Installation Guide

For Models:

AU52EB3L

AU52BNK3L

APPROVED FOR USE

IN DAMP LOCATIONS

4007498

net weight of fan: 13.5 lb (6.1 kg)

READ THESE INSTRUCTIONS AND

AND SAVE THEM FOR FUTURE USE

Need help?

Do you have a question about the AU52EB3L and is the answer not in the manual?

Questions and answers

Summary of Contents for Litex AU52EB3L

Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND AND SAVE THEM FOR FUTURE USE Installation Guide For Models: AU52EB3L Table of Contents: AU52BNK3L Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly.
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches 7 feet that the hanging location allows the blades a (2.13 m) (76 cm) clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft.
Page 5: Fan Assembly. Pgs
5. Fan Assembly. If you wish to extend the hanging length of your fan, set screw hole set screw you must remove the hanging ball from the downrod provided to use with an extended stop pin downrod (sold separately). [If you wish to use the downrod provided, please proceed to instructions following the dotted line below.] hanging ball...
Page 6 5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet box and able to support the fan you are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket and let hanging ball rest on hanging bracket tab the hanging bracket.
Page 7: Wiring
7. Wiring. WARNING: Turn off circuit breakers to current fixture from breaker panel and be sure switch is turned to the OFF position. white supply wire ground CAUTION: Be sure outlet box is properly grounded and that (green or bare) a ground (GREEN or Bare) wire is present.
Page 8: Blade Assembly
9. Blade Assembly. motor housing WARNING: To reduce the risk of serious bodily injury, DO NOT use power tools to assemble the blades. If overtightened, blades may crack and break. Locate 9 blade attachment screws and 9 decorative nuts in one of the hardware packs. blade attachment Place blade arm on TOPSIDE of blade, aligning screws...
Page 9: Testing Your Fan
10. Light Kit Assembly. (cont.) Connect male plug from motor housing to female motor plug from light kit fitter, matching up the colors housing on the male plug with the colors on the female plug for correct fit. Be sure that the plugs connect completely.
Page 10: Troubleshooting
Service at 1-800-527-1292 to arrange for return of fan. 2. Verify that reverse switch is set completely in Return fan, shipping prepaid, to Litex Industries, Ltd. We will either direction. repair or ship you a replacement fan, and we will pay the 3.
