Configuration Wiring

To configure the HMI using the EZwarePlus software, use the Ethernet
Configuration Cable (P/N 7431-0104) or USB Configuration Cable (P/N
7431-0115).
HMI Model
HMI5043L, HMI5043LB,
HMI5070L, HMI5070LB,
HMI5070NL, HMI5097XL,
HMI5097NXL, HMI5100L
HMI5121XL, HMI5150XL
Ethernet
If using a switch or router between the PC and the HMI, use a straight-
through or crossover cable as required by the switch or router.
USB
A USB driver (included with the EZwarePlus software) must be installed
when downloading from the PC to the HMI via USB connection.
Caution: When connecting two powered devices via USB, a
difference in potential can exist between the ground reference on
each device. If there is a difference in ground potential (voltage),
making a connection via a USB cable can complete a ground
loop that may damage the HMI and PC. We recommend using
the Maple Systems USB Configuration Cable (P/N 7431-0115) to
connect the HMI to the PC. The shield is not connected between
the two ends of the cable, which will prevent a potentially
damaging ground loop from occurring between the devices.
Please refer to Page 6 for proper wiring instructions.
1010-1018 Rev 06
Configuration Cable
P/N 7431-0104
Ethernet (Crossover)
X
X
