USB Stick Clamp (not on all models)
The USB Stick Clamp prevents a USB stick from disconnecting from the
HMI due to vibration.
Steps:
1. Insert the USB stick connector into the clamp and secure with the
included zip tie.
2. Press the spring and insert the USB stick into the USB port.
Note: The USB Host port is designed for data storage only. If
connecting a USB hard drive, power the drive with its own power
supply. Do not charge any device from the USB port.
