OVERVIEW TERMINAL
Contactless Paper roll holder
reader
Date, time and
Wifi/GPRS
battery indicator
indicator
Keyboard
Function key
shortcuts
F1 F2 F3 F4
Stop key
Cancel key
OK key
Paperfeed
INSTALLATION OF YOUR TERMINAL
Push the grey key
1.
2. Select "Tech Menu"
3. Then "Settings Menu"
4. Enter Settings password: 2009 and push the green key
and push the green key
5. Select "WiFi settings"
and push the green key
6. Select "Scan for Networks"
7. Select your network
8. Enter the password of the WiFi network and push the green key
Push the red key to return to the home screen. Your terminal is
9.
ready to be used
MAKE A PAYMENT
Push the OK key
1.
Enter the amount and confirm with OK key
2.
3. Hand the terminal over to the customer
4.
Use your payment card
Confirm PIN (if asked)
5.
Reclaim the terminal and confirm with OK
6.
Give the first ticket to the client
7.
8.
The second ticket is for the merchant
ALTERNATIVE
Push the keyboard shortcut F1
1.
and follow the steps above
2.
Select "payment"
USE A PAYMENT CARD
1. With the chip 2. Pay contactless
With the magnetic strip
3.
PERFORM A CANCELLATION
1.
Push the shortcut F1 on the screen
2. Select "Cancellation Menu"
3. Enter Manager password: 2580 and push the OK key
4. Select again "Cancellation"
Enter the amount and confirm with the OK key
5.
Enter the authorisation code you can find on the receipt
6.
(Auth. Code). Confirm with the OK key
Do not enter a token and push again the OK key
7.
8.
Hand the terminal over to the customer
9. Use payment card
The first receipt is for the client
10.
Reclaim the terminal and push the OK key
11.
12.
The second receipt is for the merchant
PERFORM A REFUND
1. Push the shortcut F1 on the screen
2. Select "Refund"
Enter Manager password: 2580 and push the OK key
3.
Enter the amount and confirm with the OK key
4.
5. Hand the terminal over to the customer
6. Use payment card
7. The first receipt is for the customer
8. Reclaim the terminal and confirm with OK
9. The second receipt is for the merchant
Push the OK key
10.
11. A third receipt is printed
KEYBOARD SHORTCUT F4
You can use this key to:
1. Print a copy of the last transaction
2. Request the result of the last transaction (not printed)
Print current transactions, without closing the day
3.
(no reset / X-totals)
4. Print current transactions with a day closure
(reset / Z-totals)
SOFT RESET OF YOUR TERMINAL
1. Push the point key
and the cancel key simultaneously
2.
The terminal switches itself off
Reboot the terminal with the OK key and wait until the
3.
terminal is fully rebooted
HARD RESET OF YOUR TERMINAL
1. Remove the cover
Remove the battery and wait for 30 seconds
2.
Place the battery and the cover back
3.
Reboot the terminal with the OK key and wait until the
4.
terminal is fully rebooted
