Federal regulations require ceiling fans
with light kits manufactured or imported
after January 1, 2009, to limit total
wattage consumed by the light kit to
190W.
Therefore, this fan is equipped
with a wattage limiting device.
Installation Guide
For Model:
E-BO52LN5C1S
E192641
net weight of fan: 19,40 lb. (8.8 kg)
READ THESE INSTRUCTIONS
AND SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 5
Warranty. pg. 9
PRINTED IN CHINA
