RMI5001
Installation Guide
Introduction
Thank you for purchasing a Maple Systems RMI5001 non-display HMI
with HDMI port. The RMI5001 is configured using the EZwarePlus
software (purchased separately). This booklet describes the steps
necessary for installing the RMI5001.
For information on programming and configuring the HMI, please refer to
the EZwarePlus Programming Manual (P/N 1010-1015) available on
the EZware software DVD.
For additional information, please refer to the Support Center section of
the Maple Systems website, www.maplesystems.com. The Support
Center provides links to information such as Manuals, FAQs, Technical
Notes, Training Videos, Sample Projects, Controller Information Sheets,
and Controller Cables.
1010-1019 Rev 04
www.maplesystems.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the RMI5001 and is the answer not in the manual?

Questions and answers

Related Manuals for Maple Systems RMI5001

Summary of Contents for Maple Systems RMI5001

  • Page 1 RMI5001 Installation Guide Introduction Thank you for purchasing a Maple Systems RMI5001 non-display HMI with HDMI port. The RMI5001 is configured using the EZwarePlus software (purchased separately). This booklet describes the steps necessary for installing the RMI5001. For information on programming and configuring the HMI, please refer to the EZwarePlus Programming Manual (P/N 1010-1015) available on the EZware software DVD.
  • Page 2 RMI5001 Installation Guide Static Awareness Do NOT remove the cover of your RMI5001 product – doing so will void your warranty. When the cover is removed the circuitry inside is exposed to possible damage by electrostatic discharge during handling. Minimize the possibility of electrostatic discharge by: ...
  • Page 3 No license is granted by implication, or otherwise, under any patent or patent rights of Maple Systems, Inc. Maple Systems retains the right to revise or change its products and documentation at any time without notice.
  • Page 4 RMI5001 Installation Guide Environmental Considerations The RMI5001 is designed to be mounted inside an enclosure rated for the installation. The RMI5001 operates in temperatures from -20° to 55°C (-4° to 131°F). It is intended for indoor installations and may not be suitable for use in certain outdoor applications.
  • Page 5 RMI5001 Installation Guide Cable Routing and Noise Immunity Follow these guidelines when routing cables to the HMI:  Always route the HMI communication cable and the power cable away from any AC voltage or rapidly switching DC control lines. ...
  • Page 6 RMI5001 Installation Guide Figure 1: Typical Panel Layout 1010-1019 Rev 04 www.maplesystems.com...
  • Page 7 For a more in-depth overview of ground wiring techniques, refer to Technical Note #1027, “OIT Ground Wiring and Electrical Noise Reduction” in the Technical Notes section of the Maple Systems website. Installation It is necessary to follow all installation procedures described in this chapter for electrical noise immunity and CE compliance.
  • Page 8 HMI. The power cable for the HMI should be 18AWG, 2-conductor wire with a shield drain wire and protective shield (foil/braid). Cable (P/N 6030-0009) may be purchased by the foot from Maple Systems for constructing power cables. Always run the DC ground wire directly back to the signal return of the power supply.

  • Page 9: Panel Preparation

    Push the top tab up and the bottom tab down to expose the mounting holes. HDMI Connection A standard Type-A HDMI socket is provided on the top of the RMI5001 series. Use the HDMI socket to connect any video display that supports HDMI at 1280x720 resolution.
  • Page 10 RMI5001 Installation Guide USB/SD Port The RMI5001 has an SD card slot and USB host port. These ports are designed for keyboard/mouse connection or data storage only. Note: If connecting a USB hard drive, power the drive with its own power supply.

  • Page 11: Serial Port Connections

    Boot Loader mode: This mode forces the HMI to not execute the project. This mode is used when replacing or reinstalling the operating system. Contact Maple Systems for more information. Restore Factory Settings: Erase project data and restore factory settings such as IP settings and passwords.
  • Page 12 Maple Systems Inc. 808 134 Street SW, Suite 120 Everett, WA 98204-7333 Phone: (425) 745-3229 Email: maple@maplesystems.com Web: www.maplesystems.com © 2016 Maple Systems Inc. All rights reserved.
