Maintenance; Fusing Requirements - Maple Systems HMI5097XL Installation Manual

HMI5000L Installation Guide

Maintenance

SW1 SW2
ON OFF
ON
OFF
OFF OFF
OFF OFF
OFF OFF
Note: HMI Power must be cycled to enable the DIP switch mode.
Touchscreen Calibration mode: This mode allows calibration of the
touchscreen.
Hide System Toolbar: Hides the arrow in the bottom-right corner of the
screen that accesses the System Toolbar (same as "Hide System
Toolbar" in System Parameters and LB9020).
Boot Loader mode: This mode forces the HMI to not execute the
project. This mode is used when replacing or reinstalling the operating
system. All units have an Upgrade OS button in the system menus.
Contact Maple Systems for more information.

Fusing Requirements

If the display does not come on within two seconds of power up, remove
power. An internal fuse (except HMI5043L and HMI5043LB) will prevent
damage if the polarity of the DC power is incorrect. Check wiring to
ensure proper connections and try to power up again.
1010-1018 Rev 06
DIP switch positions (not on all models)
DIP switches shown in the off position.
SW3 SW4
OFF OFF
OFF OFF
ON OFF
OFF ON
OFF OFF
Mode
Touchscreen Calibration mode
Hide System Toolbar
Boot Loader mode
Reserved
Normal operation
