FIELDER CEILING FAN
MODEL
ITEM
#0708569
#JP13EB6CRS
Español p. 18
LISTED
For
Damp Location
E192641
Advertisement
Table of Contents
Related Manuals for Litex JP13EB6CRS
Summary of Contents for Litex JP13EB6CRS
- Page 1 ITEM #0708569 FIELDER CEILING FAN MODEL #JP13EB6CRS Español p. 18 LISTED Damp Location E192641 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-527-1292, 8:30 a.m. - 5 p.m., CST, Monday - Friday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information .........................2 Package Contents .........................4 Hardware Contents .......................5 Preparation ...........................5 Initial Installation ........................6 Fan Mounting ........................7 Wiring ..........................10 Final Installation ........................11 Installing Fan Without Light Kit ....................13 Automated Learning Process/Activating Code ..............14 Operating Instructions For Remote Control and Fan............15 Care and Maintenance ......................16 Troubleshooting........................16 Limited Lifetime Warranty ....................17... - Page 3 SAFETY INFORMATION DANGER If using this fan in a DAMP location, this fan must be connected to a supply circuit that is protected by a Ground Fault Circuit Interrupter (GFCI) to reduce the risk of personal injury, electrical shock or death. WARNING To reduce the risk of fire, electrical shock, or personal injury, mount fan to outlet box marked "ACCEPTABLE FOR FAN SUPPORT OF 35 LBS.
-
Page 4: Package Contents
PACKAGE CONTENTS PART DESCRIPTION PART DESCRIPTION QUANTITY QUANTITY Downrod Yoke Cover Canopy Safety Cable (preassembled) Mounting Bracket Motor Plate Screw Motor Assembly (preassembled) Pin (preassembled) Light Kit Fitter Plate Clip (preassembled) Light Kit Fitter Plate Screw Canopy Mounting Screw (preassembled) (preassembled) Light Kit Fitter Canopy Cover... -
Page 5: Hardware Contents
HARDWARE CONTENTS (shown actual size) E3 Wire Connector Qty. 10 PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware cantents list. If any part is missing or damaged, do not attempt to assemble the product. -
Page 6: Initial Installation
INITIAL INSTALLATION Turn off circuit breakers and wall switch to the fan supply line leads. DANGER: Failure to disconnect power supply prior to installation may result in serious injury or death. This fan can only be mounted with the downrod in the motor assembly (D). -
Page 7: Fan Mounting
INITIAL INSTALLATION Secure mounting bracket (C) to outlet box (not included) using screws, spring washers, and flat washers provided with the outlet box. *NOTE: It is very important that you use the proper hardware when installing the mounting bracket (C) as this will support the fan. FAN MOUNTING Remove pin (E) and clip (F) from yoke at top of Set Screw... - Page 8 FAN MOUNTING 2. Insert downrod (A) through canopy (B), canopy cover (H) and yoke cover (L). [NOTE: Canopy cover (H) must be turned with the shiny side toward the motor assembly (D).] Thread wires from motor assembly (D) through downrod (A). Slip downrod (A) into yoke at top of motor assembly (D), align holes and re-install pin (E) and clip (F).
- Page 9 FAN MOUNTING If you decided to cut back the lead wires in Step 4, strip a 1/2 in. of insulation from end of white wire. Twist stripped ends of each strand of wire within the insulation with pliers (not included). Repeat Step 5 for black, blue (if applicable) and green wires.
-
Page 10: Wiring
WIRING WARNING: To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If your house wire is larger than 12-gauge or there is more than one house wire to connect to the corresponding fan lead wires, consult an electrician for the proper size wire connectors to use. -
Page 11: Final Installation
WIRING Gently slide remote control receiver (J) smooth side up into mounting bracket (C). Turn spliced/taped wires upward and gently push wires and wire connectors (AA) into outlet box. Let antenna from remote control receiver (J) hang to the side. Antenna NOTE: The remote control included with this fan meets the following requirements:... - Page 12 FINAL INSTALLATION Remove light kit fitter plate screw (P) located in the non-slotted hole in light kit fitter (Q) and partially loosen the other two light kit fitter plate screws (P). CAUTION: Do NOT remove screws on light kit fitter (Q) that have washers; these are not the light kit fitter plate screws (P).
-
Page 13: Installing Fan Without Light Kit
FINAL INSTALLATION 5. Install bulbs (R). WARNING: When you need to replace bulb(s), please allow the bulb(s) and glass shade to cool down before touching them. 6. Align slots on glass shade (S) with nodules on the inside of the light kit fitter (Q). Turn glass shade (S) clockwise until it no longer turns. -
Page 14: Automated Learning Process/Activating Code
INSTALLING FAN WITHOUT LIGHT KIT Align hole on the inside of the fitter plate cover (U) with the threaded rod on the fitter plate (T). Secure fitter plate cover (U) by turning fitter plate cover (U) clockwise until it no longer turns. Threaded Assembly is now complete. -
Page 15: Operating Instructions For Remote Control And Fan
AUTOMATED LEARNING PROCESS/ACTIVATING CODE Modifications not approved by the party responsible for compliance could void the user's authority to operate the equipment. *NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 16: Care And Maintenance
CARE AND MAINTENANCE At least twice each year, lower canopy (B) to check downrod (A) assembly, and then tighten all screws on the fan. Clean motor assembly (D) with only a soft brush or lint-free cloth to avoid scratching the finish. -
Page 17: Limited Lifetime Warranty
Contact Customer Service at 1-800-527-1292 to arrange for return of fan. Return fan, shipping prepaid, to Litex Industries, Ltd. We will repair or ship you a replacement fan, and we will pay the return shipping cost.
