12A-HM65 Series Panel PC 1.2.1.1 LED Indicators There are fifteen LED indicator lights located along the front of the LCD screen ( F igure 1-3). Figure 1-3: LED Indicators The descriptions of each LED indicator are listed below. LED Indicator Description Power Shows power on/off status.
Page 20: Table 1-2: Led Indicators
AFL2-12A-HM65 Series Panel PC LED Indicator Description Lights on when the audio is turned off. Controlled by the Audio Mute hot keys. See T able 1-3 Shows the status of the function key below the LED Function indicator. Blinks when the corresponding button is pushed. LCD On/Off Audio Volume Down Audio Volume Up...
Page 21: Function Keys
AFL2-12A-HM65 Series Panel PC 1.2.1.2 Function Keys The function keys are located under the bottom right hand corner of the LCD screen F igure 1-4). Figure 1-4: Function Keys The function keys are described in T able 1-3: Key Combination Function Key Description Fn + LCD On/Off RFID Enable/Disable...
Page 22: Rear Panel
AFL2-12A-HM65 Series Panel PC 1.2.2 Rear Panel The rear panel provides access to the HDD bay and the retention screw holes that support the VESA mounting. Refer to F igure 1-5. Figure 1-5: AFL2-12A-HM65 Rear View 1.2.3 I/O Interface Panel The I/O interface panel located on the bottom of the AFL2-12A-HM65 has the following features: 1 x Audio jack...
Page 23: Figure 1-6: Afl2-12A-Hm65 I/O Interface Panel
AFL2-12A-HM65 Series Panel PC 1 x AT/ATX Switch 6 x Function Keys The external I/O interface connector panel is shown in F igure 1-6. Figure 1-6: AFL2-12A-HM65 I/O Interface Panel Page 9...
Page 24: System Specifications
AFL2-12A-HM65 Series Panel PC 1.3 System Specifications The technical specifications for the AFL2-12A-HM65 systems are listed in T able 1-4. Specification AFL2-12A-HM65 LCD Size 12.1” Max. Resolution 1024 (W) x 768 (H) Brightness (cd/m Contrast Ratio 700:1 LCD Color 16.2M Pixel Pitch (H x V) (mm) 0.240 (H) x 0.240 (V) Viewing Angle (H-V)
Page 25: Table 1-4: System Specifications
AFL2-12A-HM65 Series Panel PC Operation Temperature -20ºC ~ 50ºC with SSD Storage Temperature -20ºC ~ 60ºC IP level IP 64 compliant front panel Power Adapter Input: 100 V AC ~ 240 V AC @ 50 / 60 Hz Output: 19 V DC Power Requirement 9 V ~ 36 V DC Power Consumption...
Page 26: Detailed Specifications
AFL2-12A-HM65 Series Panel PC Chapter Detailed Specifications Page 12...
Page 27: Dimensions
AFL2-12A-HM65 Series Panel PC 2.1 Dimensions The AFL2-12A-HM65 dimensions are shown below. Width: 310.0 mm Height: 265.0 mm Depth: 53.6 mm Figure 2-1: AFL2-12A-HM65 Dimensions (mm) Page 13...
Page 28: Intel® Mobile Processor
AFL2-12A-HM65 Series Panel PC 2.2 Intel® Mobile Processor An Intel® Core™ i7/i5/i3 processor or Celeron® processor is installed in the system. The Intel® mobile processor interfaces with the HM65 chipset through a Direct Media Interface (DMI) with speed of 5 GT/s and a Flexible Display Interface (FDI). 2.3 Motherboard Components The following sections describe some of the features on the motherboard.
Page 29: Lan Connectivity
AFL2-12A-HM65 Series Panel PC Figure 2-2: COM Ports 2.4.2 LAN Connectivity The AFL2-12A-HM65 has one RJ-45 LAN connector on the bottom panel. Figure 2-3: RJ-45 Ethernet Connectors The PCIe LAN from the Intel® HM65 chipset of the AFL2-12A-HM65 is interfaced to the Realtek RTL8111E PCIe gigabit Ethernet (GbE) controllers.
Page 30: Touchscreen Lcd
AFL2-12A-HM65 Series Panel PC and USB 2.0 compliant devices. Only USB 3.0 connectors are compatible with USB 3.0 devices. Figure 2-4: External USB Ports 2.5 Touchscreen LCD 2.5.1 Monitor A 12.1” LCD screen is installed on the front of the AFL2-12A-HM65. The screen is shown F igure 2-5 below.
Page 31: Touch-Screen Module
AFL2-12A-HM65 Series Panel PC 2.5.2 Touch-Screen Module A controller for the touchscreen is installed on the motherboard. The sensitive touchscreen is accurate, reliable and durable. 2.6 Audio 2.6.1 Audio Codec Controller The integrated HD Audio compliant audio controller on the Intel® HM65 Southbridge is integrated to a Realtek ALC888 audio codec.
Page 32: Atx Power Mode (Default)
AFL2-12A-HM65 Series Panel PC 2.7.1.1 ATX Power Mode (Default) With the ATX mode selected, the AFL2-12A-HM65 panel PC goes in a standby mode when it is turned off. The panel PC can be easily turned on via network or a power switch in standby mode.
Page 33: Unpacking
AFL2-12A-HM65 Series Panel PC Chapter Unpacking Page 19...
Page 34: Unpacking
AFL2-12A-HM65 Series Panel PC 3.1 Unpacking To unpack the flat bezel panel PC, follow the steps below: WARNING! The front side LCD screen has a protective plastic cover stuck to the screen. Only remove the plastic cover after the flat bezel panel PC has been properly installed.
Page 35 AFL2-12A-HM65 Series Panel PC Power adapter (P/N: 63040-010090-030-RS) Power cord (P/N: 32702-000401-100-RS) Power transfer cord (P/N: 32000-089400-RS) M3 screws (P/N: 44013-030041-RS) M4 screws (P/N: 44403-040061-RS) Touch pen (P/N: 43125-0002C0-00-RS) RJ-45 to D-sub 9 COM port cable (P/N: 32005-000200-200-RS) RS-422 cable (P/N: 32205-002400-100-RS) IR remote control (P/N: 7Z000-SLPCB005-RS)
Page 36 AFL2-12A-HM65 Series Panel PC Optional Wall mounting kit (P/N: AFLWK-19/AFLWK-19B) Panel mounting kit (P/N: AFLPK-15) Rack mount kit (P/N: AFL2RK-12) (P/N: ARM-11-RS) Stand (P/N: STAND-A12) V-Stand (P/N: VSTAND-A12) Hybrid Card Reader (P/N: AFL2P-12AMSI-U-R10) Page 22...
Page 37 AFL2-12A-HM65 Series Panel PC Magnetic Stripe Reader (P/N: AFL2P-12AMSR-U-R10) Rack Mounting Kit (P/N: AFL2RK-12) OS: Win CE 6.0 (128MB CF Card) (P/N: AFL2CF-12-HM65-CE060-128M-R10) OS: Win XPE (2GB CF Card) (P/N: AFL2CF-12-HM65-XPE-2G-R10) OS: Win XPE (4GB CF Card) (P/N: AFL2CF-12-HM65-XPE-4G-R10) OS: Linux (2GB CF Card) (P/N: AFL2CF-12A-HM65-LNX-R10) OS: Win 7 Embedded (4GB CF Card) (P/N: AFL2CF-12-HM65-WES7P-4G-R10...
Page 38: Installation
AFL2-12A-HM65 Series Panel PC Chapter Installation Page 24...
Page 39: Anti-Static Precautions
AFL2-12A-HM65 Series Panel PC 4.1 Anti-static Precautions WARNING: Failure to take ESD precautions during the maintenance of the AFL2-12A-HM65 result permanent damage AFL2-12A-HM65 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the AFL2-12A-HM65. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the AFL2-12A-HM65 is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered Wear an anti-static wristband: - Wearing a simple anti-static wristband can...
Page 40: Installation And Configuration Steps
AFL2-12A-HM65 Series Panel PC Anti-static Discharge: If a user open the rear panel of the flat bezel panel PC, to configure the jumpers or plug in added peripheral devices, ground themselves first and wear and anti-static wristband. 4.3 Installation and Configuration Steps The following installation steps must be followed.
Page 41: Figure 4-1: Hdd Cover Retention Screws
AFL2-12A-HM65 Series Panel PC Figure 4-1: HDD Cover Retention Screws Step 2: Remove the HDD cover from the device. Step 3: Loosen the captive screw to release the HDD bracket from the chassis ( F igure 4-2). Figure 4-2: HDD Bracket Screw Page 27...
Page 42: Figure4-3: Removing The Hdd Bracket
AFL2-12A-HM65 Series Panel PC Step 4: Slide the HDD bracket out of the device as shown ( F igure 4-3). Figure 4-3: Removing the HDD Bracket Step 5: Insert an HDD into the bracket as shown ( F igure 4-4). Figure 4-4: Inserting the HDD Page 28...
Page 43: At/Atx Mode Selection
AFL2-12A-HM65 Series Panel PC Step 6: Secure the HDD to the bracket using four (4) retention screws (two screws on each side) ( F igure 4-5). Figure 4-5: Securing the HDD Step 7: Slide the HDD module back into the device. Step 8: Tighten the captive screw.
Page 44: At Power Mode
AFL2-12A-HM65 Series Panel PC Figure 4-6: AT/ATX Switch Location Step 2: Adjust the AT/ATX switch. Step 0: 4.5.1 AT Power Mode With the AT mode selected, the power is controlled by a central power unit rather than a power switch. The AFL2-12A-HM65 panel PC turns on automatically when the power is connected.
Page 45: Powering On The System
AFL2-12A-HM65 Series Panel PC 4.6 Powering On the System To power on the system, follow the steps below: Step 1: Locate the Function and Brightness Up function keys. See Section 1 .2.1.1. Step 2: Hold down the Function and Brightness Up buttons for three seconds to power on the system.
Page 46: Arm Mounting
AFL2-12A-HM65 Series Panel PC 4.8.1 Arm Mounting The AFL2-12A-HM65 is VESA (Video Electronics Standards Association) compliant and can be mounted on an arm with a 100mm interface pad. To mount the AFL2-12A-HM65 on an arm, please follow the steps below. Step 1: The arm is a separately purchased item.
Page 47: Panel Mounting
AFL2-12A-HM65 Series Panel PC Step 4: Secure the flat bezel panel PC to the interface pad by inserting four retention screws through the bottom of the mounting arm interface pad and into the flat bezel panel PC. Step 0: Figure 4-8: Arm Mounting (ARM-11-RS) 4.8.2 Panel Mounting To mount the AFL2-12A-HM65 into a panel, please follow the steps below.
Page 48: Figure 4-9: Cutout Dimensions
AFL2-12A-HM65 Series Panel PC Figure 4-9: Cutout Dimensions Step 3: Slide the flat panel PC through the hole until the frame is flush against the panel. Step 4: Align the panel mounting bracket screw holes with the VESA mounting holes on the rear of the panel PC.
Page 49: Rack Mounting
AFL2-12A-HM65 Series Panel PC Figure 4-10: Panel Mounting 4.8.3 Rack Mounting The AFL2-12A-HM65 flat bezel panel PC can be installed into a cabinet or rack. The installation procedures are similar to the panel mounting installation. To do this, please follow the steps below: NOTE: When purchasing the cabinet/rack installation bracket, make sure it is compatible with both the AFL2-12A-HM65 flat bezel panel PC and the...
Page 50: Figure 4-11: The Rack/Cabinet Bracket
AFL2-12A-HM65 Series Panel PC Figure 4-11: The Rack/Cabinet Bracket Step 2: Align the rack mounting bracket screw holes with the VESA mounting holes on the rear of the panel PC. Step 3: Secure the two rack mounting brackets to the rear of the panel PC by inserting the four retention screws into the VESA mounting holes (Figure 4-10 Step 4: Insert the rack mounting clamps into the pre-formed holes along the two edges...
Page 51: Figure 4-12: Rack Bracket Mounting
AFL2-12A-HM65 Series Panel PC Figure 4-12: Rack Bracket Mounting Step 6: Slide the flat bezel panel PC with the attached rack/cabinet bracket into a rack or cabinet ( F igure 4-13). Figure 4-13: Install into a Rack/Cabinet Page 37...
Page 52: Stand Mounting
AFL2-12A-HM65 Series Panel PC Step 7: Once the flat bezel panel PC with the attached rack/cabinet bracket has been properly inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to the front of the rack or cabinet ( F igure 4-13).
Page 53: Wall Mounting
AFL2-12A-HM65 Series Panel PC Figure 4-15: Stand Mounting (Stand-A12-RS) 4.8.5 Wall Mounting To mount the flat bezel panel PC onto the wall, please follow the steps below. Step 1: Select the location on the wall for the wall-mounting bracket. Step 2: Carefully mark the locations of the four screw holes in the bracket on the wall.
Page 54: Figure 4-16: Wall-Mounting Bracket
AFL2-12A-HM65 Series Panel PC Figure 4-16: Wall-mounting Bracket Step 6: Insert the four monitor mounting screws provided in the wall mount kit into the four screw holes on the real panel of the flat bezel panel PC and tighten until the screw shank is secured against the rear panel ( F igure 4-17).
Page 55: Figure 4-17: Chassis Support Screws
AFL2-12A-HM65 Series Panel PC Step 7: Align the mounting screws on the monitor rear panel with the mounting holes on the bracket. Step 8: Carefully insert the screws through the holes and gently pull the monitor downwards until the monitor rests securely in the slotted holes ( F igure 4-17).
Page 56: Bottom Panel Connectors
AFL2-12A-HM65 Series Panel PC Figure 4-18: Secure the Panel PC 4.9 Bottom Panel Connectors 4.9.1 LAN Connection There is one external RJ-45 LAN connector. The RJ-45 connector enables connection to an external network. To connect a LAN cable with an RJ-45 connector, please follow the instructions below.
Page 57: Serial Device Connection
AFL2-12A-HM65 Series Panel PC Figure 4-19: LAN Connection Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN cable RJ-45 connector into the onboard RJ-45 connector. Step 0: 4.9.2 Serial Device Connection The AFL2-12A-HM65 has one male D-sub 9 port connector and one RJ-45 serial port connector on the I/O panel for serial device connection.
Page 58: Serial Port Connection
AFL2-12A-HM65 Series Panel PC Figure 4-20: D-sub 9 Serial Port Connector Step 3: Secure the connector. Secure the serial device connector to the external interface by tightening the two retention screws on either side of the connector. 4.9.2.2 RJ-45 Serial Port Connection CN Label: COM3 CN Type:...
Page 59: Figure 4-21: Ethernet Connector
AFL2-12A-HM65 Series Panel PC Description Description NRTS3 NRI3 Table 4-1: Ethernet Connector Pinouts Figure 4-21: Ethernet Connector Follow the steps below to connect a serial device to the RJ-45 serial port connector of the AFL2-12A-HM65 panel PC. Step 1: Locate the RJ-45 serial port. The location of the RJ-45 serial port is shown in Chapter 1.
Page 60: Rs-422/485 Serial Port Connection
AFL2-12A-HM65 Series Panel PC Step 4: Secure the connector. Secure the serial device connector to the external interface by tightening the two retention screws on either side of the connector. 4.9.3 RS-422/485 Serial Port Connection CN Label: COM6 CN Type: 4-pin connector CN Location: F igure 4-23...
Page 61: Usb Device Connection
AFL2-12A-HM65 Series Panel PC Figure 4-24: RS-422/485 Cable Step 3: Insert the serial connector. Insert the D-sub 9 connector of a serial device into the D-sub 9 connector on the RS-422/485 cable. Step 4: Secure the connector. Secure the serial device connector to the external interface by tightening the two retention screws on either side of the connector.
Page 62: Hdmi Device Connection
AFL2-12A-HM65 Series Panel PC There are two USB 2.0 connectors and two USB 3.0 connectors. All connectors are located on the bottom panel of the AFL2-12A-HM65. To connect a USB device, please follow the instructions below. Step 5: Locate the USB connectors. The locations of the USB connectors are shown in Chapter 1.
Page 63: Figure 4-27: Hdmi Connection
AFL2-12A-HM65 Series Panel PC Step 2: Align the connector. Align the HDMI connector with the HDMI port. Make sure the orientation of the connector is correct. Figure 4-27: HDMI Connection Step 3: Insert the HDMI connector. Gently insert the HDMI connector. The connector should engage with a gentle push.
Page 64: System Maintenance
AFL2-12A-HM65 Series Panel PC Chapter System Maintenance Page 50...
Page 65: System Maintenance Introduction
AFL2-12A-HM65 Series Panel PC 5.1 System Maintenance Introduction If the components of the AFL2-12A-HM65 fail they must be replaced. Components that can be replaced include: SO-DIMM module WLAN Module Please contact the system reseller or vendor to purchase the replacement parts. Back cover removal instructions for the AFL2-12A-HM65 are described below.
Page 66: Turn Off The Power
AFL2-12A-HM65 Series Panel PC 5.3 Turn off the Power WARNING: Failing to turn off the system before opening it can cause permanent damage to the system and serious or fatal injury to the user. Before any maintenance procedures are carried out on the system, make sure the system is turned off.
Page 67: Removing The Internal Aluminum Cover
AFL2-12A-HM65 Series Panel PC Step 3: Remove a total of nine (9) retention screws from the back cover ( F igure 5-1). Figure 5-1: Back Cover Retention Screws Step 4: Carefully separate the back cover from the chassis and lift the cover clear of the device Step 0: 5.4.2 Removing the Internal Aluminum Cover...
Page 68: Replacing Components
AFL2-12A-HM65 Series Panel PC Figure 5-2: Internal Cover Retention Screws Step 2: Lift the aluminum cover off the AFL2-12A-HM65. Step 0: 5.5 Replacing Components 5.5.1 Memory Module Replacement The flat bezel panel PC may be preinstalled with a DDR3 memory module. If the memory module fails, follow the instructions below to replace the memory module.
Page 69: Wlan Card Replacement
AFL2-12A-HM65 Series Panel PC Step 7: Grasp the DDR3 memory module by the edges and carefully pull it out of the socket. Step 8: Install the new DDR3 memory module by pushing it into the socket at an angle F igure 5-3). Step 9: Gently pull the spring retainer clips of the SO-DIMM socket out and push the rear of the DDR memory module down (...
Page 70: Figure5-4: Removing The Antennas
AFL2-12A-HM65 Series Panel PC Step 4: Remove the internal aluminum back cover. See Section 5 .4.2. Step 5: Locate the WLAN card. Step 6: Disconnect the main and auxiliary antennas on the WLAN module F igure 5-4). Figure 5-4: Removing the Antennas Step 7: Push the two spring clips in to release the WLAN card.
Page 71: Figure5-6: Removing The Wlan Card
AFL2-12A-HM65 Series Panel PC Step 8: Grasp the WLAN card by the edges and carefully pull it out of the socket F igure 5-6). Figure 5-6: Removing the WLAN card Step 9: Install a new WLAN card by inserting the card into the slot at an angle Step 10: Push the WLAN card down until the spring retainer clips lock into place.
Page 72: Reinstalling The Covers
AFL2-12A-HM65 Series Panel PC Figure 5-7: Attaching the Antennas Step 12: Replace the internal aluminum cover and secure it to the chassis using six (6) retention screws. Step 13: Replace the back cover and secure it using nine (9) previously removed retention screws.
Page 73: Ami Bios Setup
AFL2-12A-HM65 Series Panel PC Chapter AMI BIOS Setup Page 59...
Page 74: Introduction
AFL2-12A-HM65 Series Panel PC 6.1 Introduction A licensed copy of the BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.
Page 75: Getting Help
AFL2-12A-HM65 Series Panel PC Left arrow Move to the item on the left hand side Right arrow Move to the item on the right hand side Increase the numeric value or make changes Decrease the numeric value or make changes Page Up key Move to the next page Page Dn key...
Page 76: Main
AFL2-12A-HM65 Series Panel PC Boot Changes the system boot configuration. Security Sets User and Supervisor Passwords. Save & Exit Selects exit options and loads default settings The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above. 6.2 Main The Main BIOS menu ( B IOS Menu 1) appears when the BIOS Setup program is entered.
Page 77: Advanced
AFL2-12A-HM65 Series Panel PC Project Version: The board version Build Date and Time: Date the current BIOS version was made Access Level: User access level The System Overview field also has two user configurable fields: System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.
Page 78: Acpi Settings
AFL2-12A-HM65 Series Panel PC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit > ACPI Settings System ACPI Parameters. > CPU Configuration > SATA Configuration > USB Configuration > Super IO Configuration ---------------------- >...
Page 79: Cpu Configuration
AFL2-12A-HM65 Series Panel PC ACPI Sleep State [S3 (Suspend to RAM)] Use the ACPI Sleep State option to specify the sleep state the system enters when it is not being used. Suspend Disabled Suspend function disabled. The system enters S1 (POS) sleep state. The (CPU Stop system appears off.
Page 80 AFL2-12A-HM65 Series Panel PC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced CPU Configuration Enabled for Windows XP and Linux (OS optimized Intel(R) Core(TM) i5-2510E CPU @ 2.50GHz for Hyper-Threading Processor Stepping 206a7 Technology) and Disabled Microcode Revision for other OS (OS not Max Processor Speed 2500 MHz...
Page 81: Sata Configuration
AFL2-12A-HM65 Series Panel PC Disabled Disables the use of hyper threading technology Enables the use of hyper threading technology Enabled EFAULT Intel® Virtualization Technology [Disabled] Use the Intel® Virtualization Technology option to enable or disable virtualization on the system. When combined with third party software, Intel Virtualization technology allows several OSes to run on the same system at the same time.
Page 82 AFL2-12A-HM65 Series Panel PC Disabled Disables the on-board SATA controller. Configures the on-board SATA controller to be in Compatible compatible mode. In this mode, a SATA channel will replace one of the IDE channels. This mode supports up to 6 storage devices. Enhanced Configures the on-board SATA controller to be in EFAULT...
Page 83: Usb Configuration
AFL2-12A-HM65 Series Panel PC 6.3.4 USB Configuration Use the USB Configuration menu ( B IOS Menu 6) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced USB Configuration USB Support Parameters USB Devices: 1 Drive, 2 Keyboards, 2 Hubs...
Page 84 AFL2-12A-HM65 Series Panel PC does not become available until a USB compatible operating system is fully booted with all USB drivers loaded. When this option is enabled, any attached USB mouse or USB keyboard can control the system even when there is no USB driver loaded onto the system.
Page 85 AFL2-12A-HM65 Series Panel PC Port 60/64 Emulation [Enabled] Use the Port 60/64 Emulation BIOS option to enable Port 60-/64 Emulation support. This should be enabled for complete USB keyboard legacy support for non-USB aware OSes. Enabled Port 60-/64 Emulation enabled EFAULT Port 60-/64 Emulation disabled Disabled...
Page 86: Super Io Configuration
AFL2-12A-HM65 Series Panel PC Generic Storage Device 9454 [Auto] Use the Generic Storage Device 9454 BIOS option to configure the mass storage device. Sets the mass storage device to automatically detect Auto EFAULT settings 6.3.5 Super IO Configuration Use the Super IO Configuration menu ( B IOS Menu 7) to set or change the configurations for the FDD controllers, parallel ports and serial ports.
Page 87: Serial Port N Configuration
AFL2-12A-HM65 Series Panel PC 6.3.5.1 Serial Port n Configuration Use the Serial Port n Configuration menu ( B IOS Menu 8) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced Serial Port 0 Configuration Enable or Disable Serial Port (COM) Serial Port...
Page 88: H/W Monitor
AFL2-12A-HM65 Series Panel PC IO=3F8h; Serial Port I/O port address is 3F8h and the interrupt IRQ=3, 4 address is IRQ3, 4 Serial Port I/O port address is 2F8h and the interrupt IO=2F8h; address is IRQ3, 4 IRQ=3, 4 6.3.6 H/W Monitor The H/W Monitor menu ( B IOS Menu 9) shows the operating temperature, fan speeds and system voltages.
Page 89: Fan 1 Configuration
AFL2-12A-HM65 Series Panel PC Voltages: VCC3V +Vcc_core +V5S +V12S +1.5V VSB3V VBAT 5VSB 6.3.6.1 Fan 1 Configuration The Fan 1 Configuration submenu (BIOS Menu 10) allows user to configure the CPU Smart fan settings. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced PC Health Status CPU Smart Fan control...
Page 90: Serial Port Console Redirection
AFL2-12A-HM65 Series Panel PC Manual Mode by The fan spins at the speed set in: Fan PWM control Auto Mode The fan adjusts its speed using these settings: EFAULT Temp. Limit of OFF Temp. Limit of Start Fan Start PWM Slope PWM 1 Temperature of Start [80] The Temperature of Start field allows user to set the starting temperature using the + and...
Page 91 AFL2-12A-HM65 Series Panel PC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced COM1 Console Redirection Console Redirection [Disabled] Enable or Disable. > Console Redirection Settings COM3 --------------------- Console Redirection [Disabled] : Select Screen ↑ ↓: Select Item >...
Page 92: Iei Feature
AFL2-12A-HM65 Series Panel PC 6.4 iEi Feature Use the iEi Feature menu ( B IOS Menu 12) to configure the auto recovery function. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced iEi Feature Auto Recovery Function Reboot and recover Auto Recovery Function [Disabled] system automatically...
Page 93: Chipset
AFL2-12A-HM65 Series Panel PC 6.5 Chipset Use the Chipset menu ( B IOS Menu 13) to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction. Aptio Setup Utility –...
Page 94: Northbridge Configuration
AFL2-12A-HM65 Series Panel PC 6.5.1 NorthBridge Configuration Use the NorthBridge Configuration menu ( B IOS Menu 14) to configure the northbridge chipset. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset NorthBridge Configuration Config Graphics Settings. Memory Information Memory Frequency 1333 Mhz Total Memory...
Page 95: Graphics Configuration
AFL2-12A-HM65 Series Panel PC 6.5.1.1 Graphics Configuration The Graphics Configuration submenu ( B IOS Menu 15) allows user to configure graphics settings. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced Graphics Configuration Select DVMT 5.0 Pre-Allocated (Fixed) DVMT Pre-Allocated [64M] Graphics Memory size...
Page 96 AFL2-12A-HM65 Series Panel PC 192M DVMT memory size set at 192 MB DVMT memory size set at 224 MB 224M 256M DVMT memory size set at 256 MB 288M DVMT memory size set at 288 MB 320M DVMT memory size set at 320 MB DVMT memory size set at 352 MB 352M 384M...
Page 97: South Bridge Configuration
AFL2-12A-HM65 Series Panel PC 800x600 Sets the panel resolution at 800x600 (18-bit) 18BIT Sets the panel resolution at 1024x768 (18-bit) 1024x768 EFAULT 18BIT 1024x768 Sets the panel resolution at 1024x7678 (24-bit) 24BIT 6.5.2 South Bridge Configuration Use the South Bridge Configuration menu ( B IOS Menu 16) to configure the southbridge chipset.
Page 98 AFL2-12A-HM65 Series Panel PC USB 3.0 Controller [Enabled] Use the USB 3.0 Controller BIOS option to enable or disable the USB 3.0 controller USB 3.0 controller disabled Disabled Enabled USB 3.0 controller enabled EFAULT Azalia [Enabled] Use the Azalia option to enable or disable the High Definition Audio controller. Disabled The onboard High Definition Audio controller is disabled Enabled...
Page 99: Graphics Configuration
AFL2-12A-HM65 Series Panel PC BT Function [Enabled] Use the BT Function option to enable or disable the BT function. BT function disabled Disabled Enabled BT function enabled EFAULT Auto Dimming Support [Enabled] Use the Auto Dimming Support option to enable or disable auto dimming support. Disabled Auto dimming support disabled Enabled...
Page 100 AFL2-12A-HM65 Series Panel PC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset Graphics Configuration The platform supports DVMT Pre-Allocated [64M] only one dual-display DVMT Total Gfx Mem [MAX] mode in legacy environment (DOS) : Boot Display Device [HDMI] LVDS+CRT.
Page 101 AFL2-12A-HM65 Series Panel PC 384M DVMT memory size set at 384 MB DVMT memory size set at 416 MB 416M 448M DVMT memory size set at 448 MB 480M DVMT memory size set at 480 MB 512M DVMT memory size set at 512 MB DVMT Total Gfx Mem [MAX] Use the DVMT Total Gfx Mem BIOS option to configure the DVMT total graphics memory size.
Page 102: Boot
AFL2-12A-HM65 Series Panel PC 6.6 Boot Use the Boot menu ( B IOS Menu 18) to configure system boot options. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Boot Configuration Select the keyboard Bootup NumLock State [On]...
Page 103 AFL2-12A-HM65 Series Panel PC Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots. Normal POST messages displayed Disabled Enabled OEM Logo displayed instead of POST messages EFAULT Launch PXE OpROM [Disabled] Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices.
Page 104: Security
AFL2-12A-HM65 Series Panel PC 6.7 Security Use the Security menu ( B IOS Menu 19) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Password Description Set Setup Administrator Password If ONLY the Administrator’s password is set,...
Page 105 AFL2-12A-HM65 Series Panel PC NOTE: It is recommended that the system be reset after setting a new HDD password. Set Master Password Use the Set Master Password field to set or change the master HDD password. NOTE: It is recommended that the system be reset after setting a new master HDD password.
Page 106: Save & Exit
AFL2-12A-HM65 Series Panel PC 6.8 Save & Exit Use the Save & Exit menu ( B IOS Menu 20) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset...
Page 107 AFL2-12A-HM65 Series Panel PC Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults. Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options. Page 93...
Page 108: Software Drivers
AFL2-12A-HM65 Series Panel PC Chapter Software Drivers Page 94...
Page 109: Available Software Drivers
AFL2-12A-HM65 Series Panel PC 7.1 Available Software Drivers NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updates. The following drivers can be installed on the system: Chipset Graphic...
Page 110: Figure 7-1: Chipset Driver Screen
AFL2-12A-HM65 Series Panel PC Step 3: Locate the setup file and double click on it. Step 4: The setup files are extracted as shown in F igure 7-1. Figure 7-1: Chipset Driver Screen Step 5: When the setup files are completely extracted the Welcome Screen in F igure 7-2 appears.
Page 111: Figure 7-2: Chipset Driver Welcome Screen
AFL2-12A-HM65 Series Panel PC Figure 7-2: Chipset Driver Welcome Screen Step 7: The license agreement in F igure 7-3 appears. Step 8: Read the License Agreement. Step 9: Click Yes to continue. Figure 7-3: Chipset Driver License Agreement Step 10: The Read Me file in F igure 7-4 appears.
Page 112: Figure 7-4: Chipset Driver Read Me File
AFL2-12A-HM65 Series Panel PC Step 11: Click Next to continue. Figure 7-4: Chipset Driver Read Me File Step 12: Setup Operations are performed as shown in F igure 7-5. Step 13: Once the Setup Operations are complete, click Next to continue. Figure 7-5: Chipset Driver Setup Operations Page 98...
Page 113: Graphics Driver Installation
AFL2-12A-HM65 Series Panel PC Step 14: The Finish screen in F igure 7-6 appears. Step 15: Select “Yes, I want to restart this computer now” and click Finish.Step 0: Figure 7-6: Chipset Driver Installation Finish Screen 7.4 Graphics Driver Installation To install the Graphics driver, please do the following.
Page 114: Figure 7-7: Graphics Driver Read Me File
AFL2-12A-HM65 Series Panel PC Figure 7-7: Graphics Driver Read Me File Step 6: The installation files are extracted. See F igure 7-8. Step 7: Click Next to continue. Figure 7-8: Graphics Driver Setup Files Extracted Step 8: The Welcome Screen in F igure 7-9 appears.
Page 115: Figure 7-9: Graphics Driver Welcome Screen
AFL2-12A-HM65 Series Panel PC Figure 7-9: Graphics Driver Welcome Screen Step 10: The License Agreement in F igure 7-10 appears. Step 11: Click Yes to accept the agreement and continue. Figure 7-10: Graphics Driver License Agreement Step 12: The Read Me file in F igure 7-11 appears.
Page 116: Figure 7-11: Graphics Driver Read Me File
AFL2-12A-HM65 Series Panel PC Figure 7-11: Graphics Driver Read Me File Step 14: Setup Operations are performed as shown in F igure 7-12. Step 15: Once the Setup Operations are complete, click Next to continue. Figure 7-12: Graphics Driver Setup Operations Step 16: The Finish screen in F igure 7-13 appears.
Page 117: Audio Driver Installation
AFL2-12A-HM65 Series Panel PC Figure 7-13: Graphics Driver Installation Finish Screen 7.5 Audio Driver Installation To install the audio driver, please do the following. Step 1: Access the driver list. (See Section 7 .2) Step 2: Click “Audio” and select the folder which corresponds to your operating system. Step 3: Double click the setup file.
Page 118: Figure 7-14: Audio Driver Welcome Screen
AFL2-12A-HM65 Series Panel PC Figure 7-14: Audio Driver Welcome Screen Step 6: The audio driver installation begins. See F igure 7-15. Figure 7-15: Audio Driver Installation Page 104...
Page 119: Touchscreen Driver
AFL2-12A-HM65 Series Panel PC Step 7: When the installation is complete, the screen in F igure 7-16 appears. Step 8: Select “Yes, I want to restart my computer now” and click Finish. Step 0: Figure 7-16: AC’97 Driver Installation Complete 7.6 Touchscreen Driver To install the touch panel software driver, please follow the steps below.
Page 120: Figure 7-17: Touchscreen Driver Welcome Screen
AFL2-12A-HM65 Series Panel PC Figure 7-17: Touchscreen Driver Welcome Screen Step 6: The License Agreement shown in F igure 7-18 appears. Step 7: Click I A to accept and continue. GREE Figure 7-18: Touchscreen Driver License Agreement Step 8: Browse for an install location or use the one suggested ( F igure 7-19).
Page 121: Figure 7-19: Touchscreen Driver Choose Install Location
AFL2-12A-HM65 Series Panel PC Figure 7-19: Touchscreen Driver Choose Install Location Step 10: The Install screen appears and displays the progress of the installation ( F igure 7-20). Page 107...
Page 122: Figure 7-20: Touchscreen Driver Installation Screen
AFL2-12A-HM65 Series Panel PC Step 11: Click N to continue. Figure 7-20: Touchscreen Driver Installation Screen Step 12: When the installation is complete, click F to exit setup. ( F igure 7-21). INISH Step 12: Figure 7-21: Touchscreen Driver Update Complete Page 108...
Page 123: Calibrating The Touchscreen
AFL2-12A-HM65 Series Panel PC 7.6.1 Calibrating the Touchscreen To calibrate the touchscreen cursor with the motion of the touchscreen pen (or finger), please follow the steps below: Step 1: Make sure the touchscreen driver is properly installed. Step 2: Locate the PenMount Monitor icon in the bottom right corner of the screen. Figure 7-22: PenMount Monitor Icon Step 3: Click the icon.
Page 124: Figure 7-24: Configuration Screen
AFL2-12A-HM65 Series Panel PC Figure 7-24: Configuration Screen Step 6: Double click the PenMount 9000 icon as shown in F igure 7-24. Step 7: The calibration initiation screen in F igure 7-25 appears. Step 8: Select the Standard Calibration button as shown in F igure 7-25.
Page 125: Amcap Driver Installation
AFL2-12A-HM65 Series Panel PC Figure 7-26: Calibration Screen Step 10: Follow the instructions. The user is asked touch the screen at five specified points after which the screen is calibrated. 7.7 AMCap Driver Installation To install the AMCap driver, please do the following. Step 1: Access the driver list.
Page 126: Figure 7-27: Amcap Driver Welcome Screen
AFL2-12A-HM65 Series Panel PC Figure 7-27: AMCap Driver Welcome Screen Step 6: Browse for an install location or use the one suggested ( F igure 7-28). Step 7: Click I to continue. NSTALL Figure 7-28: AMCap Driver Choose Install Location Step 8: The program begins to install.
Page 127: Usb 3.0 Driver Installation
AFL2-12A-HM65 Series Panel PC Step 9: When the driver installation is complete, the screen in F igure 7-29 appears. Step 10: Click Finish to save and exit. Figure 7-29: AMCap Driver Installation Complete 7.8 USB 3.0 Driver Installation To install the USB 3.0 driver, please do the following. Step 1: Access the driver list.
Page 128: Figure 7-30: Usb 3.0 Driver Welcome Screen
AFL2-12A-HM65 Series Panel PC Figure 7-30: USB 3.0 Driver Welcome Screen Step 6: Browse for an install location or use the one suggested ( F igure 7-31). Step 7: Click N to continue. Figure 7-31: USB 3.0 Driver Choose Install Location Step 8: The program is ready to install ( F igure 7-32).
Page 129: Figure 7-32: Usb 3.0 Driver Choose Install Location
AFL2-12A-HM65 Series Panel PC Figure 7-32: USB 3.0 Driver Choose Install Location Step 10: When the driver installation is complete, the screen in Figure 7-33 appears. Step 11: Click Finish to exit. Figure 7-33: USB 3.0 Driver Installation Complete Page 115...
Page 130: A Interface Connectors
AFL2-12A-HM65 Series Panel PC Appendix Interface Connectors Page 116...
Page 131: Peripheral Interface Connectors
AFL2-12A-HM65 Series Panel PC A.1 Peripheral Interface Connectors The AFL2-12A-HM65 panel PC motherboard comes with a number of peripheral interface connectors and configuration jumpers. The pinouts for these connectors are listed below: PIN NO. DESCRIPTION RXD422+ RXD422- TXD422+/TXD485+ TXD422-/TXD485- TableeA-1: RS-422/485 Connector (COM6) Pinouts PIN NO.
Page 132 AFL2-12A-HM65 Series Panel PC PIN NO. DESCRIPTION PWRBTN_SW# TableeA-5: Power Button Connector (PW_BT1) Pinouts PIN NO. DESCRIPTION -DATA5 +DATA5 TableeA-6: RFID USB Connector (RFID_USB1) Pinouts PIN NO. DESCRIPTION SIN2 SOUT2 TableeA-7: RFID COM Connector (RFID_COM1) Pinouts PIN NO. DESCRIPTION PIN NO. DESCRIPTION KEYLED1 KEYLED2...
Page 133 AFL2-12A-HM65 Series Panel PC PIN NO. DESCRIPTION -DATA +DATA TableeA-10: Mini USB Connector (MINUSB2) Pinouts PIN NO. DESCRIPTION -DATA +DATA 3VCC TableeA-11: Mini USB Connector (MINUSB1) Pinouts PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPI_VCC FSCE# FMISO FSCK FMOSI TableeA-12: EC Firmware Connector (JSPI2) Pinouts PIN NO.
Page 134 AFL2-12A-HM65 Series Panel PC AD_LED# VCC3 WiFi_LED# VCC3 BT_LED# +V3.3A_EC VCC_RFID GROUND TableeA-14: LED Connector (LEDCN1) Pinouts PIN NO. DESCRIPTION PIN NO. DESCRIPTION EC_EPP_STB# EC_EPP_AFD# EC_EPP_PD0 EC_EPP_ERR# EC_EPP_PD1 EC_EPP_INIT# EC_EPP_PD2 EC_EPP_SLIN# EC_EPP_PD3 GROUND EC_EPP_PD4 EC_EPP_ACK# EC_EPP_PD5 EC_EPP_BUSY EC_EPP_PD6 EC_EPP_PE EC_EPP_PD7 EC_EPP_SLCT TableeA-15: EC Debug Connector (CN4) Pinouts PIN NO.
Page 135 AFL2-12A-HM65 Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC12 VCC12 VCC5 SATA_RXP0_C VCC5 SATA_RXN0_C VCC5 VCC5 SATA_TXN0_C SATA_TXP0_C VCC3 VCC3 TableeA-18: SATA Connector (JSATA1) Pinouts PIN NO. DESCRIPTION -DATA +DATA TableeA-19: Bluetooth USB Connector (BLUETOOTH1) Pinouts PIN NO. DESCRIPTION -DATA +DATA...
Page 136 AFL2-12A-HM65 Series Panel PC PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPI_VCC FSCE# FMISO FSCK FMOSI TableeA-22: Flash SPI Connector (JSPI1) Pinouts PIN NO. DESCRIPTION PIN NO. DESCRIPTION BKL_POWER BKL_POWER ENABKL BRIGHTNESS TableeA-23: Backlight Inverter Connector (INVERTER1) Pinouts PIN NO. DESCRIPTION PIN NO.
Page 137: B Safety Precautions
AFL2-12A-HM65 Series Panel PC Appendix Safety Precautions Page 123...
Page 138: Safety Precautions
AFL2-12A-HM65 Series Panel PC WARNING: The precautions outlined in this chapter should be strictly followed. Failure to follow these precautions may result in permanent damage to the AFL2-12A-HM65. B.1 Safety Precautions Please follow the safety precautions outlined in the sections that follow: B.1.1 General Safety Precautions Please ensure the following safety precautions are adhered to at all times.
Page 139: Cpu Temperature Warning
AFL2-12A-HM65 Series Panel PC B.1.2 CPU Temperature Warning WARNING: When the CPU’s core temperature reaches TJ Max, the CPU temperature alert LED turns and the CPU starts to lower its clock speed. At this moment, the user must lower the environments temperature or close some running applications to cool down the CPU.
Page 140: Product Disposal
AFL2-12A-HM65 Series Panel PC B.1.4 Product Disposal CAUTION: Risk of explosion if battery is replaced by and incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. Outside the European Union - If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.
Page 141: Cleaning Tools
AFL2-12A-HM65 Series Panel PC Except for the LCD panel, never spray or squirt liquids directly onto any other components. To clean the LCD panel, gently wipe it with a piece of soft dry cloth or a slightly moistened cloth. The interior of the AFL2-12A-HM65X does not require cleaning. Keep fluids away from the AFL2-12A-HM65 interior.
Page 142: C Bios Configuration Options
AFL2-12A-HM65 Series Panel PC Appendix BIOS Configuration Options Page 128...
Page 143: Bios Configuration Options
AFL2-12A-HM65 Series Panel PC BIOS Configuration Options Below is a list of BIOS configuration options described in Chapter 　 System Overview .........................62 　 System Date [xx/xx/xx] ......................63 　 System Time [xx:xx:xx] .......................63 　 ACPI Sleep State [S3 (Suspend to RAM)]................65 　...
Page 144 AFL2-12A-HM65 Series Panel PC 　 Boot Display Device [LFP] ....................82 　 LCD Panel Type [1024x768 18BIT] ..................82 　 USB Function [Enabled]......................83 　 USB 3.0 Controller [Enabled]....................84 　 Azalia [Enabled] ........................84 　 Azalia Internal HDMI Codec [Enabled]................84 　 WIFI Function [Enabled]......................84 　...
Page 145: D One Key Recovery
AFL2-12A-HM65 Series Panel PC Appendix One Key Recovery Page 131...
Page 146: One Key Recovery Introduction
AFL2-12A-HM65 Series Panel PC D.1 One Key Recovery Introduction The IEI one key recovery is an easy-to-use front end for the Norton Ghost system backup and recovery tool. This tool provides quick and easy shortcuts for creating a backup and reverting to that backup or reverting to the factory default settings.
Page 147: System Requirement
AFL2-12A-HM65 Series Panel PC After completing the five initial setup procedures as described above, users can access the recovery tool by pressing <F3> while booting up the system. The detailed information of each function is described in Section D.5. NOTE: The initial setup procedures for Linux system are described in Section D.3.
Page 148: Supported Operating System
AFL2-12A-HM65 Series Panel PC partitions. Please take the following table as a reference when calculating the size of the partition. OS Image after Ghost Compression Ratio Windows® 7 7 GB 5 GB Windows® XPE 776 MB 560 MB Windows® CE 6.0 36 MB 28 MB NOTE:...
Page 149: Setup Procedure For Windows
AFL2-12A-HM65 Series Panel PC Linux Fedora Core 12 (Constantine) Fedora Core 11 (Leonidas) Fedora Core 10 (Cambridge) Fedora Core 8 (Werewolf) Fedora Core 7 (Moonshine) RedHat RHEL-5.4 RedHat 9 (Ghirke) Ubuntu 8.10 (Intrepid) Ubuntu 7.10 (Gutsy) Ubuntu 6.10 (Edgy) Debian 5.0 (Lenny) Debian 4.0 (Etch) SuSe 11.2 SuSe 10.3...
Page 150: Hardware And Bios Setup
AFL2-12A-HM65 Series Panel PC The detailed descriptions are described in the following sections. NOTE: The setup procedures described below are for Microsoft Windows operating system users. For Linux, most of the setup procedures are the same except for several steps described in Section D.3. D.2.1 Hardware and BIOS Setup Step 1: Make sure the system is powered off and unplugged.
Page 151: Figure D-2: Launching The Recovery Tool
AFL2-12A-HM65 Series Panel PC Step 2: Boot the system from recovery CD. When prompted, press any key to boot from the recovery CD. It will take a while to launch the recovery tool. Please be patient! Figure D-2: Launching the Recovery Tool Step 3: The recovery tool setup menu is shown as below.
Page 152: Figure D-4: Command Prompt
AFL2-12A-HM65 Series Panel PC Figure D-4: Command Prompt Step 5: The command prompt window appears. Type the following commands (marked in red) to create two partitions. One is for the OS installation; the other is for saving recovery files and images which will be an invisible partition. (Press <Enter>...
Page 153: Figure D-5: Partition Creation Commands
AFL2-12A-HM65 Series Panel PC Figure D-5: Partition Creation Commands Page 139...
Page 154: Install Operating System, Drivers And Applications
AFL2-12A-HM65 Series Panel PC NOTE: Use the following commands to check if the partitions were created successfully. Step 6: Press any key to exit the recovery tool and automatically reboot the system. Please continue to the following procedure: Build the Recovery Partition.S t e p 0 : D.2.3 Install Operating System, Drivers and Applications Install the operating system onto the unlabelled partition.
Page 155: Building The Recovery Partition
AFL2-12A-HM65 Series Panel PC D.2.4 Building the Recovery Partition Step 1: Put the recover CD in the optical drive. Step 2: Start the system. Step 3: Boot the system from the recovery CD. When prompted, press any key to boot from the recovery CD. It will take a while to launch the recovery tool. Please be patient! Figure D-6: Launching the Recovery Tool Step 4:...
Page 156: Figure D-8: Building The Recovery Partition
AFL2-12A-HM65 Series Panel PC Step 5: The Symantec Ghost window appears and starts configuring the system to build a recovery partition. In this process the partition created for recovery files in Section D.2.2 is hidden and the recovery tool is saved in this partition. Figure D-8: Building the Recovery Partition Step 6: After completing the system configuration, press any key in the following window...
Page 157: Create Factory Default Image
AFL2-12A-HM65 Series Panel PC D.2.5 Create Factory Default Image NOTE: Before creating the factory default image, please configure the system to a factory default environment, including driver and application installations. To create a factory default image, please follow the steps below. Step 1: Turn on the system.
Page 158: Figure D-12: About Symantec Ghost Window
AFL2-12A-HM65 Series Panel PC Figure D-12: About Symantec Ghost Window Step 4: Use mouse to navigate to the option shown below (Figure D-13). Figure D-13: Symantec Ghost Path Step 5: Select the local source drive (Drive 1) as shown in Figure D-14. Then click OK. Page 144...
Page 159: Figure D-14: Select A Local Source Drive
AFL2-12A-HM65 Series Panel PC Figure D-14: Select a Local Source Drive Step 6: Select a source partition (Part 1) from basic drive as shown in Figure D-15. Then click OK. Figure D-15: Select a Source Partition from Basic Drive Step 7: Select 1.2: [Recovery] NTFS drive and enter a file name called (Figure D-16).
Page 160: Figure D-16: File Name To Copy Image To
AFL2-12A-HM65 Series Panel PC Figure D-16: File Name to Copy Image to Step 8: When the Compress Image screen in Figure D-17 prompts, click High to make the image file smaller. Figure D-17: Compress Image Page 146...
Page 161: Figure D-18: Image Creation Confirmation
AFL2-12A-HM65 Series Panel PC Step 9: The Proceed with partition image creation window appears, click Yes to continue. Figure D-18: Image Creation Confirmation Step 10: The Symantec Ghost starts to create the factory default image (Figure D-19). Figure D-19: Creating Image Step 11: When the image creation completes, a screen prompts as shown in Figure D-20.
Page 162: Auto Recovery Setup Procedure
AFL2-12A-HM65 Series Panel PC Step 12: The recovery tool main menu window is shown as below. Press any key to reboot the system. S t e p 0 : Figure D-21: Press Any Key to Continue D.3 Auto Recovery Setup Procedure The auto recovery function allows a system to automatically restore from the factory default image after encountering a Blue Screen of Death (BSoD) or a hang for around 10 minutes.
Page 163: Figure D-22: Auto Recovery Utility
AFL2-12A-HM65 Series Panel PC Step 1: Follow the steps described in Section D.2.1 ~ Section D.2.3 to setup BIOS, create partitions and install operating system. Step 2: Install the auto recovery utility into the system by double clicking the Utility/AUTORECOVERY-SETUP.exe in the One Key Recovery CD. This utility MUST be installed in the system, otherwise, the system will automatically restore from the factory default image every ten (10) minutes.
Page 164: Figure D-24: Launching The Recovery Tool
AFL2-12A-HM65 Series Panel PC Step 4: Reboot the system from the recovery CD. When prompted, press any key to boot from the recovery CD. It will take a while to launch the recovery tool. Please be patient! Figure D-24: Launching the Recovery Tool Step 5: When the recovery tool setup menu appears, press <4>...
Page 165: Figure D-26: Building The Auto Recovery Partition
AFL2-12A-HM65 Series Panel PC Figure D-26: Building the Auto Recovery Partition Step 7: After completing the system configuration, the following message prompts to confirm whether to create a factory default image. Type Y to have the system create a factory default image automatically. Type N within 6 seconds to skip this process (The default option is YES).
Page 166: Figure D-28: Creating Image
AFL2-12A-HM65 Series Panel PC Step 8: The Symantec Ghost starts to create the factory default image (Figure D-28). Figure D-28: Creating Image Step 9: After completing the system configuration, press any key in the following window to restart the system. Figure D-29: Press Any Key to Continue Step 10: Eject the One Key Recovery CD and restart the system.
Page 167: Setup Procedure For Linux
AFL2-12A-HM65 Series Panel PC BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit iEi Feature ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Auto Recovery Function [Enabled] Recover from PXE [Disabled] Select Screen ↑ ↓ Select Item Enter Go to SubScreen General Help Save and Exit Exit v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
Page 168: Figure D-31: Partitions For Linux
AFL2-12A-HM65 Series Panel PC Partition 1: / Partition 2: SWAP NOTE: Please reserve enough space for partition 3 for saving recovery images. Figure D-31: Partitions for Linux Step 3: Create a recovery partition. Insert the recovery CD into the optical disk drive. Follow Step 1 Step 3...
Page 169: Figure D-32: Manual Recovery Environment For Linux
AFL2-12A-HM65 Series Panel PC recovery partition. After completing the system configuration, press any key to reboot the system. Eject the recovery CD. Figure D-32: Manual Recovery Environment for Linux Step 5: Access the recovery tool main menu by modifying the “menu.lst”. To first access the recovery tool main menu, the menu.lst must be modified.
Page 170: Recovery Tool Functions
AFL2-12A-HM65 Series Panel PC Step 7: The recovery tool menu appears. (Figure D-34) Figure D-34: Recovery Tool Menu Step 8: Create a factory default image. Follow Step 2 Step 12 described in Section D.2.5 to create a factory default image. S t e p 0 : D.5 Recovery Tool Functions After completing the initial setup procedures as described above, users can access the...
Page 171: Figure D-35: Recovery Tool Main Menu
AFL2-12A-HM65 Series Panel PC Figure D-35: Recovery Tool Main Menu The recovery tool has several functions including: 1. Factory Restore: Restore the factory default image (iei.GHO) created in Section D.2.5. 2. Backup system: Create a system backup image (iei_user.GHO) which will be saved in the hidden partition.
Page 172: Factory Restore
AFL2-12A-HM65 Series Panel PC D.5.1 Factory Restore To restore the factory default image, please follow the steps below. Step 1: Type <1> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to restore the factory default. A factory default image called iei.GHO is created in the hidden Recovery partition.
Page 173: Backup System
AFL2-12A-HM65 Series Panel PC D.5.2 Backup System To backup the system, please follow the steps below. Step 1: Type <2> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to backup the system. A backup image called iei_user.GHO is created in the hidden Recovery partition.
Page 174: Restore Your Last Backup
AFL2-12A-HM65 Series Panel PC D.5.3 Restore Your Last Backup To restore the last system backup, please follow the steps below. Step 1: Type <3> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to restore the last backup image (iei_user.GHO).
Page 175: Manual
AFL2-12A-HM65 Series Panel PC D.5.4 Manual To restore the last system backup, please follow the steps below. Step 1: Type <4> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears. Use the Ghost program to backup or recover the system manually.
Page 176: Restore Systems From A Linux Server Through Lan
AFL2-12A-HM65 Series Panel PC D.6 Restore Systems from a Linux Server through LAN The One Key Recovery allows a client system to automatically restore to a factory default image saved in a Linux system (the server) through LAN connectivity after encountering a Blue Screen of Death (BSoD) or a hang for around 10 minutes.
Page 177: Configure Dhcp Server Settings
AFL2-12A-HM65 Series Panel PC D.6.1 Configure DHCP Server Settings Step 1: Install the DHCP #yum install dhcp (CentOS, commands marked in red) #apt-get install dhcp3-server (Debian, commands marked in blue) Step 2: Confirm the operating system default settings: dhcpd.conf. CentOS Use the following command to show the DHCP server sample location: #vi /etc/dhcpd.conf The DHCP server sample location is shown as below:...
Page 178: Configure Tftp Settings
AFL2-12A-HM65 Series Panel PC filename “pxelinux.0”; D.6.2 Configure TFTP Settings Step 1: Install the tftp, httpd and syslinux. #yum install tftp-server httpd syslinux (CentOS) #apt-get install tftpd-hpa xinetd syslinux (Debian) Step 2: Enable the TFTP server by editing the “/etc/xinetd.d/tftp” file and make it use the remap file.
Page 179: Configure One Key Recovery Server Settings
AFL2-12A-HM65 Series Panel PC Debian Replace the TFTP settings from “inetd” to “xinetd” and annotate the “inetd” by adding “#”. #vi /etc/inetd.conf Modify: #tftp dgram udp wait root /usr/sbin..(as shown below) #vi /etc/xinetd.d/tftp D.6.3 Configure One Key Recovery Server Settings Step 1: Copy the Utility/RECOVERYR10.TAR.BZ2 package from the One Key Recovery CD to the system (server side).
Page 180: Start The Dhcp, Tftp And Http
AFL2-12A-HM65 Series Panel PC D.6.4 Start the DHCP, TFTP and HTTP Start the DHCP, TFTP and HTTP. For example: CentOS #service xinetd restart #service httpd restart #service dhcpd restart Debian #/etc/init.d/xinetd reload #/etc/init.d/xinetd restart #/etc/init.d/dhcp3-server restart D.6.5 Create Shared Directory Step 1: Install the samba.
Page 181: Setup A Client System For Auto Recovery
AFL2-12A-HM65 Series Panel PC Modify: [image] comment = One Key Recovery path = /share/image browseable = yes writable = yes public = yes create mask = 0644 directory mask = 0755 Step 4: Edit “/etc/samba/smb.conf” for your environment. For example: Step 5: Modify the hostname #vi /etc/hostname...
Page 182: Figure D-43: Disable Automatically Restart
AFL2-12A-HM65 Series Panel PC Figure D-43: Disable Automatically Restart Step 2: Configure the following BIOS options of the client system. Advanced → iEi Feature → Auto Recovery Function → Enabled Advanced → iEi Feature → Recover from PXE → Enabled Boot →...
Page 183 AFL2-12A-HM65 Series Panel PC MUST be installed in the system, otherwise, the system will automatically restore from the factory default image every ten (10) minutes. Step 6: Restart the client system from LAN. If the system encounters a Blue Screen of Death (BSoD) or a hang for around 10 minutes, it will automatically restore from the factory default image.
Page 184: Other Information
AFL2-12A-HM65 Series Panel PC NOTE: A firewall or a SELinux is not in use in the whole setup process described above. If there is a firewall or a SELinux protecting the system, modify the configuration information to accommodate them. D.7 Other Information D.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller When the system uses AHCI mode or some specific SATA controllers such as ALi M5283 or VIA VT6421A, the SATA RAID/AHCI driver must be installed before using one key...
Page 185 AFL2-12A-HM65 Series Panel PC Step 5: When the following window appears, press <S> to select “Specify Additional Device”. Page 171...
Page 186: System Memory Requirement
AFL2-12A-HM65 Series Panel PC Step 6: In the following window, select a SATA controller mode used in the system. Then press <Enter>. The user can now start using the SATA HDD. Step 7: After pressing <Enter>, the system will get into the recovery tool setup menu. Continue to follow the setup procedure from Step 4 in Section D.2.2 Create...
Page 187: E Watchdog Timer
AFL2-12A-HM65 Series Panel PC Appendix Watchdog Timer Page 173...
Page 188 AFL2-12A-HM65 Series Panel PC NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
Page 189 AFL2-12A-HM65 Series Panel PC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BX, 05 ;time-out value is 5 seconds ;...
Page 190: F Hazardous Materials Disclosure
AFL2-12A-HM65 Series Panel PC Appendix Hazardous Materials Disclosure Page 176...
Page 191: Hazardous Material Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury
AFL2-12A-HM65 Series Panel PC F.1 Hazardous Material Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
Page 192 AFL2-12A-HM65 Series Panel PC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery This toxic or hazardous substance is contained in all of the homogeneous materials for the part is below...
Page 193 AFL2-12A-HM65 Series Panel PC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符合中国 RoHS 标准规定的限量要求。本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元件将会单独标示出来。部件名称有毒有害物质或元素铅汞镉六价铬多溴联苯多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体显示印刷电路板金属螺帽电缆组装风扇组装电力供应组装电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。 Page 179...

This manual is also suitable for:

Afl2-12a-hm65 series Afl2-12a-hm65/pc-mf-r11 Afl2-12a-hm65/pc-r11 Afl2-12a-hm65/r-em-r11 Afl2-12a-hm65/r-mf-r11 Afl2-12a-hm65/r-r11 ... Show all

IEI Technology AFL2-12A-HM65/PC-EM-R11 User Manual

Quick Links

Related Manuals for IEI Technology AFL2-12A-HM65/PC-EM-R11

Summary of Contents for IEI Technology AFL2-12A-HM65/PC-EM-R11
