AFL2D-12A-N270-ECIL Panel PC
IEI Technology Corp.
MODEL:
AFL2D-12A-N270-ECIL
Fanless All-in-one Panel PC with 1.6 GHz Intel® Atom™ Processor
Rev. 1.00 - 24 February, 2010
AFL2D-12A-N270-ECIL Flat Panel PC
TFT LCD, Capacitive Touch Screen,
RS-232/422/485 and IP 64 Protection
User Manual
User Manual
Page I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AFL2D-12A-N270-ECIL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology AFL2D-12A-N270-ECIL

Summary of Contents for IEI Technology AFL2D-12A-N270-ECIL

  • Page 1 AFL2D-12A-N270-ECIL Panel PC AFL2D-12A-N270-ECIL Flat Panel PC IEI Technology Corp. MODEL: AFL2D-12A-N270-ECIL Fanless All-in-one Panel PC with 1.6 GHz Intel® Atom™ Processor TFT LCD, Capacitive Touch Screen, RS-232/422/485 and IP 64 Protection User Manual User Manual Page I Rev. 1.00 - 24 February, 2010...
  • Page 2 AFL2D-12A-N270-ECIL Panel PC Revision Date Version Changes 24 February, 2010 1.00 Initial release Page II...
  • Page 3 AFL2D-12A-N270-ECIL Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    AFL2D-12A-N270-ECIL Panel PC Table of Contents 1 INTRODUCTION......................13 1.1 AFL2D-12A-N270-ECIL F PC O ..........14 ANEL VERVIEW 1.1.1 Features ......................15 1.1.2 Applications ..................... 15 1.2 E ....................15 XTERNAL VERVIEW 1.2.1 Front Panel ...................... 15 1.2.2 Rear Panel ....................... 16 1.2.3 I/O Interface Panel ..................
  • Page 5 AFL2D-12A-N270-ECIL Panel PC 2.7.1.1 ATX Power Mode (Default)..............27 2.7.1.2 AT Power Mode ..................28 2.7.2 Power Adapter ....................28 2.7.3 Power Connector ..................... 28 3 UNPACKING ....................... 30 3.1 U ......................31 NPACKING 3.1.1 Packing List ..................... 32 4 INSTALLATION ......................34 4.1 A...
  • Page 6 URN OFF THE OWER 5.4 O ....................62 PENING THE YSTEM 5.4.1 Removing the Back Cover................62 5.4.2 AFL2D-12A-N270-ECIL Internal Aluminum Cover Removal ......62 5.5 R ..................63 EPLACING OMPONENTS 5.5.1 Memory Module Replacement ................. 63 5.5.2 CF Card Replacement..................64 5.6 R...
  • Page 7 AFL2D-12A-N270-ECIL Panel PC 6.5.1 Boot Settings Configuration................95 6.6 S ......................... 98 ECURITY 6.7 C ........................99 HIPSET 6.7.1 North Bridge Chipset Configuration ............... 99 6.7.2 SouthBridge Configuration................102 6.8 E ........................103 7 SOFTWARE DRIVERS .................... 106 7.1 A ................
  • Page 8 AFL2D-12A-N270-ECIL Panel PC HS C 2002/95/EC W ........145 OMPLIANT NDER ITHOUT ERCURY Page VIII...
  • Page 9 AFL2D-12A-N270-ECIL Panel PC List of Figures Figure 1-1: AFL2D-12A-N270-ECIL Flat Panel PC ..............14 Figure 1-2: AFL2D-12A-N270-ECIL Front View ................16 Figure 1-3: AFL2D-12A-N270-ECIL Rear View ................16 Figure 1-4: AFL2D-12A-N270-ECIL I/O Interface Connector Panel..........17 Figure 1-5: Top View........................18 Figure 1-6: Side View........................18 Figure 2-1: AFL2D-12A-N270-ECIL Dimensions (mm) ..............22...
  • Page 10 AFL2D-12A-N270-ECIL Panel PC Figure 4-17: The Rack/Cabinet Bracket..................55 Figure 4-18: Secure the Rack/Cabinet Bracket................55 Figure 4-19: Install into a Rack/Cabinet ..................56 Figure 4-20: LAN Connection ......................57 Figure 4-21: Serial Device Connector..................58 Figure 4-22: USB Device Connection ..................59 Figure 5-1: SO-DIMM Socket Location ..................63 Figure 5-2: DDR SO-DIMM Module Installation................64...
  • Page 11 AFL2D-12A-N270-ECIL Panel PC Figure 7-26: Setup Type – RS-232.................... 125 Figure 7-27: Setup Type – 4-point calibration ................ 125 Figure 7-28: Enable Multi-Monitor Function ................126 Figure 7-29: Destination Location.................... 126 Figure 7-30: Installing PenMount DMC9000................127 Figure 7-31: Installing eGalaxTouch..................127...
  • Page 12 AFL2D-12A-N270-ECIL Panel PC List of Tables Table 1-1: System Specifications....................20 Table 4-1: Jumpers ........................41 Table 4-2: Preconfigured Jumpers .....................42 Table 4-3: Clear CMOS Jumper Settings..................43 Table 4-4: COM1 Pin 9 Setting Jumper Settings ...............44 Table 4-5: COM3 Pin 9 Setting Jumper Settings ...............44 Table 4-6: RS-422 Pinouts ......................45...

  • Page 13: Introduction

    AFL2D-12A-N270-ECIL Panel PC Chapter Introduction Page 13...

  • Page 14: Afl2D-12A-N270-Ecil Flat Panel Pc Overview

    1.1 AFL2D-12A-N270-ECIL Flat Panel PC Overview Figure 1-1: AFL2D-12A-N270-ECIL Flat Panel PC The AFL2D-12A-N270-ECIL is Intel® Atom™ powered flat panel PC with a rich variety of functions and peripherals. The AFL2D-12A-N270-ECIL is designed for easy and simplified integration in to kiosk and point-of-sales (POS) applications.

  • Page 15: Features

    1.2 External Overview 1.2.1 Front Panel The front side of the AFL2D-12A-N270-ECIL is a flat panel TFT LCD screen surrounded by an ABS/PC plastic frame. The top of the front panel has a power LED. A 1D/2D barcode scanner is attached to the bottom.

  • Page 16: Rear Panel

    AFL2D-12A-N270-ECIL Panel PC Figure 1-2: AFL2D-12A-N270-ECIL Front View 1.2.2 Rear Panel The rear panel provides access to retention screw holes that support the wall mounting. Refer to Figure 1-3. Figure 1-3: AFL2D-12A-N270-ECIL Rear View Page 16...

  • Page 17: I/O Interface Panel

    AFL2D-12A-N270-ECIL Panel PC 1.2.3 I/O Interface Panel The I/O interface panel located on the bottom of the AFL2D-12A-N270-ECIL has the following I/O interface connectors: 1 x Audio connector 1 x 12 V DC In connector (connects to barcode scanner) 1 x External SATA connector...

  • Page 18: Top Panel And Side Panels

    AFL2D-12A-N270-ECIL Panel PC 1.2.4 Top Panel and Side Panels The top panel and side panels of AFL2D-12A-N270-ECIL provides access to slots that support panel mount and rack mount (Figure 1-5). Figure 1-5: Top View Figure 1-6: Side View 1.3 Internal Overview...

  • Page 19: System Specifications

    AFL2D-12A-N270-ECIL Panel PC 1.4 System Specifications The technical specifications for the AFL2D-12A-N270-ECIL systems are listed in Table 1-1. Specification AFL2D-12A-N270-ECIL LCD Size 12.1” Max. Resolution 1024 x 768 Contrast Ratio 500:1 Brightness (cd/m LCD Color 262K Pixel Pitch (H x V) (mm) 0.240 x 0.240...

  • Page 20: Table 1-1: System Specifications

    AFL2D-12A-N270-ECIL Panel PC Net weight 1.8 kg IP level (front panel) IP 64 CE, FCC and CCC Safety Touch Screen Capacitive Type 5-wire (touch controller is on board) Power Adapter 50 W Input: 90 VAC ~ 264 VAC @ 47 Hz / 63 Hz...

  • Page 21: Detailed Specifications

    AFL2D-12A-N270-ECIL Panel PC Chapter Detailed Specifications Page 21...

  • Page 22: Dimensions

    AFL2D-12A-N270-ECIL Panel PC 2.1 Dimensions The AFL2D-12A-N270-ECIL dimensions are shown below. 304.0 mm Width: 246.0 mm Height: 49.5 mm Depth: Figure 2-1: AFL2D-12A-N270-ECIL Dimensions (mm) Page 22...

  • Page 23: Intel® Atom™ Processor

    Figure 2-2: Preinstalled DDR2 SO-DIMM 2.3.2 Storage Capacity The AFL2D-12A-N270-ECIL is preinstalled with a 2.0 GB CompactFlash® Type II (CF Type II) memory disk. The AFL2D-12A-N270-ECIL also supports a SATA drive through the external SATA connector on the bottom panel.

  • Page 24: External Peripheral Interface Connectors

    2.4.1 Serial Port Connectors The AFL2D-12A-N270-ECIL has two serial ports. One of these ports (COM1) is RS-232 only port. The other serial port (COM3) can be configured as a RS-232, RS-422 or an RS-485 serial port. Pin 9 on both ports can be set as the normal ring (RI) signal or can be designated as a 5 V or 12 V power supply.

  • Page 25: External Usb Connectors

    2.0 and USB specification Revision 1.1 and can be interfaced to both USB 1.1 and USB 2.0 compliant devices. Figure 2-5: External USB Ports 2.5 AFL2D-12A-N270-ECIL Front Side 2.5.1 Monitor A 12.1” LCD screen is installed on the front of the AFL2D-12A-N270-ECIL. The screen is shown in Figure 2-6 below. Page 25...

  • Page 26: Touch-Screen Module

    AFL2D-12A-N270-ECIL Panel PC Figure 2-6: LCD Screen 2.5.2 Touch-Screen Module A controller for the 5-wire capacitive touch screen is installed on the motherboard. The sensitive touch screen is accurate, reliable and durable. 2.6 Audio 2.6.1 AC’97 Audio Codec Controller The integrated AC’97 Audio compliant audio controller on the Intel® ICH7 Southbridge is integrated to a RealTek ALC655 audio codec.

  • Page 27: Stereo Speakers

    AFL2D-12A-N270-ECIL Panel PC 2.6.2 Stereo Speakers Two internal 1.5 W stereo speakers on the sides of the AFL2D-12A-N270-ECIL are interfaced to the system through a Philips TDA1517p integrated class-B dual output amplifier. Figure 2-8: Stereo Speakers 2.7 System Power 2.7.1 Power Mode The system can be run in the AT power mode or the ATX power mode.

  • Page 28: At Power Mode

    With the AT mode selected, the power is controlled by a central power unit rather than a power switch. The AFL2D-12A-N270-ECIL panel PC turns on automatically when the power is connected. The AT mode benefits a production line to control multiple panel PCs...

  • Page 29: Figure 2-9: Power Connector

    AFL2D-12A-N270-ECIL Panel PC Figure 2-9: Power Connector Page 29...

  • Page 30: Unpacking

    AFL2D-12A-N270-ECIL Panel PC Chapter Unpacking Page 30...

  • Page 31: Unpacking

    AFL2D-12A-N270-ECIL Panel PC 3.1 Unpacking To unpack the flat panel PC, follow the steps below: WARNING! The front side LCD screen has a protective plastic cover stuck to the screen. Only remove the plastic cover after the flat panel PC has been properly installed.

  • Page 32: Packing List

    AFL2D-12A-N270-ECIL Panel PC 3.1.1 Packing List The AFL2D-12A-N270-ECIL flat panel PC is shipped with the following components: Quantity Item Image Standard AFL2D-12A-N270-ECIL panel PC Power adapter Power cord SATA and power cable Screw kit User manual CD and driver CD...
  • Page 33 AFL2D-12A-N270-ECIL Panel PC Wall mounting kit (P/N: AFLWK-12) Stand (P/N:STAND-A12) Stand (P/N:STAND-B19) Stand (P/N: STAND-210-RS) (P/N: ARM-11-RS) (P/N: ARM-31-RS) If any of these items are missing or damaged, contact the distributor or sales representative immediately. Page 33...

  • Page 34: Installation

    AFL2D-12A-N270-ECIL Panel PC Chapter Installation Page 34...

  • Page 35: Anti-Static Precautions

    AFL2D-12A-N270-ECIL and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the AFL2D-12A-N270-ECIL. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the AFL2D-12A-N270-ECIL is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 36: Installation And Configuration Steps

    Over-tightening back cover screws will crack the plastic frame. Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm). To access the AFL2D-12A-N270-ECIL internally the back cover must be removed. To remove the back cover, please follow the steps below.

  • Page 37: Figure 4-1: Disconnect The Power Cable And Usb Cable

    AFL2D-12A-N270-ECIL Panel PC Figure 4-1: Disconnect the Power Cable and USB Cable Figure 4-2: Barcode Scanner Retention Screws Remove the retention screws (Figure 4-3) and lift the cover off the flat panel PC. Step 2: Figure 4-3: Back Cover Retention Screws...

  • Page 38: Hdd Installation

    Step 0: Figure 4-4: AFL2D-12A-N270-ECIL Plastic Back Cover Removal 4.5 HDD Installation To install the HDD into the AFL2D-12A-N270-ECIL, please follow the steps below: Remove the plastic back cover. See Section 4.4 above. Step 1: Remove the aluminum cover. See Section 5.4.2.

  • Page 39: At/Atx Mode Selection

    Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm). 4.6 AT/ATX Mode Selection AT and ATX power modes can both be used on the AFL2D-12A-N270-ECIL. The selection is made through an AT/ATX switch on the aluminum chassis inside the plastic back cover (Figure 4-6).

  • Page 40: At Power Mode

    Manufacturing shop flow 4.6.2 ATX Power Mode With the ATX mode selected, the AFL2D-12A-N270-ECIL panel PC goes in a standby mode when it is turned off. The panel PC can be easily turned on via network or a power switch in standby mode. Remote power control is perfect for advertising applications since the broadcasting time for each panel PC can be set individually and controlled remotely.

  • Page 41: Jumper Settings

    The following jumpers can be found on the motherboard installed in the AFL2D-12A-N270-ECIL. Before the AFL2D-12A-N270-ECIL is installed, the jumpers must be set in accordance with the desired configuration. The jumpers on the AFL2D-12A-N270-ECIL motherboard are listed in Table 4-1.

  • Page 42: Preconfigured Jumpers

    Jumper Location: See Figure 4-7 If the AFL2D-12A-N270-ECIL fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close the pins for a few seconds then remove the jumper clip.

  • Page 43: Com Port Pin 9 Select

    AFL2D-12A-N270-ECIL Panel PC Load Optimal Defaults Load Failsafe Defaults. After having done one of the above, save the changes and exit the CMOS Setup menu. The clear CMOS jumper settings are shown in Table 4-3. Clear CMOS Description Short 1 - 2...

  • Page 44: Com3 Rs-422 And Rs-485 Pinouts

    AFL2D-12A-N270-ECIL Panel PC Description Short 1-3 COM1 RI Pin use +12 V Short 5-7 COM1 RI Pin use +5 V Short 7-9 COM1 RI Pin use RI Default Table 4-4: COM1 Pin 9 Setting Jumper Settings JP10 Description Short 1-2...

  • Page 45: Com3 Rx Function Select Jumper

    AFL2D-12A-N270-ECIL Panel PC COM 3 RS-422 Description Pin 1 Pin 2 Pin 6 Pin 7 Table 4-6: RS-422 Pinouts COM 3 RS-485 Description Pin 1 Data- Pin 2 Data+ Table 4-7: RS-485 Pinouts 4.7.5 COM3 RX Function Select Jumper Jumper Label:...

  • Page 46: Com3 Tx Function Select Jumper

    AFL2D-12A-N270-ECIL Panel PC Figure 4-9: COM3 RX Function Select Jumper Location 4.7.6 COM3 TX Function Select Jumper Jumper Label: JP11 Jumper Type: 6-pin header See Table 4-9 Jumper Settings: Jumper Location: See Figure 4-10 The COM3 TX Function Select jumper configures the TX pin on COM3 serial port connector as RS-422 as an RS-485.

  • Page 47: Com3 Rs-232/422/485 Serial Port Select Jumper

    AFL2D-12A-N270-ECIL Panel PC Figure 4-10: COM3 TX Function Select Jumper Pinout Locations 4.7.7 COM3 RS-232/422/485 Serial Port Select Jumper Jumper Label: Jumper Type: 12-pin header (four 3-pin headers combined) See Table 4-10 Jumper Settings: Jumper Location: See Figure 4-11 The COM3 RS-232/422/485 Serial Port Select jumper sets the communication protocol used by the second serial communications port (COM3) as RS-232, RS-422 or RS-485.

  • Page 48: Mounting The System

    PC does not fall down and get damaged. The four methods of mounting the AFL2D-12A-N270-ECIL are listed below. Wall mounting...

  • Page 49: Wall Mounting

    AFL2D-12A-N270-ECIL Panel PC 4.8.1 Wall Mounting To mount the flat panel PC onto the wall, please follow the steps below. Select the location on the wall for the wall-mounting bracket. Step 1: Carefully mark the locations of the four screw holes in the bracket on the wall.
  • Page 50 AFL2D-12A-N270-ECIL Panel PC Insert the four monitor mounting screws provided in the wall mount kit into the Step 6: four screw holes on the real panel of the flat panel PC and tighten until the screw shank is secured against the rear panel (Figure 4-13).

  • Page 51: Figure 4-13: Chassis Support Screws

    AFL2D-12A-N270-ECIL Panel PC Figure 4-13: Chassis Support Screws Secure the panel PC by fastening the retention screw of the wall-mounting Step 9: bracket. (Figure 4-14). Step 0: Figure 4-14: Secure the Panel PC Page 51...

  • Page 52: Panel Mounting

    AFL2D-12A-N270-ECIL Panel PC 4.8.2 Panel Mounting To mount the AFL2D-12A-N270-ECIL flat panel PC into a panel, please follow the steps below. Select the position on the panel to mount the flat panel PC. Step 1: Cut out a section from the panel that corresponds to the rear panel dimensions Step 2: of the flat panel PC.

  • Page 53: Arm Mounting

    75mm and 100mm interface pad. To mount the AFL2D-12A-N270-ECIL on an arm, please follow the steps below. The arm is a separately purchased item. Please correctly mount the arm onto Step 1: the surface it uses as a base.

  • Page 54: Cabinet And Rack Installation

    PC. Step 0: 4.8.4 Cabinet and Rack Installation The AFL2D-12A-N270-ECIL flat panel PC can be installed into a cabinet or rack. The installation procedures are similar to the panel mounting installation. To do this, please follow the steps below:...

  • Page 55: Figure 4-17: The Rack/Cabinet Bracket

    AFL2D-12A-N270-ECIL Panel PC Figure 4-17: The Rack/Cabinet Bracket Insert the rack mounting clamps into the pre-formed holes along the edges of Step 2: the flat panel PC, behind the ABS/PC plastic frame. There are a total of 6 rack mounting clamps.

  • Page 56: Bottom Panel Connectors

    AFL2D-12A-N270-ECIL Panel PC Slide the flat panel PC with the attached rack/cabinet bracket into a rack or Step 4: cabinet (Figure 4-19). Figure 4-19: Install into a Rack/Cabinet Once the flat panel PC with the attached rack/cabinet bracket has been properly...

  • Page 57: Serial Device Connection

    RJ-45 connector into the onboard RJ-45 connector. Step 0: 4.9.2 Serial Device Connection The AFL2D-12A-N270-ECIL has two male DB-9 connectors on the bottom panel for serial devices to be connected. Follow the steps below to connect a serial device to the AFL2D-12A-N270-ECIL panel PC.

  • Page 58: Figure 4-21: Serial Device Connector

    AFL2D-12A-N270-ECIL Panel PC Figure 4-21: Serial Device Connector Secure the connector. Secure the serial device connector to the external Step 3: interface by tightening the two retention screws on either side of the connector. Step 0: Page 58...

  • Page 59: Usb Device Connection

    4.9.3 USB Device Connection There are two external USB 2.0 connectors. All connectors are perpendicular to the AFL2D-12A-N270-ECIL. To connect a USB 2.0 or USB 1.1 device, please follow the instructions below. Located the USB connectors. The locations of the USB connectors are shown Step 1: in Chapter 2.

  • Page 60: System Maintenance

    AFL2D-12A-N270-ECIL Panel PC Chapter System Maintenance Page 60...

  • Page 61: System Maintenance Introduction

    AFL2D-12A-N270-ECIL Panel PC 5.1 System Maintenance Introduction If the components of the AFL2D-12A-N270-ECIL fail they must be replaced. Components that can be replaced include: CF Module SO-DIMM module Please contact the system reseller or vendor to purchase the replacement parts. Back cover removal instructions for the AFL2D-12A-N270-ECIL are described below.

  • Page 62: Turn Off The Power

    Over-tightening back cover screws will crack the plastic frame. Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm). To access the AFL2D-12A-N270-ECIL internally the back cover must be removed. To remove the back cover, please follow the steps below.

  • Page 63: Replacing Components

    AFL2D-12A-N270-ECIL Panel PC 5.5 Replacing Components 5.5.1 Memory Module Replacement The flat panel PC is preinstalled with a 2.0 GB DDR2 memory module. If the memory module is fail, follow the instructions below to replace the memory module. Remove the back cover. See Section 5.4.1 above.

  • Page 64: Cf Card Replacement

    DDR memory module in the socket.Step 0: Figure 5-2: DDR SO-DIMM Module Installation 5.5.2 CF Card Replacement The AFL2D-12A-N270-ECIL has one CF Type II slot. To replace the CF card, follow the instructions below. Follow all anti-static procedures. See Section 5.2. Step 1: Turn off the power.

  • Page 65: Reinstalling The Covers

    AFL2D-12A-N270-ECIL Panel PC Figure 5-3: CF Card Location Replace the plastic back cover (Figure 5-4). Step 5: Figure 5-4: Plastic Back Cover Replacement Once replaced reinsert the nine previously removed retention screws. Step 6: Step 0: 5.6 Reinstalling the Covers...

  • Page 66: Ami Bios Setup

    AFL2D-12A-N270-ECIL Panel PC Chapter AMI BIOS Setup Page 66...

  • Page 67: Introduction

    AFL2D-12A-N270-ECIL Panel PC 6.1 Introduction A licensed copy of AMI BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.

  • Page 68: Getting Help

    AFL2D-12A-N270-ECIL Panel PC F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 6-1: BIOS Navigation Keys 6.1.3 Getting Help...

  • Page 69: Main

    AFL2D-12A-N270-ECIL Panel PC 6.2 Main The Main BIOS menu ( B IOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS Menu 1: Main System Overview The System Overview lists a brief summary of different system components. The fields in System Overview cannot be changed.

  • Page 70: Advanced

    AFL2D-12A-N270-ECIL Panel PC The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.

  • Page 71: Cpu Configuration

    AFL2D-12A-N270-ECIL Panel PC BIOS Menu 2: Advanced 6.3.1 CPU Configuration Use the CPU Configuration menu ( B IOS Menu 3) to view detailed CPU specifications and configure the CPU. BIOS Menu 3: CPU Configuration Page 71...

  • Page 72: Ide Configuration

    AFL2D-12A-N270-ECIL Panel PC The CPU Configuration menu (BIOS Menu 3) lists the following CPU details: Manufacturer: Lists the name of the CPU manufacturer Brand String: Lists the brand name of the CPU being used Frequency: Lists the CPU processing speed...

  • Page 73: Legacy Ide Channels [Pata Pri, Sata Sec]

    AFL2D-12A-N270-ECIL Panel PC compatible mode. In this mode, a SATA channel will replace one of the IDE channels. This mode supports up to 4 storage devices. Configures the on-board ATA/IDE controller to be in Enhanced Enhanced mode. In this mode, IDE channels and SATA channels are separated.

  • Page 74: Ide Master, Ide Slave

    AFL2D-12A-N270-ECIL Panel PC 6.3.2.1 IDE Master, IDE Slave Use the IDE Master and IDE Slave configuration menu to view both primary and secondary IDE device details and configure the IDE devices connected to the system. BIOS Menu 5: IDE Master and IDE Slave Configuration Auto-Detected Drive Parameters The “grayed-out”...

  • Page 75: Type [Auto]

    AFL2D-12A-N270-ECIL Panel PC LBA Mode: Indicates whether the LBA (Logical Block Addressing) is a method of addressing data on a disk drive is supported or not. Block Mode: Block mode boosts IDE drive performance by increasing the amount of data transferred. Only 512 bytes of data can be transferred per interrupt if block mode is not used.

  • Page 76: Lba/Large Mode [Auto]

    AFL2D-12A-N270-ECIL Panel PC LBA/Large Mode [Auto] Use the LBA/Large Mode option to disable or enable BIOS to auto detects LBA (Logical Block Addressing). LBA is a method of addressing data on a disk drive. In LBA mode, the maximum drive capacity is 137 GB.

  • Page 77: Dma Mode [Auto]

    AFL2D-12A-N270-ECIL Panel PC PIO mode 3 selected with a maximum transfer rate of 11.1MBps PIO mode 4 selected with a maximum transfer rate of 16.6MBps (This setting generally works with all hard disk drives manufactured after 1999. For other disk drives, such as IDE CD-ROM drives, check the specifications of the drive.)

  • Page 78: Super Io Configuration

    AFL2D-12A-N270-ECIL Panel PC rate of 44MBps (To use this mode, it is required that an 80-conductor ATA cable is used.) Ultra DMA mode 4 selected with a maximum data transfer UDMA4 rate of 66.6MBps (To use this mode, it is required that an 80-conductor ATA cable is used.)

  • Page 79: Serial Port1 Address [3F8/Irq4]

    AFL2D-12A-N270-ECIL Panel PC BIOS Menu 6: Super IO Configuration Serial Port1 Address [3F8/IRQ4] Use the Serial Port1 Address option to select the Serial Port 1 base address. No base address is assigned to Serial Port 1 Disabled Serial Port 1 I/O port address is 3F8 and the interrupt...

  • Page 80: Serial Port3 Address [3E8]

    AFL2D-12A-N270-ECIL Panel PC Serial Port 1 mode is normal Normal EFAULT Serial Port 1 mode is IrDA IrDA Serial Port 1 mode is ASK IR ASK IR Serial Port3 Address [3E8] Use the Serial Port3 Address option to select the Serial Port 3 base address.

  • Page 81: Hardware Health Configuration

    AFL2D-12A-N270-ECIL Panel PC 6.3.4 Hardware Health Configuration The Hardware Health Configuration menu ( B IOS Menu 7) shows the operating temperature, fan speeds and system voltages. BIOS Menu 7: Hardware Health Configuration CPU FAN Mode Setting [Full On Mode] Use the CPU FAN Mode Setting option to configure the second fan.

  • Page 82: Cpu Temp. Limit Of Off [000]

    AFL2D-12A-N270-ECIL Panel PC CPU Temp. Limit of Start CPU Fan Start PWM Slope PWM When the CPU FAN Mode Setting option is in the PWM Manual Mode, the following parameters can be set. CPU Fan PWM control CPU Temp. Limit of OFF [000]...

  • Page 83: Cpu Fan Start Pwm [070]

    AFL2D-12A-N270-ECIL Panel PC The CPU Temp. Limit of Start option can only be set if the CPU FAN Mode Setting option is set to Automatic Mode. Use the CPU Temp. Limit of Start option to select the CPU temperature at which the cooling fan should automatically turn on. When the fan starts, it rotates using the starting pulse width modulation (PWM) specified in the Fan 3 Start PWM option below.

  • Page 84: Power Configuration

    AFL2D-12A-N270-ECIL Panel PC 15 PWM The following system parameters and values are shown. The system parameters that are monitored are: System Temperatures: The following system temperatures are monitored CPU Temperature System Temperature Fan Speeds: The CPU cooling fan speed is monitored.

  • Page 85: Acpi Configuration

    AFL2D-12A-N270-ECIL Panel PC BIOS Menu 8: Power Configuration 6.3.5.1 ACPI configuration The ACPI Configuration menu ( B IOS Menu 9) configures the Advanced Configuration and Power Interface (ACPI). BIOS Menu 9: ACPI Configuration Page 85...

  • Page 86: Apm Configuration

    AFL2D-12A-N270-ECIL Panel PC Suspend Mode [S1(POS)] Use the Suspend Mode BIOS option to specify the sleep state the system enters when it is not being used. System appears off. The CPU is stopped; RAM is S1 (POS) EFAULT refreshed; the system is running in a low power mode.

  • Page 87: Power Button Mode [On/Off]

    AFL2D-12A-N270-ECIL Panel PC The system remains turned off Power Off The system turns on Power On The system returns to its previous state. If it was on, it Last State EFAULT turns itself on. If it was off, it remains off.

  • Page 88: Remote Configuration

    AFL2D-12A-N270-ECIL Panel PC Wake event not generated by an incoming call Disabled EFAULT Wake event generated by an incoming call Enabled Resume on PCI-Express WAKE# [Enabled] Use the Resume PCI-Express WAKE# BIOS option to enable activity on the PCI-Express WAKE# signal to rouse the system from a suspend or standby state.

  • Page 89: Remote Access [Disabled]

    AFL2D-12A-N270-ECIL Panel PC BIOS Menu 11: Remote Access Configuration [Advanced] Remote Access [Disabled] Use the Remote Access option to enable or disable access to the remote functionalities of the system. Remote access is disabled. Disabled EFAULT Remote access configuration options shown below...

  • Page 90: Serial Port Number [Com1]

    AFL2D-12A-N270-ECIL Panel PC Serial Port Number [COM1] Use the Serial Port Number option allows to select the serial port used for remote access. System is remotely accessed through COM1 COM1 EFAULT System is remotely accessed through COM2 COM2 System is remotely accessed through COM3...

  • Page 91: Usb Configuration

    AFL2D-12A-N270-ECIL Panel PC The console is not redirected after POST Disabled Redirection is active during POST and during Boot Boot Loader Loader Redirection is always active (Some OSes may not Always EFAULT work if set to Always) Terminal Type [ANSI] Use the Terminal Type BIOS option to specify the remote terminal type.

  • Page 92: Usb Functions [Enabled]

    AFL2D-12A-N270-ECIL Panel PC USB Functions [Enabled] Use the USB Function option to enable or disable the USB controllers. USB controllers are enabled Disabled USB controllers are disabled Enabled EFAULT USB 2.0 Controller [Enabled] The USB 2.0 Controller BIOS option enables or disables the USB 2.0 controller...

  • Page 93: Pci/Pnp

    AFL2D-12A-N270-ECIL Panel PC The controller is capable of operating at high speed HiSpeed EFAULT 480 Mb/s 6.4 PCI/PnP Use the PCI/PnP menu ( B IOS Menu 13) to configure advanced PCI and PnP settings. WARNING: Setting wrong values for the BIOS selections in the PCIPnP BIOS menu may cause the system to malfunction.

  • Page 94: Dma Channel# [Available]

    AFL2D-12A-N270-ECIL Panel PC The specified IRQ is reserved for use by Legacy ISA Reserved devices Available IRQ addresses are: IRQ3 IRQ4 IRQ5 IRQ7 IRQ9 IRQ10 IRQ 11 IRQ 14 IRQ 15 DMA Channel# [Available] Use the DMA Channel# option to assign a specific DMA channel to a particular PCI/PnP device.

  • Page 95: Boot

    AFL2D-12A-N270-ECIL Panel PC Reserved Memory Size [Disabled] Use the Reserved Memory Size BIOS option to specify the amount of memory that should be reserved for legacy ISA devices. No memory block reserved for legacy ISA devices Disabled EFAULT 16KB reserved for legacy ISA devices...

  • Page 96: Quick Boot [Enabled]

    AFL2D-12A-N270-ECIL Panel PC BIOS Menu 15: Boot Settings Configuration Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process. No POST procedures are skipped Disabled Some POST procedures are skipped to decrease...

  • Page 97: Addon Rom Display Mode [Force Bios]

    AFL2D-12A-N270-ECIL Panel PC AddOn ROM Display Mode [Force BIOS] The AddOn ROM Display Mode option allows add-on ROM (read-only memory) messages to be displayed. Allows the computer system to force a third party Force BIOS EFAULT BIOS to display during system boot.

  • Page 98: Security

    AFL2D-12A-N270-ECIL Panel PC 6.6 Security Use the Security menu ( B IOS Menu 16) to set system and user passwords. BIOS Menu 16: Security Change Supervisor Password Use the Change Supervisor Password to set or change a supervisor password. The default for this option is Not Installed.

  • Page 99: Chipset

    AFL2D-12A-N270-ECIL Panel PC 6.7 Chipset Use the Chipset menu ( B IOS Menu 17) to access the NorthBridge and SouthBridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 100: Memory Hole [Disabled]

    AFL2D-12A-N270-ECIL Panel PC BIOS Menu 18:North Bridge Chipset Configuration Memory Hole [Disabled] The Memory Hole reserves the memory space between 15MB and 16MB for ISA expansion cards that require a specified area of memory to work properly. If an older ISA expansion card is used, please refer to the documentation that came with the card to see if it is necessary to reserve the space.

  • Page 101: Dvmt Mode Select [Dvmt Mode]

    AFL2D-12A-N270-ECIL Panel PC DVMT Mode Select [DVMT Mode] Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology (DVMT) operating mode. A fixed portion of graphics memory is reserved as Fixed Mode graphics memory. Graphics memory...

  • Page 102: Southbridge Configuration

    AFL2D-12A-N270-ECIL Panel PC Sec. Display Device [CRT] Use the Sec. Display Device option to select the second display device used by the system. Configuration options are listed below. Disabled EFAULT LFP Panel Type [by H/W] Use the LFP Panel Type option to select the type of flat panel connected to the system.

  • Page 103: Exit

    AFL2D-12A-N270-ECIL Panel PC BIOS Menu 19: SouthBridge Chipset Configuration Audio Controller [AC’97 Audio Only] The Audio Controller option enables or disables the audio controller. The on-board AC’97 audio controller is enabled. AC’97 Audio Only The on-board audio controller is disabled.
  • Page 104 AFL2D-12A-N270-ECIL Panel PC BIOS Menu 20:Exit Save Changes and Exit Use the Save Changes and Exit option to save the changes made to the BIOS options and to exit the BIOS configuration setup program. Discard Changes and Exit Use the Discard Changes and Exit option to exit the BIOS configuration setup program without saving the changes made to the system.
  • Page 105 AFL2D-12A-N270-ECIL Panel PC Load Failsafe Defaults Use the Load Failsafe Defaults option to load failsafe default values for each of the parameters on the Setup menus. F8 key can be used for this operation. Page 105...

  • Page 106: Software Drivers

    AFL2D-12A-N270-ECIL Panel PC Chapter Software Drivers Page 106...

  • Page 107: Available Software Drivers

    NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updates. The following drivers can be installed on the system:...

  • Page 108: Chipset Driver Installation

    AFL2D-12A-N270-ECIL Panel PC Figure 7-1: Drivers 7.3 Chipset Driver Installation To install the chipset driver, please do the following. Access the driver list shown in Figure 7-1. (See Section 7.2) Step 1: Click “Chipset” and double click “Setup.exe”. Step 2: The setup files are extracted as shown in Figure 7-2.

  • Page 109: Figure 7-2: Chipset Driver Screen

    AFL2D-12A-N270-ECIL Panel PC Figure 7-2: Chipset Driver Screen When the setup files are completely extracted the Welcome Screen in Figure Step 4: 7-3 appears. Figure 7-3: Chipset Driver Welcome Screen Click Next to continue. Step 5: Page 109...

  • Page 110: Figure 7-4: Chipset Driver License Agreement

    AFL2D-12A-N270-ECIL Panel PC The license agreement in Figure 7-4 appears. Step 6: Read the License Agreement. Step 7: Click the Yes icon to continue. Step 8: Figure 7-4: Chipset Driver License Agreement The Read Me file in Figure 7-5 appears.

  • Page 111: Figure 7-5: Chipset Driver Read Me File

    AFL2D-12A-N270-ECIL Panel PC Figure 7-5: Chipset Driver Read Me File Setup Operations are performed as shown in Figure 7-6. Step 11: Page 111...

  • Page 112: Figure 7-6: Chipset Driver Setup Operations

    AFL2D-12A-N270-ECIL Panel PC Figure 7-6: Chipset Driver Setup Operations Once the Setup Operations are complete, click the Next icon to continue. Step 12: The Finish screen appears. Step 13: Select “Yes, I want to restart the computer now” and click the Finish icon.

  • Page 113: Vga Driver Installation

    AFL2D-12A-N270-ECIL Panel PC Figure 7-7: Chipset Driver Installation Finish Screen 7.4 VGA Driver Installation To install the VGA driver, please do the following. Access the driver list shown in Figure 7-1. (See Section 7.2) Step 1: Click “VGA” and double click the “win2k_xp14324.exe” file.

  • Page 114: Figure 7-8: Vga Driver Read Me File

    AFL2D-12A-N270-ECIL Panel PC Figure 7-8: VGA Driver Read Me File The installation files are extracted. See Figure 7-9. Step 5: Figure 7-9: VGA Driver Setup Files Extracted The Welcome Screen in Figure 7-10 appears. Step 6: Page 114...

  • Page 115: Figure 7-10: Vga Driver Welcome Screen

    AFL2D-12A-N270-ECIL Panel PC Figure 7-10: VGA Driver Welcome Screen Click Next to continue. Step 7: The license agreement in Figure 7-11 appears. Step 8: Read the License Agreement. Step 9: Click the Yes icon to continue. Step 10: Page 115...

  • Page 116: Figure 7-11: Vga Driver License Agreement

    AFL2D-12A-N270-ECIL Panel PC Figure 7-11: VGA Driver License Agreement The Read Me file in Figure 7-12 appears. Step 11: Click Next to continue. Step 12: Figure 7-12: VGA Driver Read Me File Setup Operations are performed as shown in Figure 7-13.

  • Page 117: Figure 7-13: Vga Driver Setup Operations

    AFL2D-12A-N270-ECIL Panel PC Figure 7-13: VGA Driver Setup Operations Once the Setup Operations are complete, click the Next icon to continue. Step 14: The Finish screen appears. Step 15: Select “Yes, I want to restart the computer now” and click the Finish icon.

  • Page 118: Audio Driver Installation

    AFL2D-12A-N270-ECIL Panel PC 7.5 Audio Driver Installation To install the audio driver, please do the following. Access the driver list shown in Figure 7-1. (See Section 7.2) Step 1: Click “Audio” Step 2: The screen in Figure 7-15 appears. Double click the “WDM_A404” folder.

  • Page 119: Figure 7-16: Ac'97 Driver Installation Welcome Screen

    AFL2D-12A-N270-ECIL Panel PC Figure 7-16: AC’97 Driver Installation Welcome Screen The Verification window in Figure 7-17 may appear. Step 7: Click “Continue Anyway.” Step 8: Figure 7-17: AC’97 Driver Installation Verification The driver installation begins. See Figure 7-18. Step 9:...

  • Page 120: Lan Driver Installation

    AFL2D-12A-N270-ECIL Panel PC Figure 7-18: AC’97 Driver Installation When the driver is installed, the driver installation finish screen in Figure 7-19 Step 10: appears. Select “Yes, I wish to restart my computer now” And click Finish Step 11: Figure 7-19: AC’97 Driver Installation Complete The system reboots.Step 0:...

  • Page 121: Figure 7-20: Lan Driver Welcome Screen

    AFL2D-12A-N270-ECIL Panel PC Click “LAN” and locate the setup.exe. Double click the setup.exe file to start Step 2: installing the LAN driver. The Welcome screen in Figure 7-20 appears. Step 3: Figure 7-20: LAN Driver Welcome Screen Click Next to continue.

  • Page 122: Figure 7-21: Lan Driver Welcome Screen

    AFL2D-12A-N270-ECIL Panel PC Figure 7-21: LAN Driver Welcome Screen The program begins to install. Step 7: The installation progress can be monitored in the progress bar shown in Figure Step 8: 7-22. Figure 7-22: LAN Driver Installation Page 122...

  • Page 123: Touch Screen Driver

    AFL2D-12A-N270-ECIL Panel PC When the driver installation is complete, the screen in Figure 7-23 appears. Step 9: Step 0: Figure 7-23: LAN Driver Installation Complete 7.7 Touch Screen Driver To install the touch panel software driver, please follow the steps below.

  • Page 124: Figure 7-24: Welcome Screen

    AFL2D-12A-N270-ECIL Panel PC Figure 7-24: Welcome Screen The PS/2 Setup Type screen in Figure 7-25 appears. Check the box if it is for Step 4: PS/2 touch controller. Figure 7-25: Setup Type – PS/2 The RS-232 Setup Type screen in Figure 7-26 appears. Check the box if it is for Step 5: RS-232 touch controller.

  • Page 125: Figure 7-26: Setup Type - Rs-232

    AFL2D-12A-N270-ECIL Panel PC Figure 7-26: Setup Type – RS-232 The 4-point Calibration Setup screen in Figure 7-27 appears. Select an option Step 6: on how you would like system to do after reboot. Figure 7-27: Setup Type – 4-point calibration The Multi-Monitor Setup screen in Figure 7-28 appears.

  • Page 126: Figure 7-28: Enable Multi-Monitor Function

    AFL2D-12A-N270-ECIL Panel PC Figure 7-28: Enable Multi-Monitor Function The Choose Destination Location screen in Figure 7-29 appears next. Step 8: Confirm the destination folder by clicking Next. Figure 7-29: Destination Location Select an existing folder or create a new folder for the program (Figure 7-30).

  • Page 127: Figure 7-30: Installing Penmount Dmc9000

    AFL2D-12A-N270-ECIL Panel PC Figure 7-30: Installing PenMount DMC9000 Start to install the eGalaxTouch (Figure 7-31). Close the installation window Step 10: when it is finished. Step 0: Figure 7-31: Installing eGalaxTouch Page 127...

  • Page 128: A System Specifications

    AFL2D-12A-N270-ECIL Panel PC Appendix System Specifications Page 128...

  • Page 129: Motherboard Specifications

    AFL2D-12A-N270-ECIL Panel PC A.1 Motherboard Specifications The system comes with an IEI AFLMB-945GSE motherboard. The detailed specifications for the motherboard are listed below. Specification AFLMB-945GSE Northbridge Intel® 945GSE Southbridge Intel® ICH7 Processor 1.6 GHz Intel® Atom™ N270 processor FSB Speed...

  • Page 130: Screen Specifications

    Thermal Design Power 2.5 W Tjunction 0 to 90°C A.3 Screen Specifications The AFL2D-12A-N270-ECIL comes with a TFT LCD monitor at the front of the flat panel PC. Specifications for the screens are shown below. SPECIFICATION AFL2D-12A-N270-ECIL Model Toshiba PI-LTA121C250F Size 12.1”...

  • Page 131: Barcode Scanner Specifications

    AFL2D-12A-N270-ECIL Panel PC A.4 Barcode Scanner Specifications The AFL2D-12A-N270-ECIL comes with an barcode scanner. The barcode scanner specifications are listed below. SPECIFICATION Model AFL2D-12-R11 Image Sensor CMOS, 1.3 mega pixel Decode Capability 1D: Code 39, Code 93, Code 128, UPC/EAN/JAN, Code 2 of 5,...

  • Page 132: B Safety Precautions

    AFL2D-12A-N270-ECIL Panel PC Appendix Safety Precautions Page 132...

  • Page 133: Safety Precautions

    Do not apply voltage levels that exceed the specified voltage range. Doing so may cause fire and/or an electrical shock. Electric shocks can occur if the AFL2D-12A-N270-ECIL chassis is opened when the AFL2D-12A-N270-ECIL is running. Do not drop or insert any objects into the ventilation openings of the AFL2D-12A-N270-ECIL.

  • Page 134: Anti-Static Precautions

    B.2 Maintenance and Cleaning Precautions When maintaining or cleaning the AFL2D-12A-N270-ECIL, please follow the guidelines below. B.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the AFL2D-12A-N270-ECIL, please read the details below. Page 134...

  • Page 135: Cleaning Tools

    AFL2D-12A-N270-ECIL. B.2.2 Cleaning Tools Some components in the AFL2D-12A-N270-ECIL may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the AFL2D-12A-N270-ECIL.
  • Page 136 AFL2D-12A-N270-ECIL Panel PC Foam swabs - Whenever possible, it is best to use lint free swabs such as foam swabs for cleaning. Page 136...

  • Page 137: C Bios Configuration Options

    AFL2D-12A-N270-ECIL Panel PC Appendix BIOS Configuration Options Page 137...

  • Page 138: C.1 Bios C Onfiguration O Ptions

    AFL2D-12A-N270-ECIL Panel PC BIOS Configuration Options Below is a list of BIOS configuration options described in Chapter 6. 　 System Overview .........................69 　 System Time [xx:xx:xx] .......................70 　 System Date [xx/xx/xx] ......................70 　 ATA/IDE Configurations [Compatible]................72 　 Legacy IDE Channels [PATA Pri, SATA Sec] ..............73 　...
  • Page 139 AFL2D-12A-N270-ECIL Panel PC 　 Resume on Ring [Disabled] ....................87 　 Resume on PCI-Express WAKE# [Enabled]..............88 　 Resume On RTC Alarm [Disabled]..................88 　 RTC Alarm Date (Days)......................88 　 System Time .........................88 　 Remote Access [Disabled]....................89 　 Serial Port Number ......................89 　...
  • Page 140 AFL2D-12A-N270-ECIL Panel PC 　 LFP Panel Type [by H/W]....................102 　 Audio Controller [AC’97 Audio Only]................103 　 Save Changes and Exit ....................104 　 Discard Changes and Exit....................104 　 Discard Changes....................... 104 　 Load Optimal Defaults...................... 104 　...

  • Page 141: D Watchdog Timer

    AFL2D-12A-N270-ECIL Panel PC Appendix Watchdog Timer Page 141...
  • Page 142 NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.

  • Page 143: Example Program

    AFL2D-12A-N270-ECIL Panel PC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BX, 05 ;time-out value is 5 seconds ;...

  • Page 144: E Hazardous Materials Disclosure

    AFL2D-12A-N270-ECIL Panel PC Appendix Hazardous Materials Disclosure Page 144...

  • Page 145: Hazardous Material Disclosure Table For Ipb Products Certified As

    AFL2D-12A-N270-ECIL Panel PC E.1 Hazardous Material Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 146 AFL2D-12A-N270-ECIL Panel PC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
  • Page 147 AFL2D-12A-N270-ECIL Panel PC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

Table of Contents
