TERMINAL OVERVIEW
Bluetooth
Colour screen
Keyboard
shortcuts
INSTALLATION OF YOUR TERMINAL
Check the following points before making a Bluetooth
connection between your smartphone and card reader:
1. Did you install the Mypaydesk app?
2. Is the card reader charged?
3. Is your smartphone switched on?
4. Do you have a good internet connection?
CONNECT WITH AN IOS DEVICE
1. Switch on the card reader
Briefly press the green key.
The device is starting-up.
2. Make your card reader visible for Bluetooth
Date, time and
a. On the card reader you get the message
battery indicator
app ready". Press the green key for
b. Then you get to see
so that "Expose"
Contactless
for OK.
reader
3. Switch on Bluetooth on your smartphone
Function key
a. Open the menu
b. Then press "Bluetooth".
Stop key
c. Make sure Bluetooth is switched on and the smartphone is
Cancel key
"visible".
OK key
4. Connect your smartphone with the card reader via the
Bluetooth menu
The name of the card reader appears after a while on the screen
of your smartphone under
and then you see a pin code on both devices. Verify if the pin is
the same on both devices.
a. Press the green key for
b. Select "Pair"
5. After the Bluetooth connection is made, wait until the
Bluetooth icon at the top left of the terminal screen turns
green.
6. Launch the
Sign in with your username and password.
"Please keep your
OK.
"Search" and "Expose". Press F3 once
is indicated and press again the green key
"Settings" on your smartphone.
"Other devices". Press "Link2500"
OK on the card reader
on the smartphone
"Mypaydesk" app on your smartphone
CONNECT WITH AN ANDROID DEVICE
1. Turn on the card reader
Briefly press the green key.
The device is starting-up.
2. Launch the "Mypaydesk" app on your smartphone
Sign in with your username and password.
3. Enable Bluetooth on your smartphone via the application
settings
Take the following actions in the "Mypaydesk" app
a. Select the "menu" (3 horizontal lines) in the upper
left corner
b. Select "Settings"
c. Select "Device Management".
d. Select "Pair With New Card Reader".
e. Select "OK" to navigate to the Bluetooth settings
f. Make sure Bluetooth is switched on and the
smartphone is "visible".
4. Connect your smartphone with the card reader via
Bluetooth
The name of the card reader appears after a while on the
screen of your smartphone under "Available devices". Press
"Link2500"and you'll see a pin code on both devices. Verify if
the pin is the same on both devices.
a. Press the green key for OK on the card reader
b. Select "Connect" on the smartphone
5. Configure the card reader in the
"Mypaydesk"
"Configure card readers"
Select in the applications menu.
Press the Link2500 and select "connect".
app
