Specifications Of The Planer/Moulder - Wood-mizer MP260 Original Instructions Manual

See table 7-1. Weight of the MP260 planer/moulder are given in the table below.
7.2

Specifications of the planer/moulder

See table 7-2. Wood-Mizer MP260 planer/moulder nomenclature is given in the table below.
See table 7-3. See the table below for specifications of the MP260 planer/moulder motors.
motor specifica-
Motor Type
Rated Voltage
Rated motor revo-
lutions
Rated cutter revo-
lutions
Rated power
Wood-Mizer Part #
PLANER/MOULDER SPECIFICATIONS
Planer/moulder type
Weight
MP260EA10S-V
MP260EA11S-V
MP260EA13U
MP260EA13U-V
MP260EB12S
MP260EB13S
MP260EB12U
MP260EB13U
MP260EB13U-V
MP260EC13U
MP260EC13U-V
MP260EH12S
MP260EH13S-V
Upper cutter Lower cutter
motor specifica-
tions
Electric Motor Electric Motor
3x400V 3x400V
2900 r.p.m. 2900 r.p.m.
6000 r.p.m. 6000 r.p.m.
4kW
532811 533644
PLANER/MOULDER SPECIFICATIONS
Specifications of the planer/moulder
MP260
Volts
1 ph 230V, CE Standard
1 ph 230V, UL Standard
3 ph 230V, CE Standard
3 ph 230V, UL Standard
3 ph 230V, UL Standard
3 ph 460V, UL Standard
3 ph 400V, CE Standard
MP260EH12S
Side, fixed cutter
motor specifica-
tions tions
Electric Motor
3x400V
2900 r.p.m.
6000 r.p.m.
3kW 3kW
533646
doc081920
440 kg
TABLE 7-1
TABLE 7-2
Side, movable
cutter motor
specifications
Electric Motor
3x400V
2900 r.p.m.
6000 r.p.m.
3kW
533646
7
Feed motor
specifications
Electric Motor
3x400V
2800 r.p.m.
---.
0,37kW
533642
TABLE 7-3
